Sharp TU-X1U Service Manual

Sharp TU-X1U Service Manual

Lcd color television
Hide thumbs
Table of Contents

Advertisement

Quick Links

TopPage
In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig-
inal condition and only parts identical to those specified should be used.
[1]
SPECIFICATIONS ................................. . ....... 1-1
[2]
OPERATION MANUAL .......................... . ....... 1-2
[3]
DIMENSIONS ........................................ . ....... 1-4
[1]
REMOVING OF MAJOR PARTS ........... . ....... 2-1
[1]
ADJUSTMENT PROCEDURE ............... . ....... 3-1
[2]
CHAPTER 4. TROUBLESHOOTING TABLE
[1]
TROUBLESHOOTING TABLE............... . ....... 4-1
Parts marked with "
" are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the
safety and performance of the set.

SERVICE MANUAL

LCD COLOR TELEVISION
CONTENTS
[1]
MAJOR IC INFORMATIONS .........................5-1
[1]
OVERALL WIRING DIAGRAM .....................6-1
[2]
SYSTEM BLOCK DIAGRAM .........................6-2
CHAPTER 7. PRINTED WIRING BOARD
ASSEMBLIES
[1]
MAIN Unit ......................................................7-1
[2]
TERMINAL Unit .............................................7-5
[3]
SUB TERMINAL Unit.....................................7-7
[4]
KEY Unit ........................................................7-9
CHAPTER 8. SCHEMATIC DIAGRAM
[1]
DIAGRAM......................................................8-1
[2]
SCHEMATIC DIAGRAM ................................8-2
No. S98P7TUX1U///
(AVC SYSTEM)
TU-X1U
MODEL
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
TU-X1U

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TU-X1U and is the answer not in the manual?

Questions and answers

Related Manuals for Sharp TU-X1U

Summary of Contents for Sharp TU-X1U

  • Page 1: Table Of Contents

    TopPage TU-X1U SERVICE MANUAL No. S98P7TUX1U/// LCD COLOR TELEVISION (AVC SYSTEM) TU-X1U MODEL In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig- inal condition and only parts identical to those specified should be used.

  • Page 2: Safety Precaution Important Service Safety Precaution

    TU-X1U TUX1U SAFETY PRECAUTION Service Manual IMPORTANT SERVICE SAFETY PRECAUTION Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the servicing guidelines which follow: WARNING • Use an AC voltmeter having with 5000 ohm per volt, or higher, sen- sitivity or measure the AC voltage drop across the resistor.

  • Page 3: Precautions A Prendre Lors De La Reparation

    TU-X1U PRECAUTIONS A PRENDRE LORS DE LA REPARATION Ne peut effectuer la réparation qu' un technicien spécialisé qui s'est parfaitement accoutumé à toute vérification de sécurité et aux conseils suivants. AVERTISSEMENT • A l'aide de deux fils à pinces, brancher une résistance de 1.5 kΩ...

  • Page 4: Precautions For Using Lead-Free Solder

    TU-X1U PRECAUTIONS FOR USING LEAD-FREE SOLDER Employing lead-free solder • “PWBs” of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals. The alphabetical character following LF shows the type of lead-free solder.

  • Page 5: Chapter 1. Operation Manual

    The depth does not include the protruding part of terminals. As part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units.

  • Page 6: Operation Manual

    TU-X1U [2] OPERATION MANUAL AVC System (Front/Rear/Bottom) INPUT 3 terminals SERVICE INPUT 4 terminal terminal (HDMI) Reset button Antenna/Cable in INPUT 1 terminals DIGITAL AUDIO OUTPUT terminal INPUT 2 terminals AUDIO OUTPUT RS-232C DC OUTPUT terminals terminal terminal INPUT 9 terminals...
  • Page 7 TU-X1U TV POWER: Switch the power on or enter standby. Remote Control Unit 0–9: Set the channel. (DOT): INPUT: Select an input source. (TV, INPUT 1, INPUT 2, INPUT 3, INPUT 4, INPUT 5, INPUT 6, INPUT 7, INPUT 8, INPUT 9, IrSS) MUTE: Mute the sound.

  • Page 8: Dimensions

    TU-X1U [3] DIMENSIONS Unit: mm 318.3 430.0 328.9 1 – 4...

  • Page 9: Chapter 2. Removing Of Major Parts

    TU-X1U CHAPTER 2. TUX1U REMOVING OF MAJOR PARTS Service Manual [1] REMOVING OF MAJOR PARTS 1. Remove the two lock screws from Top Cabinet. 2. Remove the three lock screws from Top Cabinet, and detach the Top Cabinet. Top Cabinet 3.
  • Page 10 TU-X1U 5. Remove the DC Output PWB from Rear Panel. 6. Remove the lock screws, two hexagon shaft screws, AC Inlet and one tuner nut from the Rear Panel, and detach the Rear Panel. 7. Remove the two lock screws, from the Rear Panel, and detach the Fan and Fan Angle.
  • Page 11 TU-X1U 10.Remove the lock screws from Main Unit, and detach the Main Unit. MAIN Unit 11.Remove the four lock screws from the Power Unit, and detach the Power Unit. POWER Unit 2 – 3...

