1. Parts and Functions

Manual
Monitor
Memory
Playback
Playback

2. Monitor mounting

Use the screws to fix the Mounting Bracket on the wall.(accessories include a
Bracket, two 4X25 screws (use to fasten the Mounting Bracket), 2 wire cables (use
to connect with Monitor)).
Connect the system correctly. then hang the Monitor on the Mounting Bracket
¿UPO\
Monitor
Intercom
Multimedia
Close
Album
User Setup
09/30/2010 Thu.16:41
DIPS
L1
ON
L2
1 2 3 4 5 6
Home Screen
UNLOCK Button
MONITOR Button
TALK Button
CALL Button
MENU Button
Microphone
Ventilation Vent
Speaker
Connection Port
Mounting Hook
-
