Summary of Contents for D'Amore engine'ring SMD IM-SG

  • Page 1 IM-SG Impedance Meter / Signal Generator Owner ’s Manual...

  • Page 2: Table Of Contents

    Table of Contents The Purpose and Benefit of This Tool What is Included About the Design Specifications Power Requirements General Notes for using the IM-SG Compensating for test harness impedance General Notes for Measuring Raw Speaker Drivers Finding the Resonant Frequencies of a Vehicle or Room Finding the Resonant Frequencies of parts (finding rattles) Using the IM-SG to tune the response of an audio system Checking the Impedance of Speaker Cables or Signal Cables 13...

  • Page 3: The Purpose And Benefit Of This Tool

    The Purpose and Benefit of the IM-SG The D'Amore Engineering IM-SG was designed to test the impedance of raw speaker drivers, loaded speaker enclosures, passive crossover networks, audio signal cables, speaker wires, and multi-speaker systems over the entire audio frequency range. In addition it can also be used as a stand-alone signal generator for both sine wave and pink noise for system tuning.

  • Page 4: Specifications

    Specifications  Impedance Measurement Range 1 ohm-100 ohms with 0.1ohms resolution  Low Impedance Measurement Range 0.00 ohm- 0.99 ohms with 0.01 ohms resolution  Operating Range of Battery 9.5 Volts - 6.4 Volts  Sine Wave Generation Frequency Range greater than 8Hz - 20kHz in two ranges ...

  • Page 5: Power Requirements

    Power Requirements Pull the silicon rubber boot off of the unit by starting at one end and pulling off towards the other end. On the back side you will see the battery compartment. Slide battery compartment cover off towards bottom end of unit to reveal the 9V battery compartment.

  • Page 6: General Notes For Using The Im-Sg

    General Notes for using the IM-SG The Off button - Hold for 3 seconds to put the IM-SG to sleep The On button - Hold for 1 second to wake the IM-SG When the IM-SG is powered up, it will display the condition of the 9V battery.

  • Page 7: Compensating For Test Harness Impedance

    General Notes for using the IM-SG continued The rotary knob - Rotate slowly to sweep through the frequency range. The display - The display shows the generator frequency "f” and the measured impedance "Z" simultaneously. Harness Compensation If making critical measurements, like those needed when trying to derive Thiele/Small parameters for a speaker driver (Page X), the IM-SG can compensate for harness impedance to obtain the highest accuracy possible.

  • Page 8: General Notes For Measuring Raw Speaker Drivers

    General Notes for Measuring Raw Speaker Drivers (out of box) When measuring raw speaker drivers it is important that the room in which the speaker is being tested is quiet and the air in the room is still. If a fan is blowing and air is moving in the room it will cause inaccurate readings.

  • Page 9: Finding The Resonant Frequencies Of A Vehicle Or Room

    Finding the Resonant Frequencies of a Vehicle or Room (For max SPL) 1. Connect IM-SG to any auxiliary input of a source unit or amplifier to use the IM-SG as a signal generator. Turn the volume of the source unit or amplifier gain down. 2.

  • Page 10: Finding The Resonant Frequencies Of Parts (Finding Rattles)

    Finding the Resonant Frequencies of vehicle parts (finding rattles) Most of the interior and exterior parts of a vehicle, and even furniture and other items in a living room can be subject to mechanical resonance. A door panel for instance, at some frequency it has a natural resonance frequency, or a frequency at which it will start to vibrate due to its physical properties.

  • Page 11: Using The Im-Sg To Tune The Response Of An Audio System

    Using the IM-SG to tune the response of an audio system By using the IM-SG with an audio spectrum analyzer (RTA) or with a inexpensive handheld SPL meter, it is possible to analyze the frequency response of an entire audio system and correct the response with equalization or by swapping phase of individual speakers, or by adjusting crossover points.
  • Page 12 Using the IM-SG to tune the response of an audio system - continued SPL Meter Method Connect IM-SG to any auxiliary input of a source unit or amplifier to use the IM-SG as a sine wave generator. Turn the volume of the source unit or amplifier gain down.

  • Page 13: Checking The Impedance Of Speaker Cables Or Signal Cables

    Checking the Impedance of Speaker Cables or Signal Cables With the IM-SG's low impedance mode and harness compensation it is easy to test the impedance of power wire, speaker cables, signal cables, and more. A few examples are listed below. Testing Power Cable 1.
  • Page 14 Checking the Impedance of Speaker Cables or Signal Cables - continued 4. Wait for the impedance reading to settle before reading it 5. This is a good way to compare two different types of wire as long as types are the same length. 6.

