- Page 1 2U Storage System User Manual SS2280 Jun. 2007 (Revision C) P/N: 1230B0033901...
-
Page 2: Copyright Notice
Copyright Notice All rights, including copyright, in the content of this manual are owned or controlled by IESC and protected by the Taiwan and international copyright act. No one may, transmit, adapt, assign, compile, rent, sale, change, copy, reproduce, distribute, publish, display, broadcast, or use in any way the content of this manual, in whole or in part, for any other purpose whatsoever without the prior written permission of IESC. -
Page 3: Table Of Contents
Contents About This Manual ........................i Conventions ..........................i Safety Symbols ........................... ii Safety Precautions........................iii Operation Safety ........................iii Electrical Safety........................iii Battery Replacement Safety....................iv Laser Peripherals or Devices Safety ..................v Intended Application Uses ....................... v Site Selection .......................... v Tools Required ........................ - Page 4 2.4.2 To install a DIMM....................2-11 System Configuration Jumper ..................2-12 Hardware Operations ......................3-1 Before You Start ......................3-1 3.1.1 Power Off .......................3-1 Chassis Cover .......................3-2 Motherboard ........................3-4 Power Distribution Board....................3-6 Power Supplies ......................3-7 IDE Converter Board .....................3-9 System Fan Assemblies ....................3-11 SATA&SAS Backplane ....................3-14 SATA&SAS HDDs .......................3-17 3.10...
- Page 5 Figure 2-3 Processor Location...................2-4 Figure 2-4 Pulling up the Two Levers.................2-5 Figure 2-5 Lifting the Heat Sink up..................2-5 Figure 2-6 Pulling up the Two Levers.................2-6 Figure 2-7 Placing the Heat Sink on Top of the Processor..........2-6 Figure 2-8 Locking the Two Levers ..................2-6 Figure 2-9 Opening the Load Plate ..................2-7 Figure 2-10 Lifting the Processor out of the Socket ............2-7 Figure 2-11 Closing the Load Plate..................2-7...
- Page 6 Figure 3-26 Backplane Location ..................3-15 Figure 3-27 Removing the Backplane Assembly .............3-15 Figure 3-28 Removing the Backplane................3-16 Figure 3-29 Fixing the Backplane to the Backplane Bracket..........3-16 Figure 3-30 Installing the Backplane Assembly ...............3-16 Figure 3-31 Location of HDD Assemblies ................3-17 Figure 3-32 Releasing the Lever..................3-17 Figure 3-33 Sliding the HDD Assembly................3-18 Figure 3-34 Placing the HDD to the HDD tray ..............3-18...
- Page 7 Figure 4-14 Connecting the 4-pin Backplane Power Cable ..........4-8 Figure 4-15 Connecting the Power Supply I C Cable ............4-8 Figure 4-16 System Fan Connector Locations..............4-9 Figure 4-17 Connecting the System Fan Cable ..............4-9 Figure 4-18 Connecting the System Fan Power/Fan Tach Cable ........4-10 Figure 4-19 Connecting the Chassis Intrusion Cable............
-
Page 8: About This Manual
About This Manual Conventions Safety Symbols Safety Precautions Regulatory and Integration Information... - Page 9 About This Manual About This Manual Conventions To make sure that you perform certain tasks properly, take note of the following symbols used throughout this manual. Information to prevent injury to yourself when trying to complete a Warning: task. Information to prevent damage to the components when trying to Caution: complete a task.
- Page 10 About This Manual Safety Symbols Before troubleshooting, you must be familiar with the safety information listed below. In order to avoid any potential hazards, the following symbols may be placed on some components of the server. The shape and the color of symbols shown below are mainly for your reference. Please take the actual shipment as standard.
