Yudor YDS-1621HF User Manual

16ch tribrid dvr
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

User Manual

16CH Tribrid DVR
V1.0.2_1608
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YDS-1621HF and is the answer not in the manual?

Questions and answers

Related Manuals for Yudor YDS-1621HF

Summary of Contents for Yudor YDS-1621HF

  • Page 1: User Manual

    User Manual 16CH Tribrid DVR V1.0.2_1608...

  • Page 2: Fcc Compliance

    FCC Compliance USER-INSTALLER CAUTION: YOUR AUTHORITY TO OPERATE THIS FCC VERIFIED EQUIPMENT COULD BE VOIDED IF YOU MAKE CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE TO PART 15 OF THE FCC RULES. NOTE: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.

  • Page 3: Table Of Contents

    16CH Tribrid DVR i. WARNINGS, CAUTIONS AND COPYRIGHT..........4 ii. PRODUCT SPECIFICATIONS.................5 iii. HARDWARE OVERVIEW................9 iv. NETWORK CONFIGURATION..............12 v. SETUP MENU....................16 * LIVE VIDEO ..................16 * CAMERA SETUP ..................23 * RECORD SETUP ...................37 * ALARM SETUP ..................42 * NETWORK SETUP .................48 * USER SETUP ……..................57 * DISK MANAGEMENT ................60 * SYSTEM SETUP ..................63...

  • Page 4: Warnings, Cautions And Copyright

    i. WARNINGS, CAUTIONS AND COPYRIGHT WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS. CAUTION CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.

  • Page 5: Product Specifications

    ii. PRODUCT SPECIFICATIONS A. Features:  Support up to 16-channel 1080P & 720P aHD cameras input.  Support up to 16-channel 1080P TVI cameras input.  Support up to 16-channel Analog cameras input.  Support up to 4-channel IP cameras input. ...
  • Page 6 Ethernet RJ-45, 10/100/1000 Mbps x1 Front : USB 2.0 x2 GPIO Alarm in x4, Relay out x1, RS485 Power DC12V, 5A Video and Audio IP Cam Video Input Max 4 channels IP Cam Resolution Up to 2 Megapixel IP Cam Frame rate Up to 30 FPS @ NTSC per CH Analog Video Input Max 16 channels...
  • Page 7 Search Method Date / Time / Event Date/ Time / Event Search Selectable on the calendar Log Search Through the log data to find the video event / time Fast Forward X 2 X8 X 16 X32 X64 Picture by picture Playback Playback Speed Pause Fast Backward...
  • Page 8 External USB Backup USB x2 Device Networking Type Static/ DHCP/ PPPoE/DDNS Environment Operating Temperature -10~55°C / 14~131°F Humidity 0~80% RH (non-condensing) Language English / Traditional Chinese / Simple Chinese / Russian / Italian Type / Japanese / Czech / France / Germany / Spanish / Portuguese Physical Color Black...

  • Page 9: Hardware Overview

    iii. HARDWARE OVERVIEW 1. Connectors A. FRONT PANEL 11 12 LABEL OPERATION IR Sensor For Remote Control. Led Indicator USB Connector/ USB Mouse Connector MIC IN Microphone input(Phone Jack) B. BACK PANEL LABEL OPERATION eSATA eSATA input...
  • Page 10 VGA OUT VGA Output MONITOR OUT Monitor display output AUDIO OUT Audio output DC 12V Power adapter (DC 12V/5A) connector HDMI HDMI video output Ethernet RJ-45 connector Alarm in x4, Relay out x1 Audio In Audio input Video In BNC video input 2.
  • Page 11 red circles. When installing several HDD, data cables on the main board to the the screws in blue circle can be loosen HDD. and the holder can be moved in order to put the HDD more smoothly. 7 Put back the cover and lock all the screws. * For a detailed Hard Disk Compatible Table, please refer to the attached User Manual.

