Page 1 USER MANUAL 3 D printer K re a tor Motion...
Page 2: Welcome
Welcome Welcome among users of Kreator Motion printer! Read the manual of the device, all information will allow you to operate the printer easily.
Page 3: Table Of Contents
Table of contents Display and controlling Welcome Table of contents Display Basic information Calibration of the platform Kreator Motion printer Installation / Change of filament Technical parameters Printing Printing materials Additional information Unboxing Technical support First run...
Page 4: Basic Information
Basic information SAFETY GENERAL INFORMATION Before using the Kreator Motion printer, it is recommended to read the When printing process do not touch: the model, head of the following instructions. working table; failure to comply with this warning may cause burns...
Page 5: Kreator Motion Printer
Kreator Motion printer SET CONTENTS box of tools and a set roll with filament of cables Kreator Motion warranty card Quick Start 3D printer...
Page 6: Technical Parameters
Technical parameters PARAMETERS MEASUREMENTS Printing technology Fused Filament Fabrication Size of the printer 519 x 395 x 420 mm 200 x 200 x 190 mm 650 x 535 x 563 mm Workspace Size of the package 60 microns 18 kg Resolution of the print Weight of the device Precision of positioning...
Page 7 Technical parameters LCD screen Working chamber Cover Control knob SD reader Chamber with filament Head with extruder USB socket Filament sensor Table Power button Spool holder Platform Power socket...
Page 8: Printing Materials
Printing materials 3D Kreator offers filaments to the Kreator Motion Printer. They are a guarantee of successful print and trouble-free operation of the device. For more information visit our website: www.3dkreator.com...
Page 9: Unboxing
Unboxing UNBOXING AND FIRST RUN Place the box on a flat and Pull out the inner box . Remove 4 cardboard packa- Lift the inner box up until you see stable surface, then open the ge protectors. the printer. Put all of the packa- outer box.
Page 10: First Run
First run UNBOXING AND FIRST RUN We recommend cutting the strap on the right side of print head. Locate the yellow plastic transport bezel, which protects the head Cut the strap and remove it from inside the from moving during transport. It is marked in blue inn the graphic. printer.
Page 11 First run UNBOXING AND FIRST RUN Remove the box located Plug the power cord into the Turn on the printer using the The print chamber should under the table - you might socket at the rear of the prin- button located above the po- light up blue, which means need to use a bit of force ter and plug into an electrical...
Page 12: Display And Controlling
Display and controlling FIRST STARTUP SCREEN After starting the printer, the display shows startup screen. 3DKREATOR Temperature of the print head: current / set. 5.00 Temperature of the print platform: current / set 100% Printer status Dis. stepper The current position of the table from the zero position expressed in millimetres.
Page 13 Display and controlling SECOND STARTUP SCREEN AND CONTROLLING Turning the control knob will start the second screen. 3DKREATOR 0 d 0:08:03 Total runtime. 0:01:13 The duration of current print. 0.0 m The total amount of used material (in meters). To navigate the menu use the control knob. If you turn it to the right or left you will move between the lines down or up the menu.
Page 14: Display
Display MAIN MENU Back Printing Change filament The main menu displays after clicking the control knob Calibration Back: return to the main screen, Printing: the function is available only when a SD card is in the reader, it allows for selection of the used material, the temperature and start of printing, Change filament: starts the procedure for changing the filament in the printer,...
Page 15 Display MAIN MENU Case lights Auto Cooldown Dis. steppers Advanced Case lights: printer case lights selection: Auto – automatic, backlight color depends on the printer status, On – white color of backlight regardless of the printer status, Off –backlight off. Cooldown: turns off the print head and table heater, Dis.
Page 16: Calibration Of The Platform
Calibration of the platform Calibrating the working platform is recommended when you first start the printer. Calibration of the table consists of leveling it with respect to the print head by means of three nuts located underneath the table’s platform. Tighte- ning them (turning them to the right) lowers the table, while loosening them (turning them to the left) raises the table. NOTICE! During the calibration process the print head heats up to 235°C. Be careful and do not touch the head components.
Page 17 Calibration of the platform CALIBRATION PROCEDURE From the main menu, select Calibration. The print head will travel to the front of the chamber and heat up to C. Clean the nozzle with tweezers and choose Next step. The print head will move to the first calibration point, located above nut nr 1. By turning the nut will cause the printer’s backlight to change color from white to green. NOTICE! A green light does not always mean that the printing platform is properly calibrated.
Page 18: Installation / Change Of Filament
Installation / Change of filament PROCEDURE FOR CHANGING A FILAMENT Before the first print, a spool with filament must be installed in the printer. This option is also used to change the material to another. From the main menu, select Change filament. Back Change filament The print head will travel to the front of the cham- Calibration ber and heat up to 235 Manual control NOTICE! During the process of changing the filament, the print head heats to temperature of 235°C.
Page 19 Installation / Change of filament PROCEDURE FOR CHANGING A FILAMENT Open the side door of the fila- If you load the material for the first time, skip Prepare the new filament spool–unravel about 40 ment compartment. this step. If you change the filament, remove cm of material and make sure that the material is around 5 cm of the filament the old material from the tube through the clean.
Page 20 Installation / Change of filament PROCEDURE FOR CHANGING A FILAMENT Back Finish From the menu, select Exit. Load the material into the fi- Place the roll of material Choose the Insert filament option from on the roller and close the Following this procedure, the lament sensor located inside the menu repeatedly while at the same door of the filament com- printer is ready to print using...
Page 21: Printing
Printing FIRST PRINT Printing with 3DKreator is easy. Follow these guidelines to create three-dimensional models: Perform calibration of the platform with a procedure which can be found in this manual (page 16) Instal material in your printer (page 18) Insert the SD card into the reader located at the lower right corner of the device.
Page 22: Additional Information
Additional information Each time you print, clean the table with the remains of the filament and other dirt. It has a big impact on the proper bonding of layers of the material in the initial stage of printing. Use spatula and dry cloth. Filament should be stored according to manufacturers guidelines.
Page 23: Technical Support
For more information on operating the device please visit our website: www. 3dkreator.com In case of problems and ambiguities related to the use of Kreator Motion printer, please contact us at support@3dkreator.com, please quote the serial number of the device or use the form available on the website...