  • Page 12: Chapter 3. Adjustment

    TU-X1U CHAPTER 3. TUX1U ADJUSTMENT Service Manual [1] ADJUSTMENT PROCEDURE The adjustment values are set to the optimum conditions at the factory before shipping. If a value should become improper or an adjustment is required due to part replacement, make an adjustment according to the following procedure.
  • Page 13 TU-X1U 5. Even a single failure in the process will trigger the upgrade failure screen. NOTE: In the event of a failure, repeat the upgrade process. If the process repeatedly fails, it is likely that the hardware need fixing. 6. Upon completion of the whole process, the upgrade success screen as shown below appears. You can check the new software version on this screen.
  • Page 14 TU-X1U 2.3. Monitor microprocessor software version upgrade Create the USB memory for monitor microprocessor software version upgrade in the same manner as explained in the “Main software version upgrade”. Copy the file XS1UVAxx.USB and XS1CSxxx.BIN (named temporarily) for monitor microprocessor software version upgrade to the USB memory.
  • Page 15 TU-X1U 3. Entering and exiting the adjustment process mode 1) Before entering the adjustment process mode, the AV position RESET in the video adjustment menu. 2) While holding down the “VOL (–)” and “INPUT” keys at a time, plug in the AC cord of the main unit to turn on the power.
  • Page 16 TU-X1U 5. List of adjustment process mode menu The character string in brackets [ ] will appear as a page title in the adjustment process menu header. Page Line Item Description Remarks (adjustment detail, etc.) STB MAIN Version Main software version...
  • Page 17 TU-X1U Page Line Item Description Remarks (adjustment detail, etc.) ANALOG RGB ADJ Analog RGB picture level adjustment R A_GAIN G A_GAIN B A_GAIN R D_GAIN G D_GAIN B D_GAIN R OFFSET G OFFSET B OFFSET Audio Switch Flat Mode ADC Volume 1...
  • Page 18 TU-X1U Page Line Item Description Remarks (adjustment detail, etc.) Output Trim Clipper SubVolume Default SubVolume SH Bass Mon Func Vol AIN Mon Func Vol HDMI Mon Func Vol ATV Mon Func Vol DTV SW Func Vol AIN SW Func Vol HDMI...

  • Page 19: Special Features

    TU-X1U 6. Special features * STANDBY CAUSE (Page 1/21) Display of a cause (code) of the last standby The cause of the last standby is recorded in EEPROM whenever possible. Checking this code will be useful in finding a problem when you repair the troubled set.
  • Page 20 TU-X1U 7.5. Component 33K signal adjustment Adjustment item Adjustment conditions Adjustment procedure Adjustment 1080i signal Feed the 100% color bar signal to INPUT 1 component input. 100% white Auto adjustment Page 6/36 Bring the cursor on [•COMP 33K ADJ] and press [ENTER].
  • Page 21 TU-X1U 8. Initialization to factory settings CAUTION: When initialization is performed, all user setting data including the channel settings are initialized. Be cautious when making this adjust- ment. (The adjustments done in the adjustment process mode are not initialized.) Adjustment item...

  • Page 22: Public Mode Setting Procedure

    TU-X1U [2] PUBLIC MODE SETTING PROCEDURE 1. How to start Public Mode • There are the following two ways to get the public mode setup screen displayed. In the adjustment process mode, turn on “PUBLIC MODE”. Also press the “CH ( )”...
  • Page 23 TU-X1U 4. Public Mode Menu The guidance is not displayed onscreen. Setup procedure • To move the cursor up and down, use the “cursor UP/DOWN” key (remote controller) and “CH ( )” key (remote controller and set). • To change the settings, use the “cursor RIGHT/LEFT” key (remote controller) and “VOL (+)/(–)” key (remote controller and set).
  • Page 24 TU-X1U 5. On Setting Items * “EZ-SETUP” discussed below indicates “EZ-SETUP after the first power-on”. 1) POWER ON FIXED Selection Selection between “Variable” and “Fixed” (loop provided) Default – (Variable) Explanation In “Fixed” setting, the power-off by the power key of the unit is invalidated and the image is kept being received. The power can be turned off by stopping the power supply from AC.
  • Page 25 TU-X1U 6) PANEL BUTTON Selection Selection between “Respond” and “No respond” (loop provided) Default Respond Explanation All the operations by keys (except the power key) of the unit can be invalidated. Limit in Setting • Adjustment process, inspection mode and hotel menu mode can be started irrespective of setting.
  • Page 26 TU-X1U 10)INPUT MODE FIXED Selection Selection between “Variable”, “Fixed”, “ACON (AC CTRL)” and “AC/RCON (AC/RC CTRL)” (loop provided) Default – (Variable) • At the “Fixed” setting, the TV set gets started with the settings of “Input mode start”, and then any other channels and inputs Explanation are not accepted.
  • Page 27 TU-X1U 15)PUBLIC MODE (ON/OFF) Selection Selection between “ON” and “OFF” (loop provided) Default Explanation In case of “ON”, public mode settings are effected. Limit in Setting None Exception None Remarks The public-mode settings are operable only when this item is set at ON.