  • Page 12: Network Configuration

    iv. NETWORK CONFIGURATION 1. ALARM TRIGGERING There are four types of alarms: Motion detection, Video Loss Alarm, External Alarm, and Digital Input from Camera. The following are the possible actions when the alarm is triggered. Every action is configurable (Ex. the screen display pattern, the relay triggered time.etc) and will be explained in the later chapter.
  • Page 13 d. The pre/ post-alarm recording video can be sent to e-mail/ uploaded to FTP. C. When Video Loss Alarm occurs: a. The external relay/ built-in buzzer can be triggered. b. Alarm time point can be recorded in the event list, and you can search for the event in playback.
  • Page 14 EX1：Connect GND & Alarm to external IR detector. EX2：Connect N.O & COM to external siren. 3. PTZ (PAN, TILT AND ZOOM) CAMERA The following diagram shows the connection between the DVR and a PTZ camera & joystick controller. To control the PTZ camera via DVR please check the CAMERA ID, BANDRATE (default at 9600 bps) and the RS-485 cable.

  • Page 16: Setup Menu

    SETUP MENU * LIVE VIDEO LIVE VIEWING AND POP-UP MENU If you cannot see the side control menu bar, move the mouse cursor to the right side of the display screen to make it appear. It is usually set as displayed at default.
  • Page 17 A. PLUG & PLAY When you turn on the machine for the first time or one of the IP addresses are set ENABLE:OFF, the system will ask you for assigning an IP address to the IP Cameras for getting automatic connection. The system will check addresses from 192.168.X.50, with X being the DVR LAN.
  • Page 18 B. GUI MENU BAR C. AUTO SWAP Click it to start switch dwell for single live view. The interval duration depends on IP Camera settings at “Image Setup”. On split screen, the switch dwell interval is 5 sec. D. DISPLAY CONTROL On Live-viewing and Playback modes, switch the camera channels with display control icons.
  • Page 19 After pressing the minimization icon, the control panel becomes smaller: When moving the mouse the arrow will follow the mouse and change direction. On this mode the user can click on the live view to control direction instead of using the direction key on the control panel. If a fisheye camera is connected: PTZ Steps: (1) Select the channel number you want to setup.
  • Page 20 (2) Select the View Mode, 360 degrees or 180 degrees. (3) Select the camera location: ceiling, desk, or wall. (4) Select the split screen pattern: : 360 degree panorama view + sub screens x4 : 180 degree flat view + sub screens x2 : sub screens x4 (5) After you set the screen pattern, use the fisheye channel list to select one of the sub screens.
  • Page 21 I. RECORD AND PLAYBACK CONTROL The same as the front panel controller. J. Lock Control Tick off the box under ‘Lock’ to view the camera channels in Split Screen Mode or Single Screen Mode without the interface of menu bar aside. To make the menu bar appear again, simply move your mouse cursor on the right so the menu bar will pop up.
  • Page 22 Record mode: Manual – Stop Recording Record mode: Schedule – FULL REC period Record mode: Manual – Recording M. FAST SWITCH Whether you are on Split Screen mode or Single Screen Mode, right click on the mouse to display a list all channels. Move your mouse cursor up and down to select on the desired channel you would like to view.

