Sliding Gate Operator
User's Manual
D-FORCE1400VA

Advertisement

loading
Need help?

Need help?

Do you have a question about the D-FORCE1400VA and is the answer not in the manual?

Questions and answers

Summary of Contents for DIGITALas D-FORCE1400VA

  • Page 1 Sliding Gate Operator User's Manual D-FORCE1400VA...

  • Page 2: Products Introduction

    D-FORCE1400VA SLIDING GATE OPERATOR 1. Products introduction Please read the instructions carefully before proceeding. MCU is supplied to control the gate operator. Keypad / single button interface. Have Infrared safety sensor interface. Soft start and soft stop function and the soft stop width are adjustable.
  • Page 3 D-FORCE1400VA SLIDING GATE OPERATOR operate the gate manually.  The operator should be switched off before repairing it or opening its cover. Please erase and reprogram the transmitter code after installing the  operator. Make sure the Power supply (AC220V or AC110V) of the gate operator is suitable for the power supply in your area.

  • Page 4: Mechanical Installation

    14m/20m if the proper installation procedures have been followed. The D-FORCE1400VA gate operator operates by forcing a drive rack by a drive gear. The entire configuration is shown in the diagram below. The gate operator must be installed on the inside of the gate.
  • Page 5 D-FORCE1400VA SLIDING GATE OPERATOR damage can result from contact with any rough or sharp part. Concrete p ad The base unit of the gate operator requires a concrete pad in order to maintain proper stability. The concrete pad should be approximately 450mm x 300mm x 200mm deep in order to providing for adequate weight and structure to insure proper stable installation.
  • Page 6 D-FORCE1400VA SLIDING GATE OPERATOR Fig.3 Installation of Rack  Fix the three nuts (in the same package with rack) on the rack element.  Lay the first piece of rack on the gear and weld the first nut on the gate.
  • Page 7 D-FORCE1400VA SLIDING GATE OPERATOR Fig.4 5. Adjustment Spring limit switch  To ensure safety, it is recommended to install limit switches at both ends of the gate to prevent the gate from sliding out of the rails. The rails must be installed horizontally.
  • Page 8 D-FORCE1400VA SLIDING GATE OPERATOR Magnetic limit switch  To ensure safety, it is recommended to install limit switches at both ends of the gate to prevent the gate from sliding out of the rails. The rails must be installed horizontally.
  • Page 9 D-FORCE1400VA SLIDING GATE OPERATOR Sliding gate Magnetic Limit block Rack Gear Magnetic limit Fig.5 M6X10 Spring limit Magnetic limit Fig.6 Manual operation In case of power failure use release key unlock the lock (clockwise is unlock, and counterclockwise is lock).
  • Page 10 D-FORCE1400VA SLIDING GATE OPERATOR  Remove the cover of the release.  Fit the supplied release key in the lock.  Turn the release key 2-3 circles clockwise unlock the output gear. Open and close the gate manually.  Note: If the gate bumps the mounting post and cannot be electric opened, move the gate a few inches by hand, thus you can release the gate with the key, open and close the gate manually.
  • Page 11 D-FORCE1400VA SLIDING GATE OPERATOR Learn button Open limit Limit swtich Close limit Loop detector GND/COM Infared sensor +12VDC Pedestrian switch O/S/C switch Capacitor Extral button switch MOT1 MOTOR MOT2 Caution light Protect Earth VDR1 POWER Fig.8 Wiring notes of control board Power Input (terminal J3): PE (Earth),L (Live),N (Neutral).
  • Page 12 D-FORCE1400VA SLIDING GATE OPERATOR D-FORCE1400VA: AC220V D-FORCE1400VAU: AC110V Output power supply: 12VDC(7 of J5), COM (9 of J5), I.R. (8 of J5 is N.C Infrared) If the infrared beam is interrupted during closing, the gate will reverse and open immediately. The product is not factory equipped with an infrared device;...
  • Page 13 D-FORCE1400VA SLIDING GATE OPERATOR switch to ‘4(COM)’. terminal J2 terminal J2 Keypad Stop Open Single-button switch Close or keypad Three-button Control board Control board switch terminal block terminal block Fig.10A Pedestrian switch Connect pedestrian switch wire to 4 and 6 terminal of J2. press the switch the door will open 1 meter when the door is closed.
  • Page 14 D-FORCE1400VA SLIDING GATE OPERATOR terminal J4 Terminal J6 Capacitor Mot1 Mot2 Control Control board board terminal block Fig.11 f. Loop detector interface Connect wire see the Fig.11A terminal J2 detector LOOP output Loop detector Control board terminal block Fig.11A The car through the loop the door will close itself when the door opened.
  • Page 15 D-FORCE1400VA SLIDING GATE OPERATOR 7. Tuning and operation a. Adjust the Adjustable resistance (see Fig.8) VR1: For motor working total time adjustment. Clockwise rotation to increase, counter-clockwise rotation to reduce. The to tal time can be set to 10 seconds as minimum and 90 seconds as maximum.
  • Page 16 D-FORCE1400VA SLIDING GATE OPERATOR button 2 too, the button 2 and button 4 are enable, the button 1 is disable. Button 1 Button 2 Button 3 Button 4 Fig.12 Remote transmitter  Adding extra remote controls (Learn): Remove the cover, press and hold the learn button ‘S1’...
  • Page 17 D-FORCE1400VA SLIDING GATE OPERATOR 8. Programming Process Adjust the DIP switch（ see Fig13B and table 1 ） Fig. 13A Fig.13B...
  • Page 18 D-FORCE1400VA SLIDING GATE OPERATOR 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 Fig. 13C Fig. 13D Table 1: DIP switch adjust DIP-switch Function SET No soft start mode (see Fig.13A) Soft start mode(need to power on reset).
  • Page 19 D-FORCE1400VA SLIDING GATE OPERATOR N.C. limit switch(spring limit) (see Fig.13B) N.O. limit switch(magnetic limit) When the 3 and 4 all OFF, the Auto-close function is disable. When the 3 OFF and the 4 is ON, auto-close time is near 12 (see Fig.13C)
  • Page 20 D-FORCE1400VA SLIDING GATE OPERATOR With each press of the button, the gate will close, stop, open or stop cycle.  Auto-close function: This feature can be selected to make the gate stay open for some seconds before it automatically closes. The auto- close time can be adjusted to between 12, 24 and 36 seconds.

  • Page 21: Troubleshooting

    D-FORCE1400VA SLIDING GATE OPERATOR pressed the LED will light. LED 5 indicate the ‘O/S/C’ external button, if the button is pressed the LED will light. LED 6 indicate the ‘pedestrian switch’ external button, if the button is pressed the LED will light.
  • Page 22 D-FORCE1400VA SLIDING GATE OPERATOR The door fails to 1. Power is OFF 1. Make sure that open and close. 2. Fuse burn power is ON. LED display 2. Replace fuse. does not light. The door can 1. Infrared beam is 1.
  • Page 23 D-FORCE1400VA SLIDING GATE OPERATOR 12. Packing list After receiving the gate operator, you should make an unpack-inspection, in which you should check whether the product was damaged. If you have any problem please contact our dealer. You should find the following items...