-
Page 11: Operation Safety
About This Manual Safety Precautions Observe the following safety precautions when you are connecting or disconnecting any device. Regarding the standards of workstation regulations, do not place the server in the visual field of the user, because of the glossy front of the case. The product is non-consumer product and for profession technical person used only. -
Page 12: Battery Replacement Safety
About This Manual Use one hand, when possible, to connect or disconnect signal cables to prevent a possible shock from touching two surfaces with different electrical potentials. This product is equipped with a three-wire power cable and plug for user safety. Use the power cable with a properly grounded electrical outlet to avoid electric shock. -
Page 13: Laser Peripherals Or Devices Safety
About This Manual Laser Peripherals or Devices Safety To avoid risk of radiation exposure and/or personal injury: Do not open the enclosure of any laser peripheral or device. Laser peripherals or devices are not user serviceable. Return to manufacturer for servicing. Intended Application Uses This product was evaluated as Information Technology Equipment (ITE), which may be installed in offices, schools, computer rooms, and similar commercial type locations. -
Page 14: Regulatory And Integration Information
About This Manual Regulatory and Integration Information Regulatory Compliance Identification Numbers For the purpose of regulatory compliance certifications and identification, this server is assigned a serial number. This server serial number can be found on the product label, along with the required approval markings and information. When requesting certification information for this product, always refer to this serial number. - Page 15 About This Manual reasonably be expected to be installed in a residential environment (for example, personal computers). The FCC requires devices in both classes to bear a label indicating the interference potential of the device, as well as additional operating instructions for the user. The rating label on the device shows which class (A or B) the equipment falls into.
-
Page 16: Power Cords
About This Manual Canadian Notice (Avis Canadien) Class A Equipment Japanese Notice Taiwanese Notice Power Cords The power cord set included in the server meets the requirements for use in the country where the server was purchased. If this server is to be used in another country, purchase a power cord that is approved for use in that country. -
Page 17: Introduction
Chapter 1 Introduction Audience Assumptions Manual Organization Packing Checklist Specifications Product Features System Overview... -
Page 18: Table 1-1 Manual Introduction
Introduction 1 Introduction 1.1 Audience Assumptions This manual assumes that you are a service technician or network administrator familiar with computer hardware, data storage and network administration terminology and tasks. 1.2 Manual Organization This manual introduces the chassis along with their hardware information, and how to replace the hardware and connect the cables. -
Page 19: Specifications
Introduction 1.4 Specifications The table below is the technical specification for the server. Table 1-3 Specifications Dimensions Height: 8.75cm Width: 43.00cm Length: 69.55cm Weight Min-weight: 6.65kg ± 5% (1 x HDD) Max-weight: 31.5kg ± 5% (12 x HDDs) Temperature Operating System: +10ºC~+35ºC Non-operating System: -40ºC~+70ºC Humidity Operating System: +20%~+80%... -
Page 20: Table 1-4 Product Features
Introduction ® ® This server is configured for the motherboard that uses Intel 5000P, Intel 6321ESB and ® ® Intel 82563EB chipset. It supports dual Intel dual-core Xeon™ 5100 series processors with 667/1066/1333MHz FSB to accelerate even the most complicated server tasks. The following highlights are the main features of the server. -
Page 21: System Overview
Introduction 1.6 System Overview 1.6.1 Server Chassis Layout Figure 1-2 Server Chassis Layout Motherboard System Fan (2) Fan Duct Power Distribution Board System Fan (1) IDE Converter Board HDD Bays Riser Card Assembly Front Panel Power Supply SATA&SAS Backplane 1230B0033901... -
Page 22: Front View
Introduction 1.6.2 Front View The front view of this 2U server allows easy access to HDDs. In addition, the front panel with buttons and system LEDs is located on the front. Please refer to the front view as follows: Figure 1-3 Front View HDD 0 HDD 6 HDD 1... -
Page 23: Buttons And System Led Information
Introduction 1.6.4 Buttons and System LED Information This server is equipped with system LED indicators and buttons located on the front panel. Front panel status LEDs allow constant monitoring of basic system functions while the server is operating. These LEDs provide visual cues to the status of system fans, power supply, and system health. -
Page 24: Table 1-5 Led Information
Introduction The detailed LED information is shown below: Table 1-5 LED Information Type of LED Color Status Front View LEDs Blue On: Normal operating state Power LED − Off: System is in the off state On: Critical Fault (Two or more fan sensors fail) Blinking: Non-critical Fault (One fan Fan Fail LED... - Page 25 Introduction Type of LED Color Status On: Power supply critical event causing a shutdown; failure, OCP, OVP, Fan Failed; No AC power to this PSU only (for 1+1 configuration) Amber Blinking:(At 1Hz) Power supply warning events where the power supply continues to operate: high temperature, high power, high current, slow fan −...