  • Page 23: Camera Setup

    * CAMERA SETUP Click to enter the administration page. Click to exit & return to live video page. Click to enter the camera setup page.
  • Page 24 A. CAMERA SETUP Assign different types of cameras to be displayed on different channels. Select your camera type from Select Camera Type drop down list, either IP-CAM or FHD-CAM for each channel based on the camera type which is currently connected. a.
  • Page 25 The IP Cam has to be under the same LAN with DVR in order to be successfully connected. For instance, if the DVR IP address is 192.168.10.33, the IP Cam IP address should be 192.168.10.X. You can edit the IP address of the IP Cam by clicking Edit. Click Save to confirm the change.
  • Page 26 a-3. ONVIF Mode The camera device supports connection under the service of ONVIF protocol, but does not support PTZ functions. a-4. RSTP Mode The DVR only supports IP address indication, live video, and video recording under RTSP Mode. Other functions like motion detection are not supported.
  • Page 27 Note: When you select RTSP mode, make sure the sub-stream resolution of camera is VGA (640x480), otherwise you will receive a warning message when you try to connect to the camera: Examples of some RTSP settings: RTSP Path 1 RTSP Path 2 Result (IP Cam Main (IP Cam Sub...
  • Page 28 640 x 480 (Fill in nothing DVR takes a 640x480 streaming for both single on "RTSP Path channel view mode and split screen mode. 1") 640 X480 1920 x 1080 DVR takes 1920x1080 streaming for single channel view, and 640x480 streaming for split screen.
  • Page 29 1. Enable: Choose “Attached”. 2. Attached Channel: Assign a normal/ RTSP IP camera channel. 3. Ratio: Adjust the zoom ratio with left and right arrows, and click on the red frame to drag it to the area where you want to show on the live view. b.
  • Page 30 For H.264 IP Cams, less than 1 Megapixel, the resolution options include ”Best, High, Standard, Medium, Low”. For MPEG IP Cams, the resolution options support “Standard, Medium, Low”. (The highest resolution option is “standard” due to the chip performance limits of IP Cam) For FHD (analog) Cams, the resolution ranges are “Best, High, Standard, Medium, Low”.
  • Page 31 C5. Brightness Press ◄ or ► to change contrast level. The adjustment value for IP camera is between 0~31, for FHD (analog) cam is between 0~255. C6. Hue Press ◄ or ► to change contrast level. The adjustment value for IP camera is between 0~31, for FHD (analog) cam is between 0~255.
  • Page 32 D. Motion Setup Page for IP Camera Setup Page for FHD Camera D1. Relay Dwell Press ◄ or ► to change the relay time or disable the relay function. D2. Buzzer Dwell Press ◄ or ► to change the buzzer time or disable the buzzer function. D3.
  • Page 33 Select “Exit With Saving” to complete your option. Select “Enable All” to enable the whole area for motion detection. Select “Clean All” to clean the area of the current color in the view. Select “Exit Without Saving” to go back to motion setup menu without saving any change.
  • Page 34 For IP Camera E1. Area1 / 2 / 3 Tick the “Area1/2/3” box and click “Area Setup”. Start dragging your masked areas in blue, green by clicking your mouse anywhere on the viewing screen. The pictures below show how all 3 different areas are set within 3 different frames.
  • Page 35 Note: The user can only set up 1 area under 1 Area Setup mode. In this case, the user can only drag the blue frame. If the user wishes to set up other frames, they need to choose Exit With/Without Saving from the mini menu and set up other frames by clicking on other Area Setup buttons.
  • Page 36 F. Audio Setup If the channel is ticked the sound from camera will be recorded into the playback video. On the contrary, no sound will be recorded in the playback video of the channel which is not ticked. Note: Audio is only supported up to 4 channels. G.

  • Page 37: Record Setup

    * RECORD SETUP Click to enter the administration page. Click to exit & return to live video page. Click to enter the record setup page.
  • Page 38 A. Pre-Alarm Record Time /Post-Alarm Record Time Pre-alarm record means the recording before the alarm is triggered; the post-alarm record means the recording after the alarm is triggered. If you set 5 sec for pre-alarm and 5 sec for post-alarm, the alarm recording length will be total 10 sec.
  • Page 39 C1. Manual: Click to start recording or to stop recording on the side menu. C2. Schedule: Click on the drop down list from the Record Mode on the right, and select Schedule. There will be three Setup options popping up: Schedule Setup, Mail Schedule Setup, and FTP Schedule Setup.
  • Page 40 2a. Schedule Setup: Click the tag “FULL REC”(Red) / “ALARM REC”(Yellow) / “NO REC”(Green), and then draw on the calendar. The recording type will follow the schedule. The tag “ALARM REC” includes all the alarm types.  Tip: You can select a whole row of grids by clicking on the title of the day or hour.
  • Page 41 The tag “ALARM” refers to both external alarm and DI from camera. 2c. FTP Schedule Setup: Select the time fort the recorded video to be uploaded to FTP. No file will be uploaded during “NO MAIL” time period even when motion detection is triggered.