  • Page 28: Troubleshooting Table

    TU-X1U CHAPTER 4. TUX1U TROUBLESHOOTING TABLE Service Manual [1] TROUBLESHOOTING TABLE No video (1) COMPOSITE: No external input video COMPOSITE: No external input video COMPOSITE: No external input video [INPUT-1] [INPUT-2] [INPUT-3] Is INPUT-1 selected on the input select Is INPUT-2 selected on the input select menu...
  • Page 29 TU-X1U Does the HOT PLUG detection function? Check the line between SC4501 and IC4503, and their periph- Is the DDC5V signal output at the pin (18) of SC4501 (HDMI_OUTPUT)? eral circuits. Does the HPD signal come from pin (19) of SC4501 (HDMI_OUTPUT) to pin (51) of IC4504...
  • Page 30 TU-X1U No video (2) COMPONENT: No external input video [INPUT-1] COMPONENT: No external input video [INPUT-3] Is INPUT-1 selected on the input select menu screen? Is INPUT-3 selected on the input select menu screen? Is the INPUT-SELECT for the input signal?
  • Page 31 TU-X1U Does the HPD signal come from pin(19) of SC4501 (HDMI_OUTPUT) to pin (51) Check the line between SC4501 and IC4504, of IC4504 (HDMI_Tx)? and their peripheral circuits. Check the HDMI cable and Monitor Unit. Are there the TMDS signal outputs at pins (12/10)(CLK-/+), (9/7)(D0-/+), (6/4)(D1-...
  • Page 32 TU-X1U No video (3) S-VIDEO: No external input video [INPUT-2] Is INPUT-2 selected on the input select menu screen? Select INPUT-2 on the input select menu screen for the right input signal. Does the INPUT-2 IN2_Y_PLG detection function? Check the line between pin (6) of input terminal (J502) and pin (H33) of IC8001 (CPU).
  • Page 33 TU-X1U Does the HPD signal come from pin (19) of SC4501 (HDMI_OUTPUT) to pin (51) of Check the line between SC4501 and IC4504, IC4504 (HDMI_Tx)? and their peripheral circuits. Check the HDMI cable and Monitor Unit. Are there the TMDS signal outputs at pins (12/10)(CLK-/+), (9/7)(D0-/+), (6/4)(D1-/+),...
  • Page 34 TU-X1U No video (4) No video at UHF/VHF broadcast signal reception. No video at digital broadcast signal reception. Is the specified TV signal selected on the input select menu screen? Is there the analog video signal output (VIDEO) at pin (13) of...
  • Page 35 TU-X1U Are there the TMDS signal outputs at pins (12/10)(CLK-/+), (9/7)(D0-/+), (6/ Check the line between SC4501 and IC4504, and 4)(D1-/+), (3/1)(D2-/+), all of SC4501 (HDMI_OUTPUT)? their peripheral circuits. Check the HDMI cable and Monitor Unit. 4 – 8...
  • Page 36 TU-X1U <HDMI input> No video (5) HDMI: No external input video [INPUT-4] Is INPUT-4 selected on the input select menu screen? Select INPUT-4 on the input select menu screen for the right input signal. Does the HOT PLUG detection function?
  • Page 37 TU-X1U Are the Parallel Video Signal inputs at the pins of IC4504(HDMI_Tx)? Check the line between IC4601 and HDMITX_G9-0 pin(71/72/73/74/75/77/78/79/80/81), IC4504, and their peripheral circuits. HDMITX_B9-0 pin(84/85/86/90/91/92/93/94/95/96), HDMITX_R9-0 pin(56/57/58/59/60/61/62/63/67/68), HDMITX_CLK pin(88), HDMITX_DE pin(1), HDMITX_HD pin(2), HDMITX_VD pin(3) Does the HOT PLUG detection function?
  • Page 38 TU-X1U <HDMI input> No video (6) HDMI: No external input video [INPUT-5] HDMI: No external input video [INPUT-6] Is INPUT-5 selected on the input select menu screen? Is INPUT-6 selected on the input select menu screen? Select INPUT-5 on the input select menu screen for Select INPUT-6 on the input select menu screen the right input signal.
  • Page 39 TU-X1U Are the LVDS signal inputs at the LVDS 1st channel and 2nd channel of IC4601 (FPGA)? Check the line between IC8001 LVDS_TX_0_DATA0_P/N (T3/R3), LVDS_TX_0_DATA1_P/N (T5/T4), and IC4601, and their peripheral LVDS_TX_0_DATA2_P/N (R7/T7), LVDS_TX_0_DATA3_P/N (R11/P11), circuits. LVDS_TX_0_DATA4_P/N (T13/R13), LVDS_TX_0_CLK_P/N (P9/N9),...
