4-Channel Voice Receiver
STI-V34104
EASY STARTUP
Install batteries in sensor,
plug in receiver and listen
to instructions.
HOW THE PRODUCT WORKS
The 4-Channel Voice Receiver is a multipurpose long-range receiver that works
with a wide range of STI Wireless Alert Series sensors. Most products can
achieve up to 1,000' receiver range (line of site). Four zone indicators light up
to indicate a sensor has triggered. Selectable tones and voice messages are a
key feature. Sensors have default messages or program your own by choosing
up to four words or tones from a preprogrammed list. All voice messages are
available in English or Spanish. Receiver is intended for indoor use only.
We protect the things that protect you.
®
- 1 -
Advertisement
Table of Contents
Related Manuals for Safety Technology International STI-V34104
Summary of Contents for Safety Technology International STI-V34104
- Page 1 4-Channel Voice Receiver STI-V34104 EASY STARTUP Install batteries in sensor, plug in receiver and listen to instructions. HOW THE PRODUCT WORKS The 4-Channel Voice Receiver is a multipurpose long-range receiver that works with a wide range of STI Wireless Alert Series sensors. Most products can achieve up to 1,000’...
- Page 2 BEFORE YOU START Review detailed product specifications (Fig. 1 and 2) Antenna Jack · Internal antenna with product · Use external for maximum range Volume Control High Lamp Controller Output · Works with STI Lamp Controller (STI-30104) · 3.5mm mono jack, center negative ·...
- Page 3 ZONE PROGRAMMING PROCEDURES Only receives wireless signals from the STI Wireless Alert Series products. Program up to 4 sensors or keyfobs. Does not allow programming into an occupied zone. Cannot program the same sensor into more than one zone. The unit will state, “Please change to normal mode if programming is completed.”...
- Page 4 PROGRAMMING 1. Plug in receiver. 2. Listen to verbal voice commands. They will guide you through programming. Notes · Firmly press acknowledge button at any time to stop voice. · Make sure battery is installed in sensor. · Each sensor provides an initial sound (DONG). (See CHART 2 below) ·...
- Page 5 ADVANCED PROGRAMMING FOR ALREADY PROGRAMMED SENSORS (DIP SWITCH 3-8) Dip Switches 3-8 provide access to all 63 messages/tones which can be assigned to any zone. Up to 4 messages/tones can be combined to create a custom message. See page 6, CHART 3, for Advanced Dip Switch Message Codes.
- Page 6 ADVANCED DIP SWITCH MESSAGE CODES ALPHABETICAL (ENGLISH) GROUPINGS DIP SWITCH LANGUAGE DIP SWITCH LANGUAGE 3 4 5 6 7 8 English Spanish 3 4 5 6 7 8 English Spanish GROUP 0 0 0 1 0 0 4-NOTE CHIME CARILLON DE 4 NOTAS 0 0 0 1 0 0 4-NOTE CHIME CARILLON DE 4 NOTAS...
- Page 7 The receiver can be mounted on a wall or set on a table with the provided stand. WARRANTY INFORMATION Safety Technology International, Inc. warrants to the original consumer/purchaser that this product shall be free of defects in material and workmanship under normal use and circumstances for a period of one (1) year from the original date of purchase.
- Page 8 Operation is subject to the following two conditions: (1) this device may cause interference, and (2) this device must accept interference, including interference that may cause undesired operation of the device. Changes or modifications not expressly approved by Safety Technology International, Inc. could void your authority to operate this equipment.
