Summary of Contents for Instrumentation Systems & Services DL169-IN-B

  • Page 2 DL169-IN-B DL169-IN DL169-IN-B – The circuit Radiomodems DL169-IN-B and its open version DL169-IN are built by the interface and supply card RMO148 and the radiomodem module DL169. The RMO148 card realises the following functions: Power supply conditioning. A step-down switching regulator give a stabilised voltage of 5 Vdc from an input voltage between 8 to 36 Vdc.

  • Page 3: Note On Power Supply

    NOTE ON POWER SUPPLY The Radiomodem DL169 or DL169-IN-B should be fed with a power limited voltage source between 8 and 36 Vdc and is not re- quired a stabilisation due to the presence of an internal efficient stabiliser. The power supply is protected against polarity reversing and is protected by a 750 mA internal SMT fuse.

  • Page 4: Starting Use

    ERE Stradella Italy DL169-IN-B Starting use: The DL169 device is delivered with the following default configuration: ♦ 169.40625 channel radio in broadcasting mode, transparent to the user. ♦ 9,600 bps UART Data Rate, 8,N,1 format, No Flow Control and 448 Bytes Buffer size ♦...
  • Page 5 DL169 -IN-B - CONFIGURATION The Radiomodem setup is achieved by the Configuration Software DL148SW-IN dedicated to all devices DL*** series. This software is www.ere-online.it releasable from our Internet website at URL: Follow the configuration procedure: 1 - Install the configuration software on your Personal computer. The required OS are Windows ’95 → XP and the PC must have a RS-232 Port. 2 - Connect the radiomodem RS-232 port to the computer COM port with a straight cable (NO Null Modem).
  • Page 6 DL169-IN-B - CONFIGURATION ADVANCED : ITS ADDRES – Address of the radiomodem unit. Allowable values between 1 and 255. The address defines univocally each radiomodem. The value 1 in a unit of a Point-Multipoint network operating in Power Saving Mode denotes the always powered Master Unit.

  • Page 9: Bill Of Materials

    BILL OF MATERIALS C:\CIRCAD\FILES\RM148\RMO148.PCB 27/04/09 ------- DESCRIPTION ------- QTY ------------------ LOCATIONS ------------------ 100p NP0 50V 220p X7R 50V X7R 50V 100n X7R 50V 1µ X5R 16V 100µ 100µ MBRM140T PMLL4148 SM4007 Z9V1 DE9-F HEAD2 HEAD21 HEAD6 RF-BNC 100µH A7502HY-101M L3VEGW L934RD HMHAA280 OPT1...
