Summary of Contents for Jaycar Electronics ST-1025
-
Page 1: User Manual
ST 1025 Moving Head Light User Manual Please read the instructions carefully before use... - Page 2 9. Fixture Cleaning The cleaning of internal must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or TABLE OF CONTENTS particularly dirty surrounding can cause greater accumulation of dirt on the fixture’s optics. ...
-
Page 3: Troubleshooting
8. Troubleshooting 1. Safety Introductions Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: Please read the instructions carefully which includes important information about the installation, operation and maintenance. A. The fixture does not work, no light WARNING 1. -
Page 4: Technical Specifications
7. DMX512 Connections 2. Technical Specifications The DMX512 is widely used in intelligent lighting control, with a maximum of 512 channels. Voltage: 100-240V, 50/60HZ Power consumption :80W Light source: 7*10W RGBW(4 in 1) Beam Angle：４５° Play mode:sound,Auto,DMX512,Master/save Dimenson:177*177*240MM Weight: 2.8 kg 1. - Page 5 13 DMX Channels Mode: Channel Value Function 0-255 0-255 PAN FINE 0-255 TILT 0-255 TILT FINE 0-255 Motor speed (CH1,CH2,CH3,CH4) CH 6 0-255 Dimmer/Strobe Red dimmer 0-255 0-255 Green dimmer 0-255 Blue dimmer White dimmer 0-255 CH10 0-255 Color+Strobe CH11 none Auto slow 3-84...
-
Page 6: Dmx512 Configuration
Master/Slave mode, the first fixture will control the others to give an automatic, sound 4.2 Main Function activated, synchronized light show. This function is good when you want an instant show. The first fixture it’s DMX input cable will have nothing connect it, and the other fixtures will MENU function be set in slave mode automatically.
