- Page 1 Frame User Manual...
- Page 2 Operating Manual Thank you for purchasing this Signi Fires product. Signi Fires is very safety conscious, we have taken every care in designing, manufacturing and assembling your Signi Fires Frame to ensure it operates effectively, efficiently and safely. In return we ask that you exercise care when using and installing this product and follow the instructions provided.
-
Page 3: Content Of Packaging
Installation Manual - qty 1 NOTE: Signi Fires does not supply the wall fixings for the Hanger Bracket to be fitted to the wall because these fixings may need to vary depending on the material that the wall is made of. Please consult your local building regulations or hardware specialist if you are... - Page 4 77,25kg * Please note the weight of the Frame including the Slimline Burner indicated here is the weight of the burner once filled with fuel. Be sure that the fixings used will compensate for at least this plus, 25% to be safe.
- Page 5 The Frame is not intended to be Built-In, it is designed to be mounted onto a surface as indicated in this manual. There are other Slimline Burner Products available in the Signi...
-
Page 6: Installation Procedure
The Frame may not be mounted in a room made of a highly combustible material. Do not cover any of the vents (top, bottom or back) of the Wall Box of the Frame. Never place anything on top of the Frame. - Page 7 Perspective of Frame Exploded Step 1: After selecting an appropriate position for the Frame to be located, mark out and fasten the Wall Hanger Bracket to the wall. Slot for Wall Fixing NOTE: After hooking the Wall Box onto the Wall Hanger Bracket (Step 2), make sure that the Safety Clips (image below) supplied are fitted into the appropriate holes to prevent the Wall Box from accidentally becoming dislodged when the flame is burning.
- Page 8 Step 2: Once the Wall Hanger Bracket is secured to the wall, hook the Wall Box onto the Wall Hanger Bracket and secure in place with the Safety Clips. Facia Assembly Clips Wall Hanger Bracket with Safety Clips in place (both ends).
-
Page 9: Cleaning And Maintenance
Step 4: All that's left to do now is to hook the Fascia onto the Wall Box by aligning the four holes in the back of the fascia with the four hooks (Fascia assembly clips)on the front of the wall box. - Page 10 Purchaser to Signi Fires of any such defect or fault in the product as soon as the Purchaser becomes aware of that fault or defect. All warranty claims must be returned to Signi Fires for assessment with a receipt or other proof of payment.
- Page 12 QC Checklist Components Wall hanger bracket 1 of …..…..……………... Wall box 1 of ………….......... Burner tray 1 of ………………………………………. Manual 1 of…………………………………………… Safety clips 2 of ……………………………………... Checked by…………………………………………. www.signifires.com...