  • Page 40 TU-X1U <HDMI input> No video (7) HDMI: No external input video [INPUT-7] HDMI: No external input video [INPUT-8] Is INPUT-7 selected on the input select menu screen? Is INPUT-8 selected on the input select menu screen? Select INPUT-7 on the input select menu screen for the Select INPUT-8 on the input select menu screen for right input signal.
  • Page 41 TU-X1U Are the LVDS signal outputs at the LVDS 1st channel and 2nd channel of IC8001 (CPU)? Check IC8001 and its peripheral cir- LVDS_TX_0_DATA0_P/N (C7/B7), LVDS_TX_0_DATA1_P/N(E7/D7), cuits. (IC8151 thru IC8154, etc.) LVDS_TX_0_DATA2_P/N (C6/B6), LVDS_TX_0_DATA3_P/N(C5/B5), LVDS_TX_0_DATA4_P/N (E5/D5), LVDS_TX_0_CLK_P/N(E6/D6), LVDS_TX_1_DATA0_P/N (B4/A4), LVDS_TX_1_DATA1_P/N(E4/D4),...
  • Page 42 TU-X1U No video (8) PC: No external input video [INPUT-9] Is INPUT-9 selected on the input select menu screen? Select INPUT-9 on the input select menu screen for the right input signal. Is IC2202 (EEPROM) accessed by I2C, with PC connected, to read the DDC_I2C SCL/SDA data? Check the DDC line and its peripheral circuits.
  • Page 43 TU-X1U No audio (1) INPUT-1 No audio. INPUT-2 No audio. Is INPUT-1 selected on the input select menu screen? Is INPUT-2 selected on the input select menu screen? Is the audio output selected for "VARIABLE" Is the audio output selected for "VARIABLE" on the...
  • Page 44 TU-X1U No audio (1) INPUT-3 No audio. Is INPUT-3 selected on the input select menu screen? Is the audio output selected for "VARIABLE" on the menu screen? Set the audio output to "FIXED". Does the audio signal come from pins(5)(L) and (4)(R) of input termi- nal(J2201) to pins(40)(L) and (41)(R) of IC1403(CODEC)? Check the line between J2201 and IC1403.
  • Page 45 TU-X1U No audio (2) [HDMI analog audio input] INPUT-5 No audio. [PC analog audio input] INPUT-9 No audio. Is INPUT-5 selected on the input select menu screen? Is INPUT-9 selected on the input select menu screen? Is the audio output selected for "VARIABLE" on Is the audio output selected for "VARIABLE"...
  • Page 46 TU-X1U No audio (3) No audio at UHF/VHF broadcast signal reception. No audio at digital broadcast signal reception. Is TV selected on the input select menu screen? Is TV selected on the input select menu screen? Is the audio output selected for "VARIABLE" on the Is the audio output selected for "VARIABLE"...
  • Page 47 TU-X1U No audio (4) INPUT-4 No audio (HDMI connected) INPUT-5 No audio (HDMI connected) INPUT-6 No audio (HDMI connected) INPUT-7 No audio (HDMI connected) INPUT-8 No audio (HDMI connected) [INPUT-4 input] Is the audio output selected for "VARI- Is INPUT-4 selected on the input select menu screen? ABLE"...
  • Page 48 TU-X1U No audio signal at Digital Audio Output terminal (Analog sound heard) No INPUT-4/5/6/7/8 (HDMI) audio. No audio at digital broadcast signal reception. If no video appears, refer to "No external input video Are there the video signal outputs (IF_OUT_PT/NT) at the pins (19) (HDMI) [INPUT-4/5/6/7/8]".
  • Page 49 TU-X1U No monitor audio output Is the audio output from the monitor set at "VARIABLE" or Check the I2C line (SCL0/SDA0) and IC1403. "FIXED" on the menu screen? Does the I2S signal come from pins (AL24)(DSP_MCLK2), Check IC8001 and IC1403, and their peripheral circuits.
  • Page 50 TU-X1U No connect network Dose the signal come to 1 pin of LAN-jack J9501? (see fig-1, fig-2) Check the interface device and peripheral circuits. (power- LED of hub, LINK-LED of hub) Dose the signal come to 1pin of IC9501? (see fig-2) Check the line between J9501 and IC9501.