  • Page 42: Alarm Setup

    * ALARM SETUP Click to enter the administration page. Click to exit & return to live video page. Click to enter the alarm setup page.
  • Page 43 A. Alarm Trigger Setup A-1. Alarm Auto Switch Click the drop down list to operate the Alarm Auto Switch. When the alarm is triggered, the screen will be switched to Full Screen, Split Screen or Disable. A-2. Video Loss Detect Choose Enable/Disable from the drop down list to switch on/off the function.
  • Page 44 storage device gets overheated Set the temperature limit between 55~70 . B. Alarm Output Setup This control item is divided in two parts, “Buzzer Time” and “Relay Time”. The user can hold ◄ or ► sign on the screen with the mouse to set the external buzzer time and video loss buzzer time in “Buzzer Time”...
  • Page 45 replayed in the playback list. D. Alarm Action and Trigger Condition List Action \ Type Motion detection External Alarm DI (IP CAM) Video Loss Necessary Condition Alarm Setup Alarm Setup Alarm Setup >>Alarm Camera Setup >>Motion >>Alarm Trigger >>Alarm Trigger (All the actions below Trigger Setup >>"Ext.
  • Page 46 Action \ Type Motion detection External Alarm DI (IP CAM) Video Loss Pre- / Post-alarm Pre-:O Post-:X Recording Condition 1: Network Setup >>Mail(/FTP) Setup >>Tick "Motion(/Alarm)"; And Record Setup >>"Record Mode" set to "Manual"; And it's on recording when alarm is triggered Condition 2: Network Setup >>Mail(/FTP) Setup >>Tick "Motion(/Alarm)";...
  • Page 47 conditions are met. E. External Alarm CH Setup You can assign external alarms to different channel(s) depending on the type of NVR which supports the external alarm device, Hold ◄ or ► sign on the screen with the mouse to shift channels.

  • Page 48: Network Setup

    * NETWORK SETUP Click to enter the administration page. Click to exit & return to live video page. Click to enter the network setup page. A. IP ADDRESS SETUP...
  • Page 49 A-1. IP Mode Press drop down list to change IP mode to Static IP or DHCP. A-2. IP Address Set the DVR IP Address. A-3. NetMask Set the subnet mask which is usually set to 255.255.255.0. A-4. Gateway Set DVR gateway. A-5.
  • Page 50 Press the drop down list to enable or disable PPPoE. B-2. User Name Enter the user name (ADSL account) which provided from local ISP. B-3. Password Enter the password which provided from local ISP. B-4. re-Password Enter the password again to confirm the password. B-5.
  • Page 51 Type-in the registered host name in the selected provider. C-4. User Name Type-in the registered user name in the selected provider. C-5. Password Type-in the registered password in the selected provider. C-6. Update Interval To set a period of time to update IP address. C-7.
  • Page 52 D-1a. Alarm / Motion A video notification will be sent via email for Alarm-in and/or Motion detection D-1b. Power On A notification will be sent via email when the DVR starts or reboots. D-1c. Start Record A notification will be sent via email when the DVR starts recording. D-1d.
  • Page 53 D-6. Sender’s Mail The sender’s account when send the mail via this mail server. D-7. Receiver’s Mail The receiver’s mail address. D-8. BCC Mail The receiver’s mail address for Bcc Mail. D-9. Subject The subject of the mail. D-10. Secure Connection Tick the box to choose between SSL or TSL connection.
  • Page 54 E-5. FTP Port The port number of file transmission. (Default value is 21) E-6. Path The FTP path where the user wants to save the information. F. DHCP Server Setup F-1. Enable Use the checkbox to enable or disable the DHCP Server function. When the function is activated, the DVR can be act as the DHCP server.
  • Page 55 G. UPNP Port Forwarding Setup G-1. Enable Use the checkbox to enable or disable UPNP port setup. G-2. External HTTP Port Use the virtual keypad to insert the external http port. G-3. External RTSP Port Use the virtual keypad to insert the external RTSP port. H.
  • Page 56 I. Connection Status Click on the Connection Status button to browse through details of your connection status. You may consider how you want to set up your streaming mode by acquiring information provided here.

  • Page 57: User Setup

    * USER SETUP Click to enter the administration page. Click to exit & return to live video page. Click to enter the user setup page.
  • Page 58 A. HDD Format Check User Password Tick the checkbox to enable/disable the HDD Format function. After it is enabled, the user has to enter the password before performing the HDD formatting. B. Anonymous User Login Tick the checkbox to enable/disable the anonymous user login which allows the user to view live image via IE browser without entering the username/ password.
  • Page 59 F-1. Add User After clicking on the Add User button, a User Management page (in this case, it is for User No.2) will appear. The administrator can distribute the authority and the permission settings for the new user. F-2. Permission Clicking on the Permission button alongside any particular user will also direct you to the User Management page where you can modify and alter the authority settings for any...

