INSTRUCTION MANUAL BROADBAND POWER AMPLIFIER MODEL PA-1000 10 MHz – 1 GHz... - Page 2 INSTRUCTION MANUAL THIS INSTRUCTION MANUAL AND ITS ASSOCIATED INFORMATION PROPRIETARY. UNAUTHORIZED REPRODUCTION IS FORBIDDEN. 1995 ELECTRO-METRICS CORP. BROADBAND POWER AMPLIFIER ELECTRO-METRICS MODEL PA-1000 10 MHz-1 GHz SERIAL NO: N/A ELECTRO-METRICS CORPORATION 231 Enterprise Road, Johnstown, New York 12095 Phone: (518) 762-2600 Fax: (518) 762-2812 EMAIL: info@emihq.com...
-
Page 3: Warranty
ELECTRO-METRICS AIT-SUS WARRANTY This Model PA-1000 Broadband Preamplifier is warranted for a period of 12 months (USA only) from date of shipment against defective materials and workmanship. This warranty is limited to the repair of or replacement of defective parts and is void if unauthorized repair or modification is attempted. - Page 4 ELECTRO-METRICS PA-1000 APPENDIX A PA-1000 ACCESSORIES A-1.0 Standard Accessories The following accessories are included as standard with each PA-1000. Power Cord. (PA-A-1)
- Page 5 MODEL PA-1000 BROADBAND POWER AMPLIFIER 1.0 Introduction The Electro-Metrics Model PA-1000 Broadband Power Amplifier is a general purpose signal amplifier that can be used in susceptibility tests, shielding effectiveness tests, insertion loss measurements, plus numerous other applications where signal amplification is required.
- Page 6 Verify that the Power Source Selector setting corresponds to the AC power source being used. Operation on "220" VAC with the module set for "110" VAC can cause extensive circuit damage. 3.3 Fuse Specifications The PA-1000 uses the following fuses: 115 VAC operation: 1.0 AMP 3AG SLO-BLO. (PA1000-2)
- Page 7 4.0 Description Front/Rear Panel 4.1 Front Panel POWER ON INDICATOR Type: LED. Color: Amber. Function: when lighted, indicates that the PA-1000 is turned "ON". POWER SWITCH Type: Two position toggle switch. Function: Used to place the unit in operation. INPUT/OUTPUT CONNECTORS Type: BNC.
- Page 8 If the PA-1000 is being used as an antenna output amplifier, there is the possibility of damage being caused by electrostatic discharges (ESD). This situation may occur since most antennas have a center conductor with a shield ground and not an actual earth ground.
- Page 9 ELECTRO-METRICS PA-1000 BB POWER AMPLIFUER The PA-1000 can also be used as a post-amplifier in combination with the BPA-1000 Broadband Amplifier for special broadband, high dynamic range measurements. The two units combined provide a third-order spurious free dynamic range (SFDR) of 47 dB (Bandwidth: >990 MHz, Overall Noise Figure: 6.0 dB, Gain: 43 dB).
- Page 10 ELECTRO-METRICS PA-1000 BB POWER AMPLIFUER FIGURE 1 GAIN LEVEL CHART PAGE 6A (PA1000-6)