-
Page 26: Motherboard
Chapter 2 Motherboard Motherboard Layout Screw Holes Processor System Memory System Configuration Jumper... -
Page 27: Figure 2-1 Connectors And Component Locations
Motherboard 2 Motherboard 2.1 Motherboard Layout The layout of the motherboard is shown below. Each connector and major component is identified by the number. Figure 2-1 Connectors and Component Locations 1230B0033901... - Page 28 Motherboard The words printed on the real motherboard to mark the processors are “CPU1” and “CPU2”. Here just for consistency, the processors are marked with “PROCESSOR1” and “PROCESSOR2” in the picture above. Rear Dual USB Port (J35) DIMM6 Socket (J23) Serial Port (J31) DIMM7 Socket (J24) UID LED (CR16)
-
Page 29: Screw Holes
Motherboard 2.2 Screw Holes The motherboard is designed with totally nine locking tab holes and two thumbscrews as the picture shows. Figure 2-2 Screws Placement Thumbscrew Locking Tab Hole Do not overly tighten the thumbscrews. Doing so may damage the motherboard. 1230B0033901... -
Page 30: Processor
Motherboard 2.3 Processor With two 771-pin LGA sockets, the system can be configured to either single or dual processors system to connect to the Northbridge chipset through the Front Side Bus (FSB) with Hyper Threading Technology. The location of the processors on the motherboard is shown below: Figure 2-3 Processor Location Processor 1 Processor 2... -
Page 31: To Remove The Heat Sink
Motherboard Reminder Before you remove or install heat sink, processor or heat sink socket, please follow the steps below: Step 1: Make sure the server is not turned on or connected to the AC power. To power off the server, see “3.1.1 Power Off”. Step 2: Remove the chassis cover. -
Page 32: To Install The Heat Sink
Motherboard 2.3.2 To install the heat sink Rotate and pull up the two levers. Figure 2-6 Pulling up the Two Levers Place the heat sink on top of the installed processor. Figure 2-7 Placing the Heat Sink on Top of the Processor Push down the levers to secure the heat sink on top of the processor. -
Page 33: To Remove The Processor
Motherboard 2.3.3 To remove the processor Unlock the load lever and lift it up. Open the load plate. Figure 2-9 Opening the Load Plate Lift the processor out of the socket. Figure 2-10 Lifting the Processor out of the Socket Close the load plate. -
Page 34: To Install The Processor
Motherboard Place the PnP cap onto the load plate. Figure 2-12 Placing on the PnP Cap 2.3.4 To install the processor Reverse the steps above to install the processor. However, when inserting the processor into the socket, make sure that the golden corner on the processor is pointed toward the socket as picture shows: Figure 2-13 Pointing the Golden Corner toward the Socket When the processor is in place, press it firmly on the socket while you push... -
Page 35: To Remove The Heat Sink Socket
Motherboard 2.3.5 To remove the heat sink socket Release the six screws from bottom of the motherboard. Figure 2-14 Releasing the Screws Lift the heat sink socket up from the motherboard. Figure 2-15 Lifting up the Heat Sink Socket 2.3.6 To install the heat sink socket Reverse the steps above to install the heat sink socket. -
Page 36: System Memory
Motherboard 2.4 System Memory The location of the DIMM sockets on the motherboard is shown below: Figure 2-17 System Memory Location Reminder Before you remove or install any DIMMs, please follow the steps below: Step 1: Make sure the server is not turned on or connected to the AC power. To power off the server, see “3.1.1 Power Off”. -
Page 37: To Remove A Dimm
Motherboard 2.4.1 To remove a DIMM Unlock a DIMM socket by pressing the retaining clips outward. This action releases the module and partially lifts it out of the socket. Lift out the DIMM. Figure 2-18 Lifting the DIMM out of the Socket 2.4.2 To install a DIMM Unlock a DIMM socket by pressing the retaining clips outward. -
Page 38: System Configuration Jumper
Motherboard DIMMs fit in only one direction. DO NOT force a DIMM into the socket to avoid damaging the DIMM. 2.5 System Configuration Jumper The location of system configuration jumper on the motherboard is shown below: Figure 2-21 System Configuration Jumper Table 2-1 System Configuration Jumper Function Jumper Function... -