  • Page 60: Disk Management

    * DISK MANAGEMENT Click to enter the administration page. Click to exit & return to live video page. Click to enter the system setup page.
  • Page 61 Overwrite Mode Select “ON” for the oldest recording data to be overwritten by new recording data. Select “OFF” for the DVR to stop writing data into HDD when its space is full. Hard Disk Full Warning Under non-overwrite mode, click the drop down list to change value to 20%/15%/10% or 5%.
  • Page 62 Your Hard Disk Device needs to be replaced if its health condition is displayed in yellow or red. G. Format HDD Enter the administrator name and password to proceed formatting the HDD.

  • Page 63: System Setup

    * SYSTEM SETUP Click to enter the administration page. Click to exit & return to live video page. Click to enter the system setup page.
  • Page 64 A. System Name Use the virtual keypad to enter the name of the DVR. B. System ID Use ◄ or ► to setup the DVR ID. The adjustment value is between 0~32. C. Language Use the drop down list to change the DVR language system. Currently, there are 18 types of different languages available.
  • Page 65 Have your firmware file ready in a USB hard drive, and insert it unto the DVR USB connector for upgrading. Press Start to Upgrade Firmware to proceed. H. Configure Setup Click the checkbox to select which item to be setup by the user. The user can also load settings to factory default, or load and back up the configuration from USB.
  • Page 66 J. Day Light Saving Time After enabling the daylight saving time function, the user can use the drop down list to select the start time and the end time of daylight saving time. After complete the setting, please click Save button to save the settings.
  • Page 67 The Resolution can be adjusted. Please check the frame rate which your LCD monitor supports before any adjustment. If you select a resolution not compatible with the LCD monitor, the system will automatically undo the recent changes. M. IPcam Search Setup If System Start is ticked, the DVR will activate the PLUG &...

  • Page 68: Hdd Playback

    HDD PLAYBACK 1. ENTERING THE PLAYBACK MENU On the side menu control bar, click icon to enter Playback mode. There will be a window popping up at the center screen. Click on icon to enter Time Search page where you can see the time frame of your recorded video.
  • Page 69 Click on button to enter the Playback page. Note: In playback mode, the sound output is only enabled on full screen mode. 2. THE PLAYBACK FUNCTIONS A. RECORD BACKUP On playback mode, press this button to backup recording (.da0 video) to the USB disk .Press this button again to finish the backup.
  • Page 70 D. DIGITAL ZOOM On live full screen mode, left-click to select a zoom-in or zoom-out range for the image. The users can right-click to disable this function. (NOTE: the image can be zoomed-in to max. 16x.) E. RECORD & PLAYBACK CONTROL Click on different icons to perform rewind, fast forward in different speeds, pause and play.
  • Page 71 The screen will display the recorded data of the playback video. Notice on the top left of the replay video, there is a ‘DRAW’ label. label informs the user that the system is now ready to launch an area of smart search, defined by the square which the user draws with the mouse.
  • Page 72 Once the Smart Search starts, the replay video will go fast-forward until any motion is detected within the detection box. There is also a bar at the bottom of the monitoring screen called the Detection Threshold Meter. By adjusting the pointer in the middle of the bar you are able to adjust the detection level of the smart search.

  • Page 73: Time Search

    G2. Smart Event Search: Users will be able to check on the event by clicking on ’Smart Event Search’ to check on the motion detected from the Smart Search. 3. TIME SEARCH Select the start of the playback time and then click the button to playback the recorded data.

  • Page 74: Event Search

    4. EVENT SEARCH After entry to the event search page, the user can click on the event log item which is shown on the list to start playback. Move the mouse cursor to highlight upon the event. Moreover, the user could click the Event Condition button to enter a list of events and select specific types to be included for being recorded on the video.

  • Page 75: System Log

    After you click ◄ or ► to set starting time and ending time for backup, the DVR will display the Backup Size for your information to prevent overloading. You may also tick boxes to select channels in Select Channel for managing the backup. Once you have confirmed all the settings, click Backup button to proceed.