  • Page 15: Checking The Final Speaker Load On An Amplifier

    Checking the Final Speaker Load on an Amplifier With the IM-SG it is possible and useful to test the impedance of a speaker system be it a component set, an individual speaker, or a multi subwoofer setup. 1. To measure the f , make sure the room or area around the subwoofer is quiet and free from moving air.

  • Page 16: S )

    Finding the f of a Raw Speaker Driver The f is the speaker's natural resonant frequency. This will give you some idea of the usable bandwidth of the speaker. Generally the speaker will not produce usable output below the frequency of f 1.
  • Page 17 Figure 1, Impedance curve of a single 4 ohm voice coil, 15 inch subwoofer. Notice the f at 24 Hz.

  • Page 18: The Significance Of F

    The Significance of f Subwoofer - The f value of a subwoofer is the frequency at which the cone naturally resonates, or vibrates at. This is one of the factors that determine how low a subwoofer will play. Example: A subwoofer with an f of 35 Hz is going to have a harder time trying to reproduce a 25 Hz tone than a subwoofer with a f...
  • Page 19 The Significance of f - Continued Tweeter - Most tweeters have a measureable f frequency. There are some types of tweeters, (ribbons for instance) that have an almost flat impedance across its operating range. For this type of tweeter, follow manufacturer's recommendations for crossover frequency.
  • Page 20 Figure 2, Impedance curve of a typical 4 ohm, 1" tweeter. Notice the f at 1.59 kHz...

  • Page 21: C )

    Finding the f of a Sealed Box Subwoofer System 1. The f is the driver's natural resonant frequency while in the sealed enclosure. This will give you some idea of the usable bandwidth of the speaker. Generally the output of the sealed subwoofer system will start to decrease as the frequency goes below f 2.
  • Page 22 Figure 3, f of a single 4 ohm, 15 inch subwoofer in a 2 cubic feet sealed box.

  • Page 23: Tc )

    Finding the Q of a Sealed Box Subwoofer System The Q of a sealed subwoofer box system will give you some idea of how the frequency response of the system might be. The effects of different Sealed Box Subwoofer values are shown in the chart below. Typical range of is 0.7 - 1.2.
  • Page 24 Figure 4 For a given driver, the Q of the sealed subwoofer box system will be affected directly by the volume of the enclosure. The larger the enclosure, the lower the Q value will be. The box can be stuffed with polyester stuffing or lined with fiberglass insulation to make adjustments to the enclosure's Q value.

  • Page 25: Finding The Volume Of A Subwoofer Enclosure

    Finding the Volume of a Subwoofer Enclosure By taking some measurements with the IM-SG and knowing two of the T/S parameters of the driver, it is possible to find the exact volume of a subwoofer enclosure. For this method to work, the enclosure has to be completely sealed. As such it may not be possible to use this method on a ported enclosure unless it is possible to seal off the port completely.
  • Page 26 6. Now using the V of the raw driver, the f of the raw driver, and the f of the subwoofer/box system we can determine the volume of the enclosure using the following formula. 7. On our sample 12 inch subwoofer driver used in the Finding the Thiele / Small (T/S) parameters of a driver section we measured the f to be 27.1 Hz.

  • Page 27: B

    Finding the Tuning Frequency of a Ported Subwoofer Box System (f The f is the resonant frequency of the ported subwoofer enclosure. Measuring this will give you some idea of the usable bandwidth of the speaker and also if the target tuning frequency when constructing the enclosure was met.
  • Page 28 Finding the Tuning Frequency of a Ported Subwoofer Box System (f ) - continued 8. Figure 5 below shows the impedance curve of a 12 inch woofer in a ported box tuned to 30 Hz. The minimum impedance between the two peaks is f , the tuning frequency.

  • Page 29: B )

    Finding the Tuning Frequency of a Passive Radiator Subwoofer Box System (f Finding the tuning frequency of a passive radiator subwoofer box system (f ) is exactly the same procedure as finding the tuning frequency for a ported box. Follow the instructions for Finding the Tuning Frequency of a Ported Subwoofer Box System on page 18.

  • Page 30: P )

    Finding the Resonant Frequency of a raw Passive Radiator (f 1. Connect IM-SG to any auxiliary input of a source unit or amplifier to use the IM-SG as a signal generator. Turn the volume of the source unit or amplifier gain down. 2.