  • Page 51: Chapter 5. Major Ic Informations

    TU-X1U CHAPTER 5. TUX1U MAJOR IC INFORMATIONS Service Manual [1] MAJOR IC INFORMATIONS IC1604 (VHiSii9185A-1Q) This IC is TMDS switch device supporting Revision 1.3 of the HDMI Specification with three HDMI inputs and a signal output. This IC is used to select a single set of HDMI/DVI signals from three HDMI/DVI receiver-ports and to generate a fully compliant HDMI/DVI stream as an output.
  • Page 52 TU-X1U IC8452 (RH-iXC418WJQZQ) The 256-Mbit page mode flash memory device stores the main CPU program. IC9501 (VHiRTL8100C-1Q) This IC is Ethernet controller that provides 32-bit performance, PCI bus master capability, and full compliance with IEEE 802.3u 100Base-T specifica- tions and IEEE 802.3x Full Duplex Flow Control. It also supports the ACPI.

  • Page 53: Chapter 6. Overall Wiring/Block Diagram [1]

    TU-X1U TUX1U CHAPTER 6. OVERALL WIRING/BLOCK DIAGRAM Service Manual [1] OVERALL WIRING DIAGRAM OVERALL WIRING DIAGRAM QCNW-H700WJQZ UNIT QCNW-H701WJQZ QCNW-H699WJQZ SUB_TERMINAL UNIT POWER UNIT MAIN UNIT B to B TERMINAL UNIT B to B 6 – 1...
  • Page 54 TU-X1U [2] SYSTEM BLOCK DIAGRAM BLOCK DIAGRAM Terminal MAIN +3.3V +2.5V IC4602 P4600 IN1_V, IN1_V_PLG Config ROM CVBS/LR Connector for IN1_L/R INPUT writing FPGA +3.3V +3.3V IN1_Y, IN1_CB, IN1_CR, IN1_Y_PLG Component Data +2.5V +1.8V +1.2V IC4504 J501 IN2_V, IN2_V_PLG IC4601...

  • Page 55: Assemblies 1] Main Unit

    TU-X1U TUX1U CHAPTER 7. PRINTED WIRING BOARD ASSEMBLIES Service Manual [1] MAIN Unit MAIN Unit (Side-A) 7 – 1...
  • Page 56 TU-X1U MAIN Unit (Side-A Chip) P9001 R2207 C9005 SC2203 SC2202 R2209 R9034R9035 P1401 SC9201 C2223 FL1401 R1403 R9510 R9512 R9522 C8085 IC8003 R9501 L9501 C9501 R9502 J9501 R9503 L9502 C9506 IC9501 C8172 C8221 R9504 C9504 C8173 C8086 R8254 R8222 R8098...
  • Page 57 TU-X1U MAIN Unit (Side-B) 7 – 3...
  • Page 58 TU-X1U MAIN Unit (Side-B Chip) C2246 R2279 C2247 C2207 C1307 R1340 R1334 R1342 C2211 R9205 R2238 R2252 R2234 Q1310 Q1311 C2212 R2242 R2233 C2267 C2264 D2203 C2245 FB2207 R2258 R2255 C2277 C2272 C2215 IC2201 R2319 D2202 FB2206 C2208 Q2212 D2207...

  • Page 59: Terminal Unit

    TU-X1U [2] TERMINAL Unit TERMINAL Unit (Side-A) 7 – 5...
  • Page 60 TU-X1U TERMINAL Unit (Side-A Chip) TU1101 R1117 R1112 R519 C1110 R1108 FB510 C525 J502 C523 R547 R555 R553 R520 C1103 D507 C517 C524 FB511 C522 R552 C1112 R546 R554 C518 R521 FB506 C515 R542 D504 R536 R544 R510 C508 FB503...

  • Page 61: Sub Terminal Unit

    TU-X1U [3] SUB TERMINAL Unit SUB TERMINAL Unit (Side-A) 7 – 7...
  • Page 62 TU-X1U SUB TERMINAL Unit (Side-A Chip) C612 C611 C604 C601 D602 D601 KAME1 KAME2 SC601 J602 J601 7 – 8...

  • Page 63: Key Unit

    TU-X1U [4] KEY Unit KEY Unit (Side-A) KEY Unit (Side-A Chip) D201 R202 R203 R205 R208 Q202 Q204 R207 Q201 Q203 R201 7 – 9...

  • Page 64: Description Of Schematic Diagram

    TU-X1U TUX1U CHAPTER 8. SCHEMATIC DIAGRAM Service Manual [1] DESCRIPTION OF SCHEMATIC DIAGRAM 1. VOLTAGE MEASUREMENT CONDITION: 1) The voltages at test points are measured on exclusive AC adaptor and the stable supply voltage of AC 120V. Signals are fed by a color bar signal genera- tor for servicing purpose and the above voltages are measured with a 20k ohm/V tester.

