mr. steam W216 Installation, Operation And Maintenance Manual

Broadway collection electric towel warmers
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Installation, Operation and Maintenance Manual
Broadway Collection Electric Towel Warmers
.
mr
_______________________________________________
Model
_______________________________________________
Serial No.
W216C
W219C
IMPORTANT NOTE: As you follow these instructions, you will notice warning and caution symbols. This
blocked information is important for the safe and efficient installation and operation of this Towel Warmer.
These are types of potential hazards that may occur during this installation and operation:
!
WA R NI NG
states a hazard
may cause serious injury or death if
precautions are not followed.
Models: W216, W219, W228, W236, W248
steam
W228C
W236C
!
C AUT I O N
signals a situation where
minor injury or product damage may
occur if you do not follow instructions.
Feel Good Inc.
®
__________________

TABLE OF CONTENTS

General Information ........................ 2
Specifications .................................. 2
Wall Preparation .............................. 3
Mounting Dimensions ..................... 3
Junction Box Connection ............. 6
General......................................... 7
Using Essential Oils ......................... 8
W248C
Warranty .......................................... 8
IMPORTANT NOTE: This highlights
information that is especially relevant to a
problem-free installation.
100425
10.13
pur
rev

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W216 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for mr. steam W216

Summary of Contents for mr. steam W216

  • Page 1: Table Of Contents

    Installation, Operation and Maintenance Manual Broadway Collection Electric Towel Warmers Models: W216, W219, W228, W236, W248 steam Feel Good Inc. ® TABLE OF CONTENTS __________________ _______________________________________________ General Information ......2 Model Specifications ........2 _______________________________________________ Wall Preparation ......3 Serial No.

  • Page 2: General Information

    steam ® Broadway Collection Towel Warmers Installation, Operation & Maintenance Instructions _______________________________________________________________ HOMEOWNER: INSTALLER: _____________________________________________________ __________________________________________________ R EAD THIS ENTIRE INSTRUCTION MANUAL THOROUGHLY THANK YOU for selecting Mr.Steam Towel Warmer, the BEFORE BEGINNING INSTALLATION. LEAVE THESE perfect addition to bathrooms, family spas, and exercise INSTRUCTIONS WITH HOMEOWNER.

  • Page 3: Wall Preparation

    steam ® Broadway Collection Towel Warmers Installation, Operation & Maintenance Instructions _______________________________________________________________ WALL PREPARATION CAUTION • DO NOT mount the Towel Warmer without provid- ing structurally secure upper and lower headers as shown. Finished • DO NOT mount the Towel Warmer directly to wall surface sheet rock or any other non-structural surface.

  • Page 4: Installation (Brass Brackets)

    steam ® Broadway Collection Towel Warmers Installation, Operation & Maintenance Instructions _______________________________________________________________ IMPORTANT: INSTALLATION BRASS MOUNTING BRACkETS LOOSENING END CAPS WILL CAUSE INTERNAL LIQUID TO ESCAPE AND CAUSE PRODUCT DAMAGE. BOX CONTENTS: Bracket • Towel Warmer • (4) Threaded Knobs Bracket •...

  • Page 5: Installation (Plastic Brackets)

    steam ® Broadway Collection Towel Warmers Installation, Operation & Maintenance Instructions _______________________________________________________________ INSTALLATION PLASTIC MOUNTING BRACkETS IMPORTANT: LOOSENING END CAPS WILL CAUSE INTERNAL LIQUID TO ESCAPE AND CAUSE PRODUCT DAMAGE. BOX CONTENTS: • Towel Warmer • (4) Bracket Assemblies • (4) Bracket Screws •...

  • Page 6: Electrical Connections

    steam ® Broadway Collection Towel Warmers Installation, Operation & Maintenance Instructions _______________________________________________________________ ELECTRICAL CONNECTIONS 1. Assemble the BX cable connector BX Cable* to the wiring box escutcheon as (or greenfield) shown. WA RNING TO PREVENT SHOCk HAZARD, Wiring Box THE ELECTRICITY MUST BE TURNED OFF AT THE Escutcheon NOTE: NM (non-metallic) cable, MAIN PANEL BEFORE ANY WIRING...

  • Page 7: General

    Towel Warmer surface may continue to be hot for a period of time after it has been turned off. White faceplate is provided standard. Field Installed Wall Switch or Mr. Steam Digital Programmable Timer PN: 103588DIG Thermal Fuse Indicator Light...

  • Page 8: Installing Optional Accessories

    Installation, Operation & Maintenance Instructions _______________________________________________________________ INSTALLING OPTIONAL BROADWAY COLLECTION ACCESSORIES IMPORTANT NOTE: 1 bar and 3 bar shelves are not compatible with model W216 Mr Steam recommends installing accessories after a towel warmer is firmly secured to a wall.