  • Page 31: Finding The Characteristics Of 4Th Order Bandpass Box

    Finding the characteristics of a 4th order Bandpass Box (single reflex) 1. With the IM-SG, it is possible to find the port tuning frequency and the approximate bandwidth of a single reflex bandpass subwoofer system. 2. To measure the impedance characteristics of the subwoofer system, make sure the room or area around the subwoofer is quiet and free from moving air.
  • Page 32 Finding the characteristics of a 4th order Bandpass Box (single reflex) - continued 9. f and f tell us about the usable bandwidth of the system. Output of the subwoofer will start to decrease at frequencies below f and subwoofer output will decrease at frequencies higher than f Figure 6, the impedance curve of a single 4 ohm voice coil subwoofer in a single reflex bandpass enclosure (4th...

  • Page 33: Finding The Thiele / Small (T/S) Paramters Of A Driver

    Finding the Thiele / Small (T/S) parameters of a driver (Advanced Topic) You don't need more equipment and a computer to do this. With the IM-SG, a small digital postage scale, and some play dough; it is possible to derive all of the T/S parameters that are needed to design a perfect custom subwoofer enclosure specific for your driver.
  • Page 34 Finding the Thiele / Small (T/S) parameters of a driver - continued Speaker Type Range Subwoofer 10 - 70 Hz Midbass 20 - 150 Hz Midrange 30 - 900 Hz 6. Record the frequency where the impedance reaches its maximum value within the range above. This Frequency is the f 7.
  • Page 35 Finding the Thiele / Small (T/S) parameters of a driver - continued represents an impedance that we are going to try to find with the IM-SG. This impedance will happen twice, once at a frequency lower than the f and once at a frequency higher than the f .
  • Page 36 Finding the Thiele / Small (T/S) parameters of a driver - continued Figure 8, finding f and f 12. To find Q plug in the recorded values for F and F into the equation below. Using numbers from our 12 inch woofer example = = 3.21...
  • Page 37 Finding the Thiele / Small (T/S) parameters of a driver - continued 13. Now calculate and record Q using this formula Using the measurements from our test woofer we get: So, Q = 0.31 14. Now calculate and record Q with this formula Using the measurements from our test woofer we get: So, Q...
  • Page 38 Finding the Thiele / Small (T/S) parameters of a driver - continued 15. To measure the V we need to add some mass to the cone and re-measure the f with the mass on the cone. We found that play dough or modeling clay works well because it is easy to make various weights and it molds easily onto the cone.
  • Page 39 Finding the Thiele / Small (T/S) parameters of a driver - continued For our sample we used 135 grams and measured the new impedance peak to be 21.3 Hz. So MA = 135 and f 21.3 MA = 18. Calculate F with by plugging in F and F into the...
  • Page 40 Finding the Thiele / Small (T/S) parameters of a driver - continued Photo 1 From the measured value of the diameter, D, we can calculate the cone area with this formula So for our woofer which measured 10 inches from center of surround to center of surround we get: So we get Sd = 78.54 square inches.
  • Page 41 Finding the Thiele / Small (T/S) parameters of a driver - continued 21. Calculate and record M For our example we get So M = 6.6 grams 22. Calculate and record M For our example we get So M = 224.6 grams, this is the moving mass of the driver...
  • Page 42 Finding the Thiele / Small (T/S) parameters of a driver – continued 23. Calculate and record C For our example we get So C = 0.000154 24. Calculate and record V For our example we get Finally V = 1.98 cubic feet...
  • Page 43 Finding the Thiele / Small (T/S) parameters of a driver - continued Table of parameters found in this process, in order, from 12 inch woofer used in example. Ohms 27.1 38.3 Ohms 11.4 Ohms 3.21 unitless 0.31 unitless 0.28 unitless 224.6 grams 0.000154...
  • Page 44 Notes:...
  • Page 45 Notes:...

  • Page 46: Troubleshooting

    Troubleshooting: Problem: The unit says “battery bad replace now” and won’t go to next screen Solution: Replace battery Problem:. It won’t switch modes from low range to high range to pink noise Solution: Make sure the impedance being read is greater than 0.5 ohms.

  • Page 47: Limited Warranty Information

    Limited Warranty D’Amore Engineering warrants this product to be free of defects in materials and workmanship for a period of one year. This warranty is not transferrable and applies only to the original purchaser from an authorized D’Amore Engineering dealer. Should service be necessary under this warranty for any reason due to manufacturing defect or malfunction, D’Amore Engineering will (at its discretion) repair or replace the defective product with new or remanufactured product...
  • Page 48 If you need service on your product All warranty returns should be sent to D’Amore Engineering accompanied by proof of purchase (a copy of the original sales receipt). Warranty expiration on products returned without proof of purchase will be determined from the manufacturing date code.