  • Page 65: Schematic Diagram

    TU-X1U [2] SCHEMATIC DIAGRAM MAIN Unit (1/18) 8 – 2...
  • Page 66 TU-X1U MAIN Unit (2/18) 8 – 3...
  • Page 67 TU-X1U MAIN Unit (3/18) 8 – 4...
  • Page 68 TU-X1U MAIN Unit (4/18) 8 – 5...
  • Page 69 TU-X1U MAIN Unit (5/18) 8 – 6...
  • Page 70 TU-X1U MAIN Unit (6/18) 8 – 7...
  • Page 71 TU-X1U MAIN Unit (7/18) 8 – 8...
  • Page 72 TU-X1U MAIN Unit (8/18) 8 – 9...
  • Page 73 TU-X1U MAIN Unit (9/18) 8 – 10...
  • Page 74 TU-X1U MAIN Unit (10/18) 8 – 11...
  • Page 75 TU-X1U MAIN Unit (11/18) 8 – 12...
  • Page 76 TU-X1U MAIN Unit (12/18) 8 – 13...
  • Page 77 TU-X1U MAIN Unit (13/18) 8 – 14...
  • Page 78 TU-X1U MAIN Unit (14/18) 8 – 15...
  • Page 79 TU-X1U MAIN Unit (15/18) 8 – 16...
  • Page 80 TU-X1U MAIN Unit (16/18) 8 – 17...
  • Page 81 TU-X1U MAIN Unit (17/18) 8 – 18...
  • Page 82 TU-X1U MAIN Unit (18/18) 8 – 19...
  • Page 83 TU-X1U KEY Unit 8 – 20...
  • Page 84 TU-X1U TERMINAL Unit (1/2) 8 – 21...
  • Page 85 TU-X1U TERMINAL Unit (2/2) 8 – 22...
  • Page 86 TU-X1U SUB TERMINAL Unit 8 – 23...

