Summary of Contents for German RepRap X1000

  • Page 1 1000 3D PRINTER MADE IN GERMANY X1000 3D printer manual Congratulations on your purchase of your personal X1000 3D printer German RepRap...

  • Page 2: Table Of Contents

    7.3 Recommissioning after trigger ..................... 43 8. Tipps & Tricks 8.1 How to determine the X1000s MAC address ..............44 8.2 How to update Repetier-Server ................... 44 8.3 PVA solution for enhanced adhesion ................. 45 X1000 02/51 3D printer manual...
  • Page 3 Humidity, solar radiation, heat, open flames ................47 Ventilation ............................47 Long absence, tempest, power plug reachability ..............47 Installation site ............................ 48 Disposal ..............................48 12. Legal disclaimers Software modifications/ use of applications ................48 Rev.Nr. 0.4 X1000 03/51 3D printer manual...

  • Page 4: General Information

    German RepRap The X1000 is a professional 3D printer, especially designed for processing various plastic mate- rials with extra-large work area and optional double extruder. With a layer thickness up to 0.1 mm und a printing surface of 1000x800x600 mm, this 3D printer can produce either big models or several small objects with the highest precision.

  • Page 5: System Requirements

    • Mac OS X 10.6 or newer • Ubuntu/Debian Linux • OpenGL 2.0 Please note that you must use one of the following browsers to establish a connection with your X1000 3D printer. • Chrome • Firefox Microsoft´s Internet Explorer is not supported 1.3 Additional options...

  • Page 6: Operating Modes Of The X 1000

    X1000 Standby In this mode, you can keep the lid of the X1000 open and heat up the extruder heads and let material extrude simultaneously. All other functions (like traversing the axis) are blocked for safety reasons. In addition, the standby mode allows you thread new filaments easily, to clean the nozzle or even to replace it completely.

  • Page 7: Green/ Work Mode

    RepRap 2.2 Green/ work mode To switch from standby mode to work mode to w After successfully booting the X1000 you must first close its lid. Then you must press the green switch underneath the LCD display. When the green switch is light up the lid will be locked automatically and the device is now ready to start a 3D print.

  • Page 8: Emergency Stop

    Allow the building platform to cool down, the object will be much easier to remove. The X1000 has two machine zeros. Besides the actual one the other one is located half way up the building platform. When operating the two-hand circuit this prevent pushing the printed object into the main- tenance lid.

  • Page 9: Network And Printer Set Up

    If necessary, contact your network administrator about integrating the X1000 into your network. If your network settings are DHCP based, the X1000 is automatically assigned an IP address. If this is the case the X100 just has to be connected through a patch cable to your network.
  • Page 10 Enter the following ip address to establish a connection to the 3d printer: 192.168.1.2 Info: By using this method you assign a static ip address in the same name space as your 3D printer to your computer Entering static IP address X1000 10/51 3D printer manual...

  • Page 11: Setup Routine

    In the first step, you chose the language of the installation assistant Setup routine step one Step 2: Please contact the support if an error message occurs during the second step or if not all bullet points are checked with the result “OK”. https://www.germanreprap.com/support/ X1000 11/51 3D printer manual...
  • Page 12 In the fourth step, you set the time and the date. You can get them set automatically over the internet. If you do not have an internet connection, you can also set them both manually. For some devices, there is a real-time module available. For an inquiry please contact the support via: https://www.germanreprap.com/support/ X1000 12/51 3D printer manual...
  • Page 13 Here you can connect your printer to a WLAN. Please press the button “Scan Wifi” to have all available wireless networks displayed. Here you can also choose between a static ip address or the use of DHCP. Setup routine step five Tip: Create a screenshot of these settings for later reference. X1000 13/51 3D printer manual...
  • Page 14 Step 7: Here you can activate the checkboxes at “Grafische Oberfläche” and “Filamentüberwachung”, depending on your configuration, for single - or double extruder. Setup routine step seven X1000 14/51 3D printer manual...
  • Page 15 Start the device using the key and wait until it is completely booted. Then shut it down and repeat the procedure. Setup routine step nine X1000 15/51 3D printer manual...

  • Page 16: How To Activate The Printer And Establish A Connection

    You will be presented the start screen (dashboard) of the Repetier-Server. Repetier-Server Dashboard To ensure that everything has been installed correctly click on your 3D printer and then on the right bar on “Druckereinstellungen”. Printer settings, Repetier-Server X1000 16/51 3D printer manual...
  • Page 17 Also, ensure that the baud rate is set to 15200 and the “Communica- tion-timeout” is enabled. Attention: Wir empfehlen einen Wert von 160, dieser kann bei bestimmten Geometrien jedoch abweichen. Gerne berät Sie hierbei einer unserer Fachhändler. General printer settings X1000 X1000 17/51 3D printer manual...

