INSTRUMENT PANEL
1
2
3
4
10
1. Instrument panel
2. Hazard light switch
3. Power shuttle lever
4. Adjustment knob of the power shuttle engagement speed
5. Ignition switch
6. Multifunction lever
7. Light switch
8. Adjustment lever of the steering wheel position
9. Control panel of the instrument panel display
10. Steering wheel tilt pedal
5
6
7
9
8
1. Speed gear lever
2. Hand throttle
3. Engine RPM memory button
4. Switch for four-wheel drive (4WD)
5. Switch for differential lock
6. Switch for creeper gear (optional for PowerShuttle models)
7. Air Pressure trailer brake test switch (optional)
8. Range gear lever
9. Lever for creeper gear (A74-A94)
10. Engine RPM memory button rear (optional)
11. Lowering speed selector
12. Max lifting height selector
13. Draf control selector
14. Drive balance control knob
15. Indicator light of the drive balance control
16. Work position marker
17. Work position control knob
18. AutoControl switch (lift/stop/lower)
19. Forced lowering button
20. Lifting/lowering switch
21. Trailer hitch release lever
22. Position locking of the valve control lever
23. Control lever for auxiliary hydraulic valve 1
24. Control lever for auxiliary hydraulic valve 2
25. Control lever for auxiliary hydraulic valve 3
26. Control stop switch (optional)