Page 39: Hardware Operations
Chapter 3 Hardware Operations Before You Start Chassis Cover Motherboard Power Distribution Board Power Supply IDE Converter Board System Fans SATA&SAS Backplane SATA&SAS HDDs Optional Riser Cards Daughter Card Fan Duct... -
Page 40: Power Off
Hardware Operations 3 Hardware Operations This chapter describes the hardware setup procedures that you have to perform when replacing system components. It also gives detailed information on the internal components and how to replace them. In addition, this server is also designed with the toolless feature, which permits to remove or install the components without any tools. -
Page 41: Chassis Cover
Hardware Operations To press the button: Press the power button to toggle the server to hibernation. The power LED in blue turns off. Figure 3-1 Pressing the Power Button To unplug the power cords: First unplug the power cords from the AC outlet and then from the server. Figure 3-2 Unplugging the Power Cords 3.2 Chassis Cover The server is a 2U form factor designed for easy assembly and disassembly, making the... -
Page 42: Figure 3-3 Removing The Top Cover
Hardware Operations To remove the chassis cover: Loosen the screw on top of the cover. Press the button as the arrow shows. Meanwhile slide the cover horizontally to the back. Figure 3-3 Removing the Top Cover To install the chassis cover: Slide the top cover horizontally to the front until it is closed. -
Page 43: Motherboard
Hardware Operations 3.3 Motherboard This section explains how to remove the motherboard from the chassis. For the operation of main components on the motherboard. The location of the motherboard on the server chassis is shown below: Figure 3-6 Motherboard Location Reminder Before you remove or install the motherboard, please follow the steps below: Step 1: Make sure the server is not turned on or connected to the AC power. -
Page 44: Figure 3-7 Removing The Motherboard
Hardware Operations To remove the motherboard: 1. Loosen the two thumbscrews 2. Release the motherboard from the chassis by unlocking the nine locking tabs along the direction of the arrow and lift out the motherboard from the chassis. Figure 3-7 Removing the Motherboard To install the motherboard: Reverse the steps above to install the motherboard. -
Page 45: Power Distribution Board
Hardware Operations 3.4 Power Distribution Board All the power cables come out from the power distribution board. The location of the power distribution board on the server chassis is shown below: Figure 3-8 Power Distribution Board Location Reminder Before you remove or install the power distribution board, please follow the steps below: Step 1: Make sure the server is not turned on or connected to the AC power. -
Page 46: Power Supplies
Hardware Operations To install the power distribution board: Place the power distribution board along the direction of the arrow. Push it down firmly. Make sure that the power distribution board is connected to the power supply connector on the power supply. Figure 3-10 Installing the Power Distribution Board 3.5 Power Supplies This server is designed with two 700W power supplies. -
Page 47: Figure 3-12 Removing The Power Supply
Hardware Operations To remove the power supply: Press the retaining clip on the right side of the power supply along the direction of the arrow. At the same time, pull out the power supply by using its handle. (The power supply takes considerable force to remove.) Figure 3-12 Removing the Power Supply To install the power supply:... -
Page 48: Ide Converter Board
Hardware Operations 3.6 IDE Converter Board This server is designed with an IDE converter board, which connects the front panel cable and the front IDE cable. The IDE converter board is shown below: Figure 3-14 IDE Converter Board Front Panel Connector IDE Flash Card Connector Front Panel IDE Connector The location of the IDE converter board on the server chassis is shown below:... -
Page 49: Figure 3-16 Removing The Ide Flash Card
