Glowworm SAXONY 2 BBU FIRE FRONT Instructions For Use Installation And Servicing

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Installation and Servicing

BBU Fire Front

G.C. No. 37 047 11

For use with a specially designed

Glow-worm Back Boiler Unit only

This is a Cat I

Reference in these instructions to British Standards and Statutory

Regulations/Requirements apply only to the United Kingdom.

For Ireland the rules in force must be used.

These instructions consist of three parts, User, Installation and Servicing Instructions, which includes the Guarantee Registration

Card. The instructions are an integral part of the appliance and must, to comply with the current issue of the Gas Safety

(Installation and Use) Regulations, be handed to the user on completion of the installation.

Thank you for installing a new Glow-worm appliance in your home.

Glow-worm appliances' are manufactured to the very highest standard so we are pleased

In the center pages are to be found your Guarantee Registration Card, which we recommend you complete and

If this card is missing you can obtain a copy or record your registration by telephoning the Heatcall Customer

Our Guarantee gives you peace of mind plus valuable protection against breakdown by covering the cost of:

All replacement parts

All labour charges

All call-out charges

One Contact Local Service

Supplied By www.heating spares.co Tel. 0161 620 6677

Instructions for Use

To b e l e f t w i t h t h e u s e r

BS 6332

BS 5258

Appliance

Guarantee Registration

to offer our customers' a Comprehensive First Year Guarantee.

return as soon as possible.

Service number 01773 828100.

FOR 1ST YEAR GUARANTEE PROTECTION

CALL 0181 380 2555

Customer Services:

Tel: (01773) 828100

Fax: (01773) 828070

Hepworth Heating Ltd.,

Nottingham Road, Belper, Derbyshire. DE56 1JT

General/Sales enquiries:

Tel: (01773) 824141 Fax: (01773) 820569

221648B. 02. 00

Table of Contents

Need help?

Do you have a question about the SAXONY 2 BBU FIRE FRONT and is the answer not in the manual?

Questions and answers

Summary of Contents for Glowworm SAXONY 2 BBU FIRE FRONT

Page 1 221648B. 02. 00 Instructions for Use Installation and Servicing To b e l e f t w i t h t h e u s e r BBU Fire Front G.C. No. 37 047 11 For use with a specially designed Glow-worm Back Boiler Unit only BS 6332 BS 5258...
