INTRODUCTION GENERAL VIEW OF THE BH EMOTION PEDAL ASSISTANCE SYSTEM How does it work? Without pedal assistance Start pedaling DISPLAY PANEL General View of Display Panel Display panel operation 1. Removable display panel 2. Start and stop of the pedal assistance system 3. -
Page 3: Introduction
Belgian Gustave Deloor (1913 - 2002), who won the first two editions of the Vuelta a España in 1935 and 1936. Up to this date, BH has won seven Vueltas a España, the last one in 1986 with Alvaro Pino. In that edition, the team Zor-BH also came first in the team classification. -
Page 4: General View Of The Bh Emotion
GENERAL VIEW OF THE BH EMOTION EVO/NITRO REVO EMOTION Display Panel EMOTION Display Panel Rear motor Central motor Motor Motor Torque sensor Torque sensor Ion Lithium battery Ion Lithium battery EVO AWD EASY GO EMOTION Display Panel AWD in two motors... -
Page 5: Pedal Assistance System
PEDAL ASSISTANCE SYSTEM How does it work? The BH EMOTION pedal assistance system comprises the following elements: A. A motor, which drives the bike. The location of the motor describes the system of the e-bike: FDS (Front Drive System). Motor located in the front hub. -
Page 6: Without Pedal Assistance
Without pedal assistance BH EMOTION may be used as a conventional bicycle. It comes equipped with a direct current electrical motor featuring Brushless technology. The magnetic type torque sensor also uses brushless technology. Therefore, pedaling without assistance is carried out with no additional resistance. -
Page 7: Display Panel Operation
POWER button for starting or stopping the system. Button (+). Button (-). Bicycle lights and display panel backlight indicator. Bicycle instant speed indicator. System error indicator. Pedal assistance level indicator. Battery level indicator. Bicycle information indicator. Display panel operation 1. Removable display panel The user can make the display panel be removable or not, as easily as inserting or removing a M3 screw, as it is shown in the image below:... -
Page 8: Selection Of Pedal Assistance Level
3. Selection of pedal assistance level The system has 5 levels of pedaling assistance (including the without assistance mode) To move through the assistance modes, the user should press the (+) button to increase the level of assistance and the (-) button to reduce the level of assistance. -
Page 9: Adjustments
60 - 80% 40 - 60% 20 - 40% 10 - 20% 0-5% 80 - 10% 5-10% CAPACITY CAPACITY CAPACITY CAPACITY CAPACITY CAPACITY CAPACITY blinking only only MODE 0% MODE 100% MODE 30% lights 7. Adjustments The user can access the adjustments menu by pressing buttons (+) and (-) for 3 seconds. Press the POWER button to scroll through the adjustments options: The system will exit the “Adjustments”... -
Page 10: Throttle Function Up To 6 Km/H
8. Throttle function up to 6 km/h The BH EMOTION system has a throttle function integrated into control limited to a maximum speed of 6 km/h, according to the EN 15194 standard. To activate the throttle, the user should press and maintain pressed the (+) button for 3 seconds, and give an initial impulse to the bike. -
Page 11: Battery
BATTERY Technology The battery which comes equipped with your BH EMOTION is Ion-Lithium type and is the highest technology available regarding energy density (energy stored per kilogram of weight and per cm3 of volume). There are several different battery options depending on their location in the bicycle: BH EMOTION batteries have different capacities, depending on the acquired version. -
Page 12: Charge Of The Battery
Charge of the battery Due to its advanced Ion-Lithium technology, reaching a full discharge of the battery before connecting it to the charger is not necessary. Likewise, fully charging the battery to its 100% capacity before use is not necessary. But take into consideration that in order to obtain a maximum operation range a full charge is recommended. -
Page 13: Checking The Charge Level Of The Battery In The Rear Carrier
Only use the charger provided with the battery. Do not place any object on the charger. Charging the BH EMOTION battery at 70-80% is mandatory if not used or stored for a long time period. Additionally, control the level of the battery charger every 3 months and keep it always above 20% charge. -
Page 14: Motor
- Keep out of animal and children’s reach. - When unplugging the cable from the outlet, do not pull the cable, pull the plug. Always pull the charger’s cable smoothly. - Do not use outlets, connectors or other electrical systems with different voltages than the standard. - Do not use damaged components, such as the chargers casing, cable or pin;... -
Page 15: Warranty Programme
(including a late replacement of parts subject to wear and tear). In the event that BH accepts a warranty claim, this does not imply, in any case, the acceptance of responsibilities due to the possible damages incurred. In the event of a dispute regarding damages suffered (subsequent), BH shall be exempt of any responsibility to that effect, as it is not legally bound to compensation. -
Page 16: Technical Characteristics
The maximum assistance speed is limited to 45 km/h. Isn’t the BH EMOTION bicycle too heavy? No, considering that the weight of BH EMOTION bicycles is between 16.75 kg and 24.40 kg, depending on different models, they are the lightest electrical bicycles in the market. The pedal assistance provides the BH EMOTION an additional weight of 5-6 kg when comparing a standard bicycle with the same characteristics, which is the sum of the battery and the motor. - Page 17 Must I charge the battery when not in use? It’s not necessary. The battery may be stored in a dry place or left on the BH EMOTION bicycle.
- Page 18 BH dealer. System overvoltage Torque sensor out of range Over temperature Restart the system. If error does not disappear, contact a BH dealer. Below temperature Current out of range Torque sensor out of range Speed sensor signal...