  • Page 18: Workflow And Operation

    One integrated software suite contains everything you need to print high quality parts • Customizable settings and advanced processes put the controls into your hands • Support for dual-extruders, multi-part printing and even multiple processes within one part X1000 18/51 3D printer manual...

  • Page 19: Quick Start Guide

    file and launch the .run installation package. It is recommended to launch this program as super-user by openingTerminal cd‘ing to the directory where you unzipped the file, and then typing: sudo ./Simplify3D*installer.run and entering the administrator password. X1000 19/51 3D printer manual...
  • Page 20 To import the downloaded profile, follow these steps: • Click on menu “File” “Import FFF-Profile” and choose the downloaded file. • Open the FFF settings window and check if the profile is visible. Select profile Import profile X1000 20/51 3D printer manual...

  • Page 21: The Interface Layout

    5. Toolbar • This toolbar contains quick access buttons for frequently used tools. You can move the toolbar anywhere you wish by clicking and dragging the top dotted line. Interface Layout X1000 21/51 3D printer manual...
  • Page 22 Move Model – Ctrl-left-click and drag (or Command-left-click on Mac) • Scale Model – Ctrl-right-click and drag up or down (or Command-right-click on Mac) • Rotate Model – Alt-left-click and drag right or left (or Option-Left Click on Mac) X1000 22/51 3D printer manual...
  • Page 23 To make adjustments to your Process, double-click on the Process or click Edit Process Settings. This will open the FFF (Fused Filament Fabrication) Settings window. Processes X1000 23/51 3D printer manual...
  • Page 24 The animated Preview Mode in the Simplify3D™ Software allows you to inspect all aspects of your print ope- ration prior to execution. The software takes your generated G-Code and virtually displays line by line how your model will be constructed. X1000 24/51 3D printer manual...
  • Page 25 This saves your print file to a user-defined location, such as a folder on your computer or an SD card. Congratulations! You have now completed your first 3D print using Simplify3D™ Software. You’ll soon be ready to explore other options and create many exciting models. X1000 25/51 3D printer manual...

  • Page 26: Repetier Server

    5.1 Web interface The web interface provides full control of the X1000, no matter if you work via a computer, a tablet or even a smartphone. To access the web interface, enter the following adress into your web browser: •...

  • Page 27: Dashboard

    In the bottom area under the heading of “Netzwerk” you can see the printer´s IP address and MAC address. There are also an URL and a QR code shown which you can use to connect another device to the 3D printer like a Smartphone or a tablet. X1000 27/51 3D printer manual...

  • Page 28: Device Panel

    You can use this menu item to manually operate your 3D printer. You can manually traverse the axis or regulate the heating bed. The controls are separated into 3 categories: • General working area • Extruder and temperature curves • Macros, to define your own commands Categories, Repetier-Server X1000 28/51 3D printer manual...
  • Page 29 Under the tab “bewegen” you can manually traverse the printer`s axis. This is either done by clicking on the corresponding arrow or via the slide controls, which are arranged around the virtual print bed, by pulling them to the required position. X1000 29/51 3D printer manual...
  • Page 30 As well as all the functions previously motioned here you also get to see tempe- rature cures for all heating elements. This view is especially useful to exclude mal- functions of the heating elements. Extruder and temperature curves, Repetier-Server X1000 30/51 3D printer manual...

  • Page 31: Eeprom

    I the EEPROM arena you have direct access to the printer´s firmware, therefor care should be taken when changing values. You should generally only modify these settings after consulting the support. Incorrectly registered values can lead to a malfunctioning device or could even damage the 3D printer. X1000 31/51 3D printer manual...

  • Page 32: Log-Files

    To record a 3D print you just must check the two boxes It is not possible to log already started print jobs. You must restart your 3D printer if you want to record a specific print job. Log-files, Repetier-Server X1000 32/51 3D printer manual...

  • Page 33: Firmwareupdate

    Make sure that under “Durckerboard Art” the Arduino 2560 Borad is chosen • Under “Firmware Abbild hochladen” you can select the path of the HEX file • The upload and installation will then be executed Firmware Upload X1000, Repetier-Server X1000 33/51 3D printer manual...

  • Page 34: Tool Heads And Cosumables

    5 : 24V - an empty 24V slot • 6 : FIL1 • 7 : Fan 5 / 24V fan to cool the hotends • 8 : E1 / T1 - extruderheater and thermistor Wiring X1000, tool slides X1000 34/51 3D printer manual...