Hardware Operations Before removing the IDE converter board, the IDE flash card attached on it should be removed first. To remove the IDE flash card: Lift up the IDE flash card to release it from the IDE converter board. Figure 3-16 Removing the IDE Flash Card To remove the IDE converter board: Unscrew the IDE converter board. -
Page 50: System Fan Assemblies
Hardware Operations 3.7 System Fan Assemblies This server contains two groups of hot-swappable fans seated in the system fan cages, which are located inside the chassis. These two groups of system fans respectively locate in system fan cage (1) and system fan cage (2). The system fan cage (1) supports three sets of system fans and the system fan cage (2) supports two system fans. -
Page 51: Figure 3-20 Lifting The System Fan Out Of The System Fan Cage (1)
Hardware Operations To remove the system fan in the system fan cage (1): Pull up the locking handle on the system fan. Lift the system fan out of the system fan cage housing. Figure 3-20 Lifting the System Fan out of the System Fan Cage (1) To install the system fan in the system fan cage (1): Reverse the steps above to install the system fans. -
Page 52: Figure 3-22 Unlocking The System Fan Cage
Hardware Operations To remove the system fan cage: Lift the release tab. Figure 3-22 Unlocking the System Fan Cage Push the system fan cage along the direction of the arrow to unlock it from the chassis and lift the system fan cage out of the chassis. Figure 3-23 Removing the System Fan Cage To install the system fan cage: Position the system fan cage into the chassis by placing the holes of the system fan cage... -
Page 53: Sata&Sas Backplane
Hardware Operations 3.8 SATA&SAS Backplane The shape of SATA&SAS Backplane with expander chip for 12x3.5” HDDs is shown below: Figure 3-25 Front & Back View of SATA&SAS Backplane SATA&SAS HDD Connector 0 SATA&SAS HDD Connector 9 SATA&SAS HDD Connector 1 SATA&SAS HDD Connector 10 SATA&SAS HDD Connector 2 SATA&SAS HDD Connector 11... -
Page 54: Figure 3-26 Backplane Location
Hardware Operations The location of the backplane is shown below: Figure 3-26 Backplane Location Reminder Before you remove or install the SATA&SAS backplane, please follow the steps below: Step 1: Make sure the server is not turned on or connected to the AC power. To power off the server, see “3.1.1 Power Off”. -
Page 55: Figure 3-28 Removing The Backplane
Hardware Operations Press the release tab on the backplane bracket. Remove the backplane along the direction of the arrow. Figure 3-28 Removing the Backplane To install the backplane: Put the backplane at the backplane bracket with the locking tabs going through the holes on the backplane, and push the backplane along the direction of the arrow until it is locked by the locking tab. -
Page 56: Sata&Sas Hdds
Hardware Operations 3.9 SATA&SAS HDDs The server can support twelve 3.5” SATA&SAS HDDs The location of SATA&SAS HDD assemblies on the server chassis is shown below: Figure 3-31 Location of HDD Assemblies Take note of the drive tray orientation before sliding it out. The tray will not fit back into the bay if inserted incorrectly. -
Page 57: Figure 3-33 Sliding The Hdd Assembly
Hardware Operations Slide the HDD assembly out of the HDD bay. Figure 3-33 Sliding the HDD Assembly To install the HDD: Place the HDD to the HDD tray. Figure 3-34 Placing the HDD to the HDD tray Secure the HDD to the HDD tray with four screws as shown. Figure 3-35 Securing HDD to the HDD Tray 1230B0033901 3-18... -
Page 58: Optional Riser Cards
Hardware Operations Carefully insert the HDD assembly into the bay with the lever lifted until it completely enters the bay. Figure 3-36 Inserting the HDD Assembly Push the lever back in place. Turn the lock on the lever clockwise to secure the HDD. Figure 3-37 Pushing the Lever Back in Place Make sure that the HDD is connected to the HDD connector on the backplane. -
Page 59: Figure 3-38 Pci-X/Pci-E Riser Card
