BX811
Hyper Box IP Camera
User's Manual
Ver. 1.7
001B06ZXZ1A7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BX811 and is the answer not in the manual?

Questions and answers

Summary of Contents for Tracker BX811

  • Page 1 BX811 Hyper Box IP Camera User’s Manual Ver. 1.7 001B06ZXZ1A7...
  • Page 2: Table Of Contents

    Table of Contents Overview ..........................2 Features ........................2 Package Contents ....................... 3 Dimensions ........................4 Connectors ........................5 1.4.1 Light Sensor ....................6 Camera Cabling ........................6 Power Connection ....................... 6 Ethernet Cable Connection ..................6 Lens Mounting ......................7 Alarm I/O Connection ....................
  • Page 3: Overview

    Overview Hyper Box IP Camera offers up to 4k2k resolution in real-time, providing extraordinary images. With state-of-the-art encoding SOC, the camera is capable of streaming 8MP resolution in real-time or 6MP resolution in real-time + 720P in real-time (or 2MP@120 fps). Multiple Region of Interest (ROI) and 3D Noise Reduction are also supported for different application scenarios.
  • Page 4: Package Contents

    Package Contents Please check the package containing the following items listed below. Hyper Box IP Camera Power Switch Connector Quick Guide (bundled software and documentation)
  • Page 5: Dimensions

    Dimensions The dimensions of the camera are shown below. Non-ABF Models ABF Models...
  • Page 6: Connectors

    Connectors The diagram below shows the various connectors of the camera. Definition for each connector is given as follows. DC 12V / AC 24V / PoE DC 12V / AC 24V / PoE (RS-485) Connector Definition Audio I/O Two-way audio transmission Press the button with a proper tool for at least 20 Default Button seconds to restore the system.
  • Page 7: Light Sensor

    1.4.1 Light Sensor A light sensor is used to detect the ambient light for day/night switching function. The light sensor is located at the front of the cameras. The location and definition of the light sensor is as below. Non-ABF Models ABF Models Item Definition...
  • Page 8: Lens Mounting

    Check the status of the link indicator and the activity indicator LEDs. If the LEDs are unlit, please check the LAN connection. Green Link Light indicates good network connection. Orange Activity Light flashes for network activity indication. Lens Mounting Follow the steps below to mount the C/CS Mount Lens to the camera. Step 1: Remove the plastic cover of the camera.
  • Page 9: Alarm I/O Connection

    Alarm I/O Connection The camera supports one alarm input and one relay output for alarm application. Refer to alarm pin definition below to connect alarm devices to the IP camera if needed. DC 12V / AC 24V / PoE DC 12V / AC 24V / PoE (RS-485) 1.
  • Page 10: System Requirements

    System Requirements To perform the IP camera via web browser, please ensure the PC is in good network connection, and meet system requirements as described below. Items System Requirement Minimum : 1. Intel® CoreTM i5-2430M @ 2.4 GHz 2. 4 GB RAM Recommended : Personal Computer 1.
  • Page 11: Access Camera

    Access Camera For initial access to the IP camera, users can search the camera through the installer program: DeviceSearch.exe, which can be found in “DeviceSearch” folder in the supplied CD. Accessing the Camera by Device Search Software Step 1: Double click on the program Device Search.exe. Step 2: After its window appears, click on the <Device Search>...
  • Page 12 Step 8: A prompt window requesting for default username and password will appear. Enter the default username and password shown below to login to the camera. Login ID Password admin admin NOTE: ID and password are case sensitive. NOTE: It is strongly advised that administrator’s password be altered for the security concerns.
  • Page 13 Once the Viewer is successfully installed, the Home page of the IP camera will be shown as the figure below. Non-ABF Models...
  • Page 14 ABF Models NOTE: For more details about the function buttons on the Home page, please refer to the Hyper IP Camera Menu Tree in the supplied CD.
  • Page 15: Setup Video Resolution

    Setup Video Resolution Users can setup video resolution on Video Format page of the user-friendly browser-based configuration interface. Video Format can be found under this path: Streaming> Video Format. The default values of video resolution are as below. H.264- 1920 x 1080 (60/50 fps) + H.264- 720 x 480 (30 fps) / 720 x 576 (25 fps) H.264- 1920 x 1080 (60/50 fps) + 2M-Advanced...
  • Page 16: Configuration File Export / Import

    Configuration File Export / Import To export / import configuration files, users can access the Maintenance page on the user-friendly browser-based configuration interface. The Maintenance setting can be found under this path: System> Maintenance. Users can export configuration files to a specified location and retrieve data by uploading an existing configuration file to the camera.
  • Page 17: Tech Support Information

    Tech Support Information This chapter will introduce how to delete previously-installed Viewer in the PC and how to setup the Internet security. Delete the Existing Viewer For users who have installed Viewer in the PC previously, please remove the existing Viewer from the PC before accessing to the camera. Deleting the Viewer In the Windows <Start Menu>, activate <Control Panel>, and then double click on <Add or Remove Programs>.
  • Page 18: Setup Internet Security

    Setup Internet Security If ActiveX control installation is blocked, please either set Internet security level to default or change ActiveX controls and plug-ins settings. Internet Security Level: Default Step 1: Start the Internet Explorer (IE). Step 2: Click on the <Tools> tab on the menu bar and select <Internet Options>.
