FOMA
M702iG
Manual for Data Communication
Data Communications .........................................................................................
Before Using.........................................................................................................
Preparing for Data Communication ...................................................................
...............................................................................................................................
Configuring Communication Settings Using FOMA PC
FOMA PC Configuration Software .............................................................
Installing the FOMA PC Configuration Software ......................................
Configuring Communication Settings .......................................................
Start Communicating ..................................................................................
W-TCP Settings ............................................................................................
Setting APN ..................................................................................................
Uninstalling the FOMA PC Configuration Software .................................
Configuring Communication Settings without Using FOMA
Configuring a Dial-up Network ...................................................................
Communicating............................................................................................
AT Commands......................................................................................................
AT Command List ................................................................................................
About Manual for Data communication
This manual explains the items required for making data communication on the FOMA M702iG as well as
how to install "M702iG 通信設定ファイル（ドライバ）(M702iG Communication Configuration Files
(Drivers))" and "FOMA PC 設定ソフト (FOMA PC configuration Software)" inside the CD-ROM.
About Windows XP Operation
This manual explains the contents compliant with Windows XP Service Pack 2. Some procedures and
displays in this manual may differ depending on your operating environment.
1
2
3
4
5
6
7
7
9
9
11
15
16
17
18
19
24
26
27
