- Page 1 Operations Manual PCI bus multi-8255/8254 adapter PCI BUS MULTIPLE 8255/8254 ADAPTER OPERATION MANUAL Update 02/04 DECISION DECISION Computer International Co., Ltd. 頁碼DECISION Computer International 頁 碼...
-
Page 2: Table Of Contents
Operations Manual PCI bus multi-8255/8254 adapter CHAPTERS 1. Introduction……………………………………….. 2. Unpacking Information…………………………… 3. Hardware Installation…………….……………….. 4. Hardware Configuration…………………………… 5. DII Device Driver…………..……………………… 6. Diagnostic…………………………………………. APPENDICES A. Warranty Information ………………………….. 18 B. Data Sheet………………………………………… 21 頁 頁碼DECISION Computer International 碼... -
Page 3: Chapters
CHAPTER 1 INTRODUCTION INTRODUCTION The PCI bus multi-8255/8254 adapter is a 32 bits PCI bus adapter with Plug and Play (PnP) features, it is a programmable I/O interface for PC/486, Pentium or compatible computers. The PnP features let hardware configuration for IRQ and I/O address is detected by BIOS automatically, you don’t need set... - Page 4 Operations Manual PCI bus multi-8255/8254 adapter The features of the PCI bus multi- 8255 /8254 adapter are: 32 bits PCI bus with Plug and Play (PnP) features. Programmable I/O control functions. Up to 192 I/O lines.
-
Page 5: Unpacking Information
Operations Manual PCI bus multi-8255/8254 adapter CHAPTER 2 UNPACKING INFORMATION UNPACKING INFORMATION Check that your PCI bus multi- 8255 /8254 package includes the following items: PCI bus multi-8255/8254 adapter. Demo Program. Data Capture Software Manual with CD. -
Page 6: Hardware Installation
CHAPTER 3 HARDWARE INSTALLATION HARDWARE INSTALLATION Your PCI bus multi-8255/8254 adapter is designed to be inserted in any available PCI slot in your PC/486, Pentium or compatibles. In order to gain access to the expansion slots, follow the steps listed below: 1. -
Page 7: Hardware Configuration
Operations Manual PCI bus multi-8255/8254 adapter CHAPTER 4 HARDWARE CONFIGURATION HARDWARE CONFIGURATION 4.1 I/O Port Address Base + 0 : Port 1A input/output buffer. Base + 1 : Port 1B input/output buffer. Base + 2 : Port 1C input/output buffer. - Page 8 Operations Manual PCI bus multi-8255/8254 adapter Base + 26 : Port 7C input/output buffer. Base + 27 : Port 7 control register. Base + 28 : Port 8A input/output buffer. Base + 29 : Port 8B input/output buffer. Base + 30 : Port 8C input/output buffer.
- Page 9 Operations Manual PCI bus multi-8255/8254 adapter b. manual mode Set card number by card identifier switch, the PCI BIOS will assign pre-allocated I/O address to each adapter. Please set different card number to each adapter (do not duplicate card number setting).
- Page 10 Operations Manual PCI bus multi-8255/8254 adapter 頁 頁碼DECISION Computer International 碼...
-
Page 11: Pin Assignments
Operations Manual PCI bus multi-8255/8254 adapter 4.3 Pin Assignments The signals are assigned in the IDC-40 and IDC-50 connectors. The assignment for the pin-connentor on the card, the flat-cable and the DB-50 is different! When you like to connect by a flat-cable direct to the card, please use assignment A for the flatcable. - Page 12 Operations Manual PCI bus multi-8255/8254 adapter 1. Connector Pin Assignments (JP1) U1/U2 Functio Functio P1A1 P1A0 P1A3 P1A2 P1A5 P1A4 P1A7 P1A6 P1B1 P1B0 P1B3 P1B2 P1B5 P1B4 P1B7 P1B6 P1C1 P1C0 P1C3 P1C2 P1C5 P1C4 P1C7 P1C6 P2A1 P2A0...
- Page 13 Operations Manual PCI bus multi-8255/8254 adapter P2C5 P2C4 P2C7 P2C6 2. Connector Pin Assignments (JP2) U3/U4 Functio Functio P3A1 P3A0 P3A3 P3A2 P3A5 P3A4 P3A7 P3A6 P3B1 P3B0 P3B3 P3B2 P3B5 P3B4 P3B7 P3B6 P3C1 P3C0 P3C3 P3C2 P3C5 P3C4...
