- Page 1 Breeze FPV Controller USER MANUAL...
- Page 2 INTRODUCTION Breeze FPV Controller allows users to pilot their Breeze in a new way. The portable Game Controller is connected to the smart device via Bluetooth, and enables users to control the Breeze accurately with physical joysticks and buttons. It is compatible with the Breeze Cam application (Breeze Cam is a remote control application for Breeze) on iOS devices (above iOS 8.0...
- Page 3 06 Gimbal Tilt Trim 07 Drone Yaw Trim 08 Altitude/Throttle Control 09 Yaw/Rudder Control 10 Power Button 11 Roll/Aileron Control 12 Pitch/Elevator Control 13 B: Parameters Hidden 14 Y: GO HOME 15 Start Button: Press the Start Button for 3 seconds to take off Press the Start Button to land/cancel landing during flight 16 Android Mode indicator light 17 Apple Mode indicator light...
-
Page 4: Specifications
SPECIFICATIONS Working Platforms: iOS/Android Charging Current: 1A-2A Working Temperatures: -20~65 Working Distance: Approx.7M Working Humidity: 20~80% Battery Capacity: 600mA Connection Types: Bluetooth Product Size: 160 x 104 x59mm Charging Voltage: 3.7~5.2V Net Weight: 189g Charging Time: 2-3H PREPARATIONS 1. CHARGING THE BATTERY 1. - Page 5 Battery Warnings: To charge the LiPo battery, you must only use the included charger. Do not over-discharge the LiPo battery. If at any time the LiPo battery begins to balloon or swell, discontinue charging or discharging immediately. Always terminate all processes if the battery/charger malfunctions. Store the LiPo battery at room temperature and in a dry area for best results.
- Page 6 3. DOWNLOADING THE BREEZE CAM APPLICATION Download the Breeze Cam application on your smart device, available for free on the App Store and Google Play Store.
- Page 7 4. BREEZE CONNECTION Power on your Breeze on a flat and stable surface and wait for it to complete initialization. When the LED indicator blinks blue WELCOME TO YOUR BREEZE rapidly, Breeze has entered the “Wi-Fi” bind mode. TO GET STARTED: Connect your device to Breeze via Wi-Fi.
- Page 8 Breeze, people and surroundings. Step 3) Slide the “SLIDE TO PROCEED” bar to confirm that you have entered the FPV Mode. Note: In this mode, you are required to have the whole set of the Breeze FPV Controller. SLIDE TO PROCEED...
- Page 9 ] indicator light keeps on. ] indicator light keeps on. NOTICE: In this mode, you can use the Game Controller to pilot your Breeze instead of the on-screen buttons within the Breeze Cam app. Installation Method for the FPV Goggles...
- Page 10 Tap "Experience Now" icon, and mount your Mobile Phone to the Game Controller Holder. Press R2 to view all button descriptions. NOTICE: In this mode, you can use the Game Controller to pilot Experience Now your Breeze instead of the on-screen buttons within the Breeze Cam app.
- Page 11 Installation Method for the Game Controller Holder: Step 1) Press the buckle of the holder downward to unlock. Step 2) Pull up the Clamp Retainer. Step 3) Attach Game Controller to the clip then pull back the clamp retainer. Step 4) Button up the buckle. Step 5) Open the seat of the holder and mount your smart device.
- Page 12 DISCLAIMER Yuneec Electric Aviation cannot be held liable for any damage, injury or for use of the product in violation with legal regulations, especially in the following circumstances: Damage and/or injury as well violation of legal regulations resulting from a failure to comply with the operating instructions or the instructions at www.yuneec.com, product information, user manual and other legally binding information.
- Page 13 Damage and/or injury brought about through a violation of the legal regulations for operating the model, in unsuitable weather conditions, e.g. rain,wind, snow, hail, storms, hurricanes etc. Damage and/or injury as well as violation of legal regulations caused by force majeure, e.g.collision, fire, explosion, flooding, tsunami, landslide, avalanche, earthquake or other forces of nature.
- Page 14 FCC STATEMENT This equipment has been tested and found to comply with the limits for Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interfer- ence to radio communications.
- Page 15 —Consult the dealer or an experienced radio/TV technician for help. CAUTION: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. RF EXPOSURE WARNING This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
- Page 16 COLLECTION AND PROCESSING OF DATA Yuneec may collect navigation information such as GPS data to help improve our products. We may also collect Depth Map information and Infrared Image information from your drone delivered to our service center for repair and maintenance service or any other service.
- Page 17 CUSTOMER SERVICE Manufacturer: Production Address: Yuneec International (China) Co., Ltd. East Zhengwei Road No.388, Jinxi Town, Kunshan City, Jiangsu Province Distributor: CN: Youyu (Shanghai) Digital Technology Co.,Ltd. Address: B 15F, 461 HongCao Road, CaoHeJing Software Building XuHui District, Shanghai, China Tel: +86 400 8207 506 US: Yuneec USA Inc.
- Page 18 Any information below might be changed due to the software update. For the latest documents, please check the official website.