  • Page 87: Parts Guide

    TU-X1U PartsGuide PARTS GUIDE No. S98P7TUX1U/// LCD COLOR TELEVISION (AVC SYSTEM) TU-X1U MODEL CONTENTS PRINTED WIRING BOARD DUNTKE837FE01 ASSEMBLIES (SUB TERMINAL Unit) PRINTED WIRING BOARD CABINET PARTS ASSEMBLIES (UNIT REPLACEMENT ITEM) SUPPLIED ACCESSORIES DUNTKE593FE02(KEY Unit) PACKING PARTS DUNTKE760FE01(MAIN Unit) [10] SERVICE JIGS DUNTKE761FE01(TERMINAL Unit) Parts marked with "...
  • Page 88 TU-X1U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [1] PRINTED WIRING BOARD ASSEMBLIES KEY Unit DUNTKE593FE02 MAIN Unit DUNTKE760FE01 TERMINAL Unit DUNTKE761FE01 SUB TERMINAL Unit DUNTKE837FE01 [2] PRINTED WIRING BOARD ASSEMBLIES (UNIT REPLACEMENT ITEM) POWER Unit RDENCA301WJQZ DC OUT Unit...
  • Page 89 TU-X1U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE760FE01(MAIN Unit) C1524 Capacitor 1000p 50V Ceramic VCKYCZ1HB102KY C1525 Capacitor 0.1 25V Ceramic VCKYCZ1EF104ZY C1526 Capacitor 1000p 50V Ceramic VCKYCZ1HB102KY C1527 Capacitor 0.1 25V Ceramic VCKYCZ1EF104ZY C1528 Capacitor 1000p 50V Ceramic...
  • Page 90 TU-X1U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE760FE01(MAIN Unit) C1673 Capacitor 0.1 10V Ceramic VCKYCZ1AB104KY C1674 Capacitor 1000p 50V Ceramic VCKYCZ1HB102KY C1680 Capacitor 330p 50V Ceramic VCKYCZ1HB331KY C1681 Capacitor 330p 50V Ceramic VCKYCZ1HB331KY C1701 Capacitor 10 16V Ceramic...
  • Page 91 TU-X1U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE760FE01(MAIN Unit) C2234 Capacitor 15p 50V Ceramic VCCCCZ1HH150JY C2235 Capacitor 27p 50V Ceramic VCCCCZ1HH270JY C2236 Capacitor 27p 50V Ceramic VCCCCZ1HH270JY C2237 Capacitor 33p 50V Ceramic VCCCCZ1HH330JY C2238 Capacitor 33p 50V Ceramic...
  • Page 92 TU-X1U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE760FE01(MAIN Unit) C4609 Capacitor 0.01 25V Ceramic VCKYCZ1EB103KY C4610 Capacitor 0.01 25V Ceramic VCKYCZ1EB103KY C4611 Capacitor 0.01 25V Ceramic VCKYCZ1EB103KY C4612 Capacitor 0.01 25V Ceramic VCKYCZ1EB103KY C4613 Capacitor 0.01 25V Ceramic...
  • Page 93 TU-X1U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE760FE01(MAIN Unit) C8050 Capacitor 4.7 6.3V Ceramic RC-KZA116WJZZY C8051 Capacitor 0.1 10V Ceramic VCKYCZ1AB104KY C8052 Capacitor 1000p 50V Ceramic VCKYCZ1HB102KY C8053 Capacitor 1000p 50V Ceramic VCKYCZ1HB102KY C8054 Capacitor 0.01 25V Ceramic...
  • Page 94 TU-X1U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE760FE01(MAIN Unit) C8162 Capacitor 2700p 50V Ceramic VCKYCZ1HB272KY C8163 Capacitor 2700p 50V Ceramic VCKYCZ1HB272KY C8164 Capacitor 470p 50V Ceramic VCKYCZ1HB471KY C8165 Capacitor 470p 50V Ceramic VCKYCZ1HB471KY C8166 Capacitor 10 10V Ceramic...
  • Page 95 TU-X1U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE760FE01(MAIN Unit) C8925 Capacitor 0.1 10V Ceramic VCKYCZ1AB104KY C8926 Capacitor 0.1 10V Ceramic VCKYCZ1AB104KY C8927 Capacitor 0.1 10V Ceramic VCKYCZ1AB104KY C8928 Capacitor 0.1 10V Ceramic VCKYCZ1AB104KY C8929 Capacitor 0.1 10V Ceramic...
  • Page 96 TU-X1U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE760FE01(MAIN Unit) C9649 Capacitor 1000p 50V Ceramic VCKYCZ1HB102KY C9701 Capacitor 0.1 10V Ceramic VCKYCZ1AB104KY C9702 Capacitor 0.1 25V Ceramic VCKYCY1EB104KY C9703 Capacitor 4.7 25V Ceramic RC-KZA178WJZZY C9704 Capacitor 4700p 25V Ceramic...
  • Page 97 TU-X1U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE760FE01(MAIN Unit) D9702 Diode 1SS355TE-17 VHD1SS355//-1Y D9703 Diode 1SS355TE-17 VHD1SS355//-1Y D9704 Diode 1SS355TE-17 VHD1SS355//-1Y D9705 Diode 1SS355TE-17 VHD1SS355//-1Y D9706 Zener Diode MAZ8140GML RH-EXA552WJZZY D9707 VHDD1FH3+++-1Y Diode D1FH3 D9708 Zener Diode MAZ8033GLL...
  • Page 98 TU-X1U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE760FE01(MAIN Unit) IC1606 IC PCA9517DP,118 VHiPCA9517+-1Y IC1607 IC PCA9517DP,118 VHiPCA9517+-1Y IC1701 IC SII9185ACTU VHiSii9185A-1Q IC1702 IC TC7WBD125AFK(T5L,F) VHiT7WB125A-1Y IC1703 IC S-24CS02AFJ-TB-G VHiS24CS02J-1Y IC1704 VHiS24CS02J-1Y IC S-24CS02AFJ-TB-G IC1705 IC TC7WBD125AFK(T5L,F) VHiT7WB125A-1Y...
  • Page 99 TU-X1U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE760FE01(MAIN Unit) L4604 Coil CILFA279WJ RCiLFA279WJZZY L4605 Coil CILFA279WJ RCiLFA279WJZZY L4606 Coil CILFA279WJ RCiLFA279WJZZY L4607 Coil CILFA279WJ RCiLFA279WJZZY L4608 Coil CILFA279WJ RCiLFA279WJZZY L4609 RCiLFA279WJZZY Coil CILFA279WJ L4610 Coil CILFA279WJ RCiLFA279WJZZY...
  • Page 100 TU-X1U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE760FE01(MAIN Unit) R1318 Resistor 47k 1/16W Metal Oxide VRS-CZ1JF473FY R1319 Resistor 4.7 1/16W Metal Oxide VRS-CZ1JF4R7JY R1320 Resistor 12k 1/16W Metal Oxide VRS-CZ1JF123FY R1321 Resistor 4.7 1/16W Metal Oxide VRS-CZ1JF4R7JY R1322 Resistor 4.7k 1/16W Metal Oxide...
