Summary of Contents for Fritonex PowerTube QuickZap
- Page 1 Medical certification EN ISO 13485 ® Instruction manual English FRITONEX AG, Breite 9, CH-3636 Forst (Switzerland)
-
Page 3: Table Of Contents
Instruction manual This instruction manual is considered an integral part of the device. It shall be kept within reach at all times. Exact compliance with these instruc- tions is essential for the correct handling of the device as well as for the safety of patient and user. -
Page 4: Illustration Of The Device
1. Illustration of the device Plug connection for cable to handhold Therapy head Insulation Handhold with cable can be used instead of therapy head Control panel and display Gold- / Silver-plated casing with integrated electronics Cover of battery compartment. Use a coin to open. Cable with plug Requires one IEC 6LR61 9-volt for connection to... -
Page 5: Control Panel With Functions
2. Control panel with functions Button: TIME Programme sequence (STEP 1 - 3) Course of therapy in minutes (1 - 7 min. per STEP) Battery indicator is flashing: Stop therapy and replace battery Button: I / GO Turning on the device (push button briefly) Select number of minutes (1 - 7 min.) -
Page 6: Description Of The Device
3. Description of the device Intended use The PowerTube ® QuickZap ® is intended for the electronic stimulation of nerves. It is used for self-treatment of symptoms and pain. Its application does not replace treatment or instructions from a doctor, but has a positive influence on symptoms and pain. -
Page 7: Battery And Battery Compartment
Every device is tested by the manufacturer in terms of functionality and safety before being shipped. Please observe the following to ensure that the device continues to operate properly following transport and installation: The operator should only start using the device after carrying out a function test (see chapter 12). -
Page 8: Specifications
6. Specifications • Time of therapy in minutes Display • 7 light-emitting diodes • Therapy steps 1 - 3 • Exchange light-emitting diode battery Intermittent tone: Error messages handholds or contact areas are not applied properly Continuous tone: handholds have short circuited Battery IEC 6LR61 9-volt block battery Output voltage... -
Page 9: Handling
7. Handling Turning on the device: push I / GO button briefly. Set appropriate therapy time per step by means of TIME button. Start with 1 minute per step, i. e. the complete treatment time is 3 minutes. Increase the time with every treatment by 1 minute per step. -
Page 10: Indications
Step 2 Treatment of abdominal area Please ensure good body contact. Moisten skin with water if necessary. Consume large quantities of water before and after the treatment. Indications • Pain relief Contraindications • Pregnancy, cardiac pacemaker, open wounds and fresh scars. -
Page 11: Care, Maintenance And Storage
• ® ® PowerTube QuickZap may only be operated with the accessories included in the range of delievery. • Fritonex AG is only responsible for the reliability and safety ® ® of PowerTube QuickZap • ® ® PowerTube QuickZap... -
Page 12: Errors And Malfunctions, Function Test
Errors and malfunctions, function test • Discharge of the battery is displayed on a battery indicator LED. • After being turned on, PowerTube ® QuickZap ® automatical- ly runs a battery test. • An acoustic warning signal during therapy indicates that the electrodes have not been properly applied. -
Page 13: Safety Inspection
Additional claims, particularly claims for damages, are excluded. • The repair may only be carried out by FRITONEX AG, one of its agencies or authorised specialist dealers. The guarantee shall become void if improper modifications or repairs are carried out. -
Page 14: Conformity Declaration Ce 0482
Registration no. 7288DE414150310 Conformity of the quality MEDCERT GmbH management system is Pilatuspool 2 acknowledged and moni- D-20355 Hamburg tored by Deutschland CH-Forst, 23-03-2015 Martin Frischknecht (CEO FRITONEX AG) The period of validity of 23. Januar 2020 the certificate English... - Page 16 Instruction manual ® ® PowerTube QuickZap © 2015 FRITONEX AG. All rights reserved. All trade names are registered trademarks of FRITONEX AG Breite 9 CH-3636 Forst Switzerland Edition 2015-03-23 Printed in switzerland...
