Page 1: Operating Instructions
OPERATING INSTRUCTIONS Dust Extractor READ ALL INSTRUCTIONS BEFORE USING... - Page 2 Dear Customer, Thank you for choosing Ermator as your supplier. We hope that the Ermator S13 dust extractor will be to your satisfaction and meet your expectations. Ermator has been manufacturing professional dust extractors since 1967 and has over the years acquired a genuine technical knowledge in this area.
-
Page 3: Safety Instructions
Unpacking When unpacking the machine, please check that the following accessories are included: • The hose with end fittings. • Handle. • Floor nozzle. • Extra bags. If any of the above-mentioned parts are missing, please contact your local distributor or our sales representative. -
Page 4: Filter Change
Function The machine is designed for sucking and separating dry, non-combustible dust with an explosion limit value of >0.1mg/m The motor is started by the switch. The switch has three positions: 0: Motor off 1: Motor on 2: Autostart function, only 230V version (When you use the dust extractor together with another machine, there is an electrical outlet on the dust extractor. -
Page 5: Warranty
For other spare parts, see the enclosed spare parts list. Warranty All Ermator devices and accessories have a 12-month factory warranty for material and manufacturing defects. The warranty extends to 36 months when returning the attached warranty slip. Do not attempt to repair the suction apparatus without the consent of the manufacturer. -
Page 6: Problem Solving
Problem solving The S13 is designed and manufactured for a severe environment and tasks, but the user must note that the machine must be protected from knocks and blows. Filter, seals, attachments, and connections are carefully adapted and selected with regard to the operator’s work environment. Therefore, the operator and service personnel must treat the machine with care in order to work correctly for many years. -
Page 7: Technical Data
TECHNICAL DATA 120V VOLTAGE (120VAC, 1-phase) POWER 1200 W max MAX AIRFLOW 200 m³/h 129 cfm MAX VACUUM 26 kPa 4m x ∅ 38mm HOSE 13’x ∅ 1,5” ∅ 50mm INLET ∅ 2” >99.5% MAIN FILTER 1.5m /16,6ft >99.95% 1st HEPA 13 FILTER 1.2m /13,32ft... - Page 8 OM ÖVERENSSTÄMMELSE DECLARATION OF CONFORMITY DECLARATION DE CONFORMITÉ ERKLÄRUNG DER ÜBERSTIMMUNG SAMSVARSERKL∅RING Pullman Ermator AB Industrivägen 10 S-777 34 SMEDJEBACKEN Försäkrar under eget ansvar att maskinen Declare under our sole responsibility that the machine Certifie sous sa propre responsabilité que le produit ciaprès...
- Page 9 S13 120V Number 200900249a S13 120V Model Rev. Revision 0...
- Page 10 S13 120V POS. QTY. NUMBER DESCRIPTION 201000117 TOP COVER ASSEMBLY (ex.S13) 201000118 CLEANING UNIT KIT 201000016 MAIN FILTER (ex. S13) 201000119a TANK COMPLETE (ex. S13 US) 200600799 HOLDER KIT 201000120 HANDLE KIT 201000116 FLAP KIT 1351145 ANTI-SKID 1371001 BELT 1276008...
- Page 11 Revision 0...
- Page 12 200700413 MANOMETER KIT 200600482 ENGINE COVER, KIT 1370019 COVER 1362184 CABLE FIX 1361025 CORD SET 201000134 CHASSI, COMPLETE 201000133 COUNTER KIT 6362109 SWITCH 201000138 S13 120V MOTOR KIT 200700396 CABLE KIT Number 200600398a Model ENGINE PACK 120V Rev. Revision 0...
- Page 13 ACCESSORIES S13 120 V NUMBER DESCRIPTION POS. 200900281 HOSE 38mm x 4m 6324034 KC004 SUCTION PIPE 1326054 GRD370 FLOOR TOOL 1340011 D370A RUBBER BLADES Revision 0...
- Page 14 Notes ______________________ ______________________ ______________________ ______________________ ______________________ ______________________ ______________________ ______________________ ______________________ ______________________ ______________________ ______________________ ______________________ Revision 0...
- Page 15 Revision 0...
- Page 16 Revision 0...
- Page 17 Revision 0...