  • Page 101 TU-X1U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE760FE01(MAIN Unit) R1630 Resistor 10 1/16W Metal Oxide VRS-CJ1JF100JY R1631 Resistor 330 1/16W Metal Oxide VRS-CZ1JF331JY R1632 Resistor 1k 1/16W Metal Oxide VRS-CZ1JF102JY R1633 Resistor 4.7k 1/16W Metal Oxide VRS-CZ1JF472JY...
  • Page 102 TU-X1U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE760FE01(MAIN Unit) R2025 Resistor 47k 1/16W Metal Oxide VRS-CZ1JF473JY R2026 Resistor 10k 1/16W Metal Oxide VRS-CZ1JF103JY R2028 Resistor 10k 1/16W Metal Oxide VRS-CZ1JF103JY R2029 Resistor 10 1/16W Metal Oxide VRS-CZ1JF100JY...
  • Page 103 TU-X1U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE760FE01(MAIN Unit) R2273 Resistor 0 1/16W Metal Oxide VRS-CZ1JF000JY R2279 Resistor 3.9k 1/16W Metal Oxide VRS-CZ1JF392JY R2280 Resistor 2k 1/16W Metal Oxide VRS-CZ1JF202JY R2305 Resistor 0 1/16W Metal Oxide VRS-CZ1JF000JY...
  • Page 104 TU-X1U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE760FE01(MAIN Unit) R4659 Resistor 4.7k 1/16W Metal Oxide VRS-CZ1JF472FY R4660 Resistor 100 1/16W Metal Oxide VRS-CZ1JF101FY R4681 Resistor 4.7k 1/32W Metal Composition VRK-SB1FF472JY R8002 Resistor 0 1/16W Metal Oxide VRS-CZ1JF000JY...
  • Page 105 TU-X1U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE760FE01(MAIN Unit) R8145 Resistor 4.7k 1/16W Metal Oxide VRS-CZ1JF472JY R8146 Resistor 4.7k 1/16W Metal Oxide VRS-CZ1JF472JY R8147 Resistor 4.7k 1/16W Metal Oxide VRS-CZ1JF472JY R8151 Resistor 22 1/32W Metal Composition VRK-SB1FF220JY...
  • Page 106 TU-X1U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE760FE01(MAIN Unit) R8234 Resistor 68 1/32W Metal Composition VRK-SB1FF680JY R8235 Resistor 68 1/32W Metal Composition VRK-SB1FF680JY R8236 Resistor 68 1/32W Metal Composition VRK-SB1FF680JY R8237 Resistor 68 1/32W Metal Composition VRK-SB1FF680JY...
  • Page 107 TU-X1U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE760FE01(MAIN Unit) R9517 Resistor 0 1/16W Metal Oxide VRS-CZ1JF000JY R9518 Resistor 3.9k 1/16W Metal Oxide VRS-CZ1JF392FY R9519 Resistor 47 1/16W Metal Oxide VRS-CZ1JF470JY R9520 Resistor 47 1/16W Metal Oxide VRS-CZ1JF470JY...
  • Page 108 TU-X1U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKE760FE01(MAIN Unit) SG1505 Spark Gap EZAEG2A50AX RH-VXA187WJQZY SG1506 Spark Gap EZAEG2A50AX RH-VXA187WJQZY SG1507 Spark Gap EZAEG2A50AX RH-VXA187WJQZY SG1508 Spark Gap EZAEG2A50AX RH-VXA187WJQZY SG1601 Spark Gap EZAEG2A50AX RH-VXA187WJQZY SG1602 RH-VXA187WJQZY Spark Gap EZAEG2A50AX...
  • Page 109 TU-X1U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [5] DUNTKE761FE01(TERMINAL Unit) D509 Diode PHOTODIODE VHPGPFM513T-1 FB501 Balun BLN-0067TA RBLN-0067TAZZY FB502 Balun BLN-0067TA RBLN-0067TAZZY FB503 Balun BLN-0067TA RBLN-0067TAZZY FB504 Balun BLN-0065TA RBLN-0065TAZZY FB505 RBLN-0065TAZZY Balun BLN-0065TA FB506 Balun BLN-0067TA RBLN-0067TAZZY...
  • Page 110 TU-X1U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [6] DUNTKE837FE01(SUB TERMINAL Unit) C610 Capacitor 56p 50V Ceramic VCCCCY1HH560JY C611 Capacitor 1 16V Ceramic VCKYTV1CB105KY C612 Capacitor 1 16V Ceramic VCKYTV1CB105KY C613 Capacitor 56p 50V Ceramic VCCCCY1HH560JY C614 Capacitor 1000p 50V Ceramic...
  • Page 111 TU-X1U [7] CABINET PARTS 3-10 3-13 2-10 3-14 3-11 2-11 3-11 2-10 3-14 3-12 3-14...
  • Page 112 TU-X1U PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [7] CABINET PARTS Top Cabinet Ass'y CCABAC188WJ02 Top Cabinet Not Available Caution Label TCAUZA345WJZZ Front Panel Ass'y CPNLCA245WJ01 Front Panel Not Available Door GDORFA223WJKB Door Decoration HDECAA035WJSA LED Decoration HDECQA943WJSA Indication Seat...
  • Page 113 TU-X1U [8] SUPPLIED ACCESSORIES Remote control unit (x1) “AAA” size battery (x2) AC cord (x1) HDMI cable fixture/ HDMI cable (x1) HDMI cable holder (x1) cushion (x1) Operation manual (x1) HDMI Clamp Transition Note Extended Warranty Card PRICE PART PARTS CODE...
  • Page 114 TU-X1U [9] PACKING PARTS PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [9] PACKING PARTS Packing Case SPAKCE440WJZZ Accessories Case SPAKFB681WJZZ Wrapping Paper SPAKPB179WJZZ Buffer Material SPAKXC161WJZZ Polyethylene bag SSAKA0170CEZZ No. Label TLABK0001TAZZ [10] SERVICE JIGS Extension Cable (PM) QCNW-H939WJQZ...
  • Page 115 TU-X1U 2008 2008 © COPYRIGHT XXXX BYSHARP CORPORATION ALL RIGHTS RESERVED. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.