Hardware Operations The PCI-X/PCI-E riser card is shown below: Figure 3-38 PCI-X/PCI-E Riser Card Golden Fingers PCI-E x8 Expansion Slots with x4 Speed PCI-X Expansion Slot The PCI-E riser card is shown below: Figure 3-39 PCI-E Riser Card Golden Fingers PCI-E x8 Expansion Slots with x4 Speed The two riser cards share many similarities during the removal and installation procedures. -
Page 60: Figure 3-40 Riser Card Assembly Location
Hardware Operations The location of riser card assembly is shown below. Figure 3-40 Riser Card Assembly Location Reminder Before you remove or install the riser card, please follow the steps below: Step 1: Make sure the server is not turned on or connected to the AC power. To power off the server, see “3.1.1 Power Off”. -
Page 61: Figure 3-42 Removing The Expansion Card
Hardware Operations Open the lock along the direction of the arrow. Pull out the expansion card. Install the slot cover. Figure 3-42 Removing the Expansion Card Press the locking tab. Push the riser card along the direction of the arrow. Figure 3-43 Releasing the Riser Card Lift the riser card along the direction of the arrow. -
Page 62: Daughter Card
Hardware Operations 3.11 Daughter Card This server provides SAS RAID daughter card with two channels. It is designed to provide extra HDD storage capability. This section provides the location, removal and installation steps of the daughter card. SAS RAID Daughter Card supports two SAS channels with 256MB embedded memory. -
Page 63: Figure 3-47 Removing The Daughter Card Assembly
Hardware Operations Reminder Before you remove or install the daughter card, daughter-card latch and I-button, please follow the steps below: Step 1: Make sure the server is not turned on or connected to the AC power. To power off the server, see “3.1.1 Power Off”. Step 2: Remove the chassis cover. -
Page 64: Figure 3-49 Connecting The Sas Jbod Cable
Hardware Operations To connect the daughter card with the JBOD: Connect on end of the SAS JBOD cable to the SATA&SAS connector on the daughter card. Connect the other end of the SAS JBOD cable to the SATA&SAS connector on the JBOD. Figure 3-49 Connecting the SAS JBOD Cable When installing the SAS RAID daughter card with two channels (LSI1078 SAS daughter card), a daughter-card latch is necessary to fix it tightly. -
Page 65: Figure 3-51 Installing The Daughter-Card Latch
Hardware Operations To install the daughter-card latch: Make the daughter-card latch parallel to the daughter card surface, point the hole toward the plastic pole, and then carefully insert it. Figure 3-51 Installing the Daughter-card Latch When installing the SAS RAID daughter card with two channels (LSI1078 SAS daughter card), an I-button is necessary to be installed. -
Page 66: Fan Duct
Hardware Operations To install the I-button: Put the I-button into the socket. Figure 3-54 Installing the I-button 3.12 Fan Duct The location of the fan duct is shown below: Figure 3-55 Fan Duct Location Reminder Before you remove or install the fan duct, please follow the steps below: Step 1: Make sure the server is not turned on or connected to the AC power. -
Page 67: Figure 3-56 Removing The Fan Duct
Hardware Operations To remove the fan duct: Lift the fan duct along the direction of the arrow shown in the picture below. Figure 3-56 Removing the Fan Duct To install the fan duct: Reverse the step above to install the fan duct. 1230B0033901 3-28... -
Page 68: Cable Connections
Chapter 4 Cable Connections Connectors and Pin 1 Locations Cable Connections Power Supply Power On... -
Page 69: Cable Connections
Cable Connections 4 Cable Connections This chapter provides the details of all necessary cables connection for 2U server. 4.1 Connectors and Pin 1 Locations The figure below shows the different locations of necessary connectors and their pin 1 locations, which can make you easily connect the cables. Figure 4-1 Locations of Connectors and Pin 1 1230B0033901... -
Page 70: Jbod Cable
Cable Connections 4.2 Cable Connections You can get a clear picture on how to connect the cables from the figures below. Before connecting cables you must make sure there are no bent pins existing because it affects signal transmission. With the pin 1 location and foolproof feature, you can link these cables correctly and conveniently. -