- Page 14 Operations Manual PCI bus multi-8255/8254 adapter P4C3 P4C2 P4C5 P4C4 P4C7 P4C6 頁 頁碼DECISION Computer International 碼...
- Page 15 Operations Manual PCI bus multi-8255/8254 adapter Connector Pin Assignments (JP3) U5/U6 Functio B Function P5A1 P5A0 P5A3 P5A2 P5A5 P5A4 P5A7 P5A6 P5B1 P5B0 P5B3 P5B2 P5B5 P5B4 P5B7 P5B6 P5C1 P5C0 P5C3 P5C2 P5C5 P5C4 P5C7 P5C6 P6A1 P6A0...
- Page 16 Operations Manual PCI bus multi-8255/8254 adapter P6C7 P6C6 頁 頁碼DECISION Computer International 碼...
- Page 17 Operations Manual PCI bus multi-8255/8254 adapter 3. Connector Pin Assignments (JP4) U7/U8 Functio Functio P7A1 P7A0 P7A3 P7A2 P7A5 P7A4 P7A7 P7A6 P7B1 P7B0 P7B3 P7B2 P7B5 P7B4 P7B7 P7B6 P7C1 P7C0 P7C3 P7C2 P7C5 P7C4 P7C7 P7C6 P8A1 P8A0...
- Page 18 Operations Manual PCI bus multi-8255/8254 adapter P8C7 P8C6 頁 頁碼DECISION Computer International 碼...
- Page 19 Operations Manual PCI bus multi-8255/8254 adapter Connector Pin Assignments (JP5) U16/U17 Functio Functio CLK0 OUT0 GATE0 CLK1 OUT1 GATE1 CLK2 OUT2 GATE2 CLR3 OUT3 GATE3 CLK4 OUT4 GATE4 CLK5 OUT5 GATE5 -12V +12V -12V 1MHZ 5MHZ 100KHZ 500KHZ 頁碼DECISION Computer International 頁...
-
Page 20: Dii Device Driver
Industrial Interface"). After DII is installed, please select “Start” menu, then “Settings”, then “Control Panel”, then “Add New Hardware” menu, then select PCI multi-8255 card on the “Industrial I/O Devices” hardware group. The DII provides DLL, OCX, ... etc. components for further programming. -
Page 21: Diagnostic
: integer; procedure subtest; begin for i := 0 to 2 do port[test+i] := a; end; begin { 8255 I/O Card Testing Program } clrscr; gotoxy(10, 10); writeln('8255 I/O CARD TESTING'); gotoxy(10, 12); writeln('TWO 8255 PORT A,B,C OUTPUT SQUARE WAVE');... - Page 22 Operations Manual PCI bus multi-8255/8254 adapter { 8253 Testing } test := $1B0; port[test+11] := $36; port[test+11] := $76; port[test+11] := $B6; port[test+ 8] := $02; port[test+ 8] := $0; port[test+ 9] := $32; port[test+ 9] := $0; port[test+10] := $64;...
- Page 23 I/O CARD TESTING"); gotoxy(10,12); puts("TWO 8255 PORT A,B,C OUTPUT SQUARE WAVE"); gotoxy(10,14); puts("8253 COUNTER 0 DIVIDE BY 2"); gotoxy(10,16); puts("8253 COUNTER 1 DIVIDE BY 50"); gotoxy(10,18); puts("8253 COUNTER 2 DIVIDE BY 100");...
- Page 24 Operations Manual PCI bus multi-8255/8254 adapter } while(!kbhit()); 頁 頁碼DECISION Computer International 碼...
- Page 25 DECISION COMPUTER INTERNATIONAL CO., LTD. Each piece of PCI bus 8255 adapter package permits user to use PCI bus 8255 adapter only on a single computer, a registered user may use the program on a different computer, but may not use the program on more than one computer at the same time.
-
Page 26: A.2 Warranty Information
In the event of the failure of a PCI bus 8255 adapter product within the specified warranty period, DECISION will, at its option, replace or repair the item at no additional charge. This... - Page 27 DECISION is not liable to the purchaser for any damages or losses of any kind, through the use of, or inability to use, the PCI bus 8255 adapter product. DECISION reserves the right to determine what constitutes warranty repair or replacement.
-
Page 28: Data Sheet
Operations Manual PCI bus multi-8255/8254 adapter APPENDIX B DATA SHEET DATA SHEET Please put the data sheet that copy from DCI Smartlab 8255/8253 I/O card. 頁 頁碼DECISION Computer International 碼...