  • Page 35: How To Set Up The Second Extruder

    6.2 How to set up the second extruder Follow this illustrated guide to put the second extruder into operation: If the X1000 is delivered with two extruders, the left/ first extruder sits lower compared to the right/second extruder. This is intentional. We recommend for new users to make their first 3D printing experience with only one extruder.

  • Page 36: How To Replace The Hot End And The Extruder

    Follow this illustrated guide to exchange a hot end or the entire extruder: Remove cover Remove fan The X1000`s cover is magnetically attached First, pull Then you take away the object fan (red) and the fan out the color marked tubes of the black cladding and for the hot end cooling (white).
  • Page 37 The hot end then can be easily pulled out of the extruder unit. Detail: assembly The assembly is done in the vice versa order. Please ensure that serrated washer is installed between the grounding lung and the holder metal sheet. X1000 37/51 3D printer manual...

  • Page 38: How To Change The Filaments

    For easy handling traverse the tool slide via the display to the following coordinates in the working mode (green): X: 500mm Y: 600mm Then change to the working mode (red) and open the X1000`s maintenance cover. Turn on the extruder`s heating elements and wait until they reached the desired temperature. • Green: Turn on the desired extruder on or off •...
  • Page 39 Removing the filament from extruder 1 Then open the material tray on the right side of the X1000. Here you can find the consumables as well as the filament monitoring. On the pictures above you can see the filament monitoring (white bordered). The feed for extruder 1 (EX0) is marked in pink, the feed for extruder 2 (EX1) is marked in green in the pictures above.
  • Page 40 Exchange the filaments when the filament sensor has triggered The filament monitoring checks in real time if the X1000 possesses enough material for processing. If the whole filament is used up during a print job, the device respond as follows: •...
  • Page 41 Turn off the heating bed manually and switch into standby mode (red) • Open the material tray on the right side of the X1000 and remove the empty spool • Mount the new spool and thread the filament only through the monitoring unit •...

  • Page 42: Co2 Extinguishing System

    Please review the user guide of the manufacturer on the cycles for maintenance and inspection of the extinguishing system. In case of activation the printer´s location must be immediately aerated. The X1000´s case is not hermetically sealed so that Co2 can escape the device!

  • Page 43: Manual Triggering

    After pulling the lever the device will be disconnected from mains and the complete work space and sitch cabinet will be flooded with CO2. Unplug the X1000 thereafter. Only operate the device in the space-...

  • Page 44: Tipps & Tricks

    To do this choose your 3D printer from the tab “settings”. Then click on “Network”. The IP address as well as the MAC address are displayed here. You are also shown an URL that enables access to the X1000´s web interface. The also displayed QR code can be used to access the web interface via mobile device.

  • Page 45: Pva Solution For Enhanced Adhesion

    9. Download area Here you can find all the files and documents that you need to operate your X1000. https://www.germanreprap.com/firmware/#x1000 Simplify Profiles...

  • Page 46: Return Shipment/ Original Package

    As part of your responsibility for your fellow human beings, please save this manual for eventual questions and give it in case of a resell to the new owner. X1000 46/51 3D printer manual...

  • Page 47: Power Supply

    In case of long term absence or tempest you should unplug the device as a precaution. We recom- mend this for all devices that are plugged to the printer, even via USB. X1000 47/51 3D printer manual...

  • Page 48: Installation Site

    Only use the software packages provided by German RepRap GmbH via download at their website at http:// www.germanreprap.com. German RepRap GmbH cannot be held liable for the loss of data on any external or internal storages. The device has been preinstalled with software and works as can be reasonably expected. It cannot be guaran- teed that the software is error free.
  • Page 49 Risk of fire (6.3.10) Operation only under supervision Daily cleaning of the device and the workplace Keep a fire extinguisher ready. The servo drive of the axes can become very hot; these must be cleaned regularly. X1000 49/51 3D printer manual...
  • Page 50 The wear and tear on the gas chamber can lead to uncontrolled movement. Daily visual and functionality tests are prerequisites for a safe operation. Transport 7.1 The transport is carried out by German RepRap GmbH. The device can by moved by the assembled wheels. Packed delivery: Machine weight: 400 Kg Local requirements for the delivery: forklift, lift truck when a transport via the assembled wheels is not possible.
  • Page 51 The incurred process waste must be separated into recyclable material and hazardous substances in accor- dance with local laws and practices. The device itself must also be separated into recyclable material and hazardous substances in accordance with local laws and practices. X1000 51/51 3D printer manual...