Page 71: Front Panel Cable
Cable Connections 4.2.2 Front Panel Cable Front Panel IDE Cable Connect one end of the front panel IDE cable to the front panel IDE connector on the motherboard. Connect the other end of the front panel IDE cable to the corresponding connectors on the IDE converter board. -
Page 72: Figure 4-5 Connecting The Front Panel Cable
Cable Connections Connect one end of the front panel cable to the front panel connector on the front panel. Connect the other end of the front panel cable to the corresponding connectors on the IDE converter board. Figure 4-5 Connecting the Front Panel Cable To remove the front panel cable Remove the two screws on the side of the chassis. -
Page 73: Figure 4-8 Releasing The Buttons
Cable Connections Pull the clips outward to release the buttons. Figure 4-8 Releasing the Buttons Pull out the front panel cable. Figure 4-9 Pulling out the Front Panel Cable To install the front panel cable Reverse the steps above to install the front panel cable. 1230B0033901... -
Page 74: Power Cables
Cable Connections 4.2.3 Power Cables Main Power Cable Connect the 24-pin main power cable from the power supply to the main power connector on the motherboard. Figure 4-10 Connecting the Main Power Cable Processor Power Cable Connect the 8-pin processor power cable from the power supply to the processor power connector on the motherboard. -
Page 75: Sata&Sas Hdd Cable
Cable Connections 4.2.4 SATA&SAS HDD Cable Connect one end of the SATA&SAS HDD cable to the SATA&SAS connector on the SAS daughter card. Connect the other end of the SATA&SAS HDD cable to the backplane SATA&SAS connector on the backplane. Figure 4-12 Connecting the SATA&SAS HDD Cable 4.2.5 Backplane Power Cables 6-pin Backplane Power Cable... -
Page 76: Power Supply I
Cable Connections 4-pin Backplane Power Cable Connect the 4-pin backplane power cable from the power supply to the power connector on the backplane. Figure 4-14 Connecting the 4-pin Backplane Power Cable 4.2.6 Power Supply I C Cable Connect the 5-pin power supply I C cable from the power supply to the power supply I connector on the motherboard. -
Page 77: System Fan Cables
Cable Connections 4.2.7 System Fan Cables System Fan Cable For the connectors of system fan cage (1) and system fan cage (2), please refer to the figure below. Figure 4-16 System Fan Connector Locations Connector of System Fan Cage (2) Connector of System Fan Cage (1) Connect one end of the fan cable to the fan connector on the system fan cage (2). -
Page 78: Figure 4-18 Connecting The System Fan Power/Fan Tach Cable
Cable Connections System Fan Power/Fan Tach Cable Connect one end of the fan power/fan tach cable to the fan power connector on the motherboard. Connect the other end of the fan power/fan tach cable to the fan power connector on the system fan cage (1). -
Page 79: Chassis Intrusion Cable
Cable Connections 4.2.8 Chassis Intrusion Cable Connect one end of the chassis intrusion cable to the chassis intrusion connector on the motherboard. Connect the other end of the chassis cable to power supply cage. Figure 4-19 Connecting the Chassis Intrusion Cable 4.3 Power Supply The system comes with two 700W power supplies with universal AC input that includes PFC and SSI-compliant output cables and connectors. -
Page 80: Power On
Cable Connections 4.4 Power On Before you turn on the server, make sure that you have completed the basic system connections. Follow these steps when starting the server. Step 1: Monitor Connection Connect a monitor by plugging a video cable to the VGA port at the back of the server. Step 2: PS/2 Keyboard Connection Plug the keyboard cable into the keyboard port on the back of the server. -
Page 81: Figure 4-22 Powering On
Cable Connections Step 6: Power on Press the power button on the front panel to toggle the server to power on. The power turns blue. Figure 4-22 Powering On Power Button Power LED 1230B0033901 4-13... - Page 82 Appendix China RoHS Regulations...
-
Page 83: Appendix China Rohs Regulations
Appendix Appendix China RoHS Regulations Appendix Figure I China RoHS Regulations 1230B0033901...
