- Page 1 User Manual MeticaFM 7 Field Monitor...
-
Page 2: Table Of Contents
MENU MeticaFM 7 Caution ....................Components ..................Control & Functions ................Compatible Input Formats ..............Menu Tree & Adjustment ..............OSD (On-screen Display) Menu ............[1] Picture ..................[2] Color ..................[3] Display ..................[4] Marker ..................[5] Advanced ................. -
Page 3: Caution
CAUTION MeticaFM 7 • Always use set voltage. (DC 6.8-12V) • If any of the following conditions occurs, unplug the power cord from the DC outlet, • All operating instructions must be read and and request a quali ed service person to understood before the product is operated. -
Page 4: Components
COMPONENTS MeticaFM 7 MeticaFM 7 with Hood Junior Joint HDMI Mini to Standard Cable BNC Cable (SDI version) D-tap to Mini XLR Cable USB Upgrade Cable AC Adapter... -
Page 5: Control & Functions
CONTROL & FUNCTIONS MeticaFM 7 TALLY SDI IN & OUT * DC 2.5Φ 6.8-18 V USB 2.0 TALLY POWER SIGNAL HDMI IN & OUT FUNCTION Scroll up Click Scroll down MENU TALLY * These options only available on the SDI version. -
Page 6: Compatible Input Formats
COMPATIBLE INPUT FORMATS MeticaFM 7 The following standards are supported by the MeticaFM 7 eld monitor: 1080p(24/25/30/50/60), 1080i(50/60), HDMI 720p(50/60), 576p(50), 576i(50), 480p(60), 480i(60) 1080p(60/59.94/50/30/59.97/25/24/24sf) SMPTE-425M-A/B 1080i(60/59.97/50) 1080p(30/29.97/25/24/24sf) SMPTE-274M 1080i(60/59.94/50) SMPTE-296M 720p(60/59.94/50) SMPTE-125M 480i(59.94) ITU-R BT.656 576i(50) MENU TREE & ADJUSTMENT... - Page 7 (Default), [Low], [Middle], [High] System OSD Time [Off] (Default), [5 seconds], [10 seconds], [15 seconds] Reset [No] (Default), [Yes] Software Version Hardware Version * The functions with an asterisk are only available for MeticaFM 7 units that have upgraded to the advanced chip.
-
Page 8: Osd (On-Screen Display) Menu
• Pattern Generator * Use this setting to check the color and gray levels of your display. Push any key to exit this function. [PLEASE NOTE: This function is only available for MeticaFM 7 units that have upgraded to the advanced chip.]... -
Page 9: Color
Use this setting to activate the False Color function. It cannot be used in conjunction with Range Error. A color key will be displayed on the monitor for exposure reference. [PLEASE NOTE: This function is only available for MeticaFM 7 units that have upgraded to the advanced chip.] •... -
Page 10: Display
Use this setting to activate the Histogram in the bottom, right corner of the screen. Use the Histogram to help understand the overall exposure of your image. [PLEASE NOTE: This function is only available for MeticaFM 7 units that have upgraded to the advanced chip.]... -
Page 11: Marker
• Marker Color* Use this setting to change the Marker Color between the following: Black, White, Red, Green*, Blue*. [PLEASE NOTE: Green and Blue marker colors are only available for MeticaFM 7 units that have upgraded to the advanced chip.]... -
Page 12: Advanced
• Peaking Filter (Focus Assist) Use this setting to activate the Peaking Filter. [ PLEASE NOTE: If you have upgraded your MeticaFM 7 to the advanced chip, you can change the Peaking Filter color between red and white. ] • Peaking Level Use this setting to change the sensitivity of the Peaking Filter from 0 to 5. -
Page 13: Audio
• Audio Column* Use this setting to activate the audio column in the bottom-left corner of the screen. [PLEASE NOTE: If you have upgraded your MeticaFM 7 to the advanced chip, you can change the Peaking Filter color between red and white.]... -
Page 14: System
OSD (On-screen Display) MENU MeticaFM 7 [7] System • Input Source Use this setting to change the input source between HDMI and SDI. • OSD Language Use this setting to change the language of the OSD. • OSD Transparency Use this setting to change the transparency of the OSD between: Off, Low, Medium, High. -
Page 15: Speci Cations
SPECIFICATIONS MeticaFM 7 Size 7” Resolution 1024 X 600 px Pixel Pitch 0.15 mm Color Depth 16.7M Viewing Angle 170°(H) / 170°(V) Luminance of white 400cd/ Contrast Ratio 800 : 1 Display Area 153.6 (H) × 90.0 (V) mm 1 X BNC* 3G/HD/SD-SDI –... -
Page 16: Dimensions
DIMENSIONS MeticaFM 7 193 mm 142 mm 43 mm... -
Page 17: Maintenance
MAINTENANCE MeticaFM 7 • Screen Cleaning Periodically clean the screen surface using non-abrasive, ammonia-free cleaning wipes. A clean micro ber cloth can also be used. Do not use paper towels. Paper towel bers are coarse and may scratch the surface of the polycarbonate faceplate or leave streaks on the surface. - Page 18 MEMO MeticaFM 7...
- Page 19 MEMO MeticaFM 7...
- Page 20 F&V Photographic Industry B.V. Steenovenweg 5, 5708HN Helmond, Netherlands For more information visit: fvlight.com TM & © F&V All rights reserved.
