SERVICE
COLOR TELEVISION RECEIVER
COLOR TELEVISION RECEIVER
Chassis : S62B(P)_SHINE
Model
: WS32Z306VBXXEC
Manual
WS32Z306V
FEATURES
Slimfit(Low Depth) CRT
■
■
■ SRS-WOW
Simple 100Hz
■
■