  • Page 76: Pc Remote Access

    vii. PC REMOTE ACCESS * PC SITE SETUP SYSTEM REQUIREMENT SUGGESTED REQUIREMENT CPU: Intel Celeron 1.6G CPU: Intel P4 2.8G MEMORY: 256MB. MEMORY:512MB or above VGA: 32MB VGA: 64MB or above VGA RESOLUTION: 1024 x 768. VGA RESOLUTION:1024 x 768 OS: Windows XP / 2000 OS: Windows XP / 2000 NETWORK BANDWIDTH: Upload Speed is...

  • Page 77: Internet Settings

    Then, the IPScannerEng.exe will popup. The DVR default IP address is 192.168.1.220 NOTE: Please input correct network parameters without blank spaces. On “Device Lists”, the software lists all servers. By clicking on the server the IP settings will be show on the right side. After editing the parameters and clicking on “Submit”, the following dialogue box will popup.
  • Page 78 A. Security  Custom Level  Security Settings  Download unsigned ActiveX controls  Enable or Prompt (recommended). B. Security  Custom Level  Security Settings  Initialize and script ActiveX controls not marked as safe  Enable or Prompt (recommended).
  • Page 79 Please click "YES" to proceed. OPTION 2: ADD TO TRUSTED SITES Control Panel  Internet Options  Security  Trusted sites  Sites 3. LOGIN A. INSTALL ACTIVEX Choose ‘Allow’, Then choose ‘Install’.
  • Page 80 B. START INSTALL ACTIVEX C. ACCOUNT & PASSWORD LOGIN After the IP setup and connecting to the network or LAN; type directly the IP address on the IE Browser directly. The following User name & Password Login window will popup. Default user name: admin Default...

  • Page 81: Remote Playback

    * REMOTE PLAYBACK 1. MAIN SCREEN SETTING (D6 Viewer) D6Viewer.exe is used for playing the DVR backup video. It can be obtained via the Internet or from the CD files; or you can simply obtain it by performing USB backup and DVD-RW backup operation, because the software will be created within the USB device right away.
  • Page 82 B. HDD PLAY Reading the DVR HDD from PC may not be possible since the DVR HDD is in Linux format, so you need “Ext2Fsd” to assign a drive letter to the HD. You can find it in the attached CD or download it from Internet.
  • Page 83 Under HDD Play mode, select the DVR HDD to load the video files inside. C. File Play You can open a single video backup file, select "File->File Play”. Then “Open".
  • Page 84 Choose the path the .haX file reserved and pick the file to playback. Press the play icon to play the video or pause picture.

  • Page 85: Playback Operation

    2. PLAYBACK OPERATION A. TIME SEARCH Select the Date and Time and then click to play the video. B. EVENT SEARCH After pressing the button, it will display all the events which are saved within the DVR HDD (Shown in the following image). C.
  • Page 86 D. ZOOM Tick the “Zoom” box and drag an area on the screen, then click the area to zoom in.
  • Page 87 E. BACKUP FILE TO MKV OR AVI FORMAT There are two types of video formats: MKV and AVI. With AVI file, you can choose to either include Time Stamp and Audio or not. After double-clicking on one specific channel display image, the ‘File Convert’...
  • Page 88 A window will pop up. Enter a file name and edit the file path directory. While the converting is in process, you may press the button to pause at any time before it is completed.

  • Page 89: Remote Control

    * REMOTE CONTROL Open the IP Scanner, and double-click on the DVR name. The remote control brower will soon appear on your PC screen and gain access to your camera live view through the DVR. 1. Live Viewing DVR Configuration Playback Control Screen Format System Time...
  • Page 90 A. PTZ Control PTZ control function panel Viewing Direction control in/out Zoom Auto Pan: start/pause Preset Point Setup Select different streaming B. DVR Configuration Users can adjust the Language setting, and shift interface for controlling options by clicking on Live View and Settings. Read 2.
  • Page 91 Save button to select the path for saving the backup file on the PC, or click Stop to pause recording. The backup file will be named after the time which starts the backup. For instance, (09162014133255.ha0) means 09/16/2014 13:32:55. G. Playback Control Click the button for the Playback Window to appear.
  • Page 92 or simply click All Event Search to browse through all the events in the video recording. H. OTHER FUNCTIONS Click on any channel with the mouse right button. The following menu will pop up: H1. Snapshot Save a single picture from the image. H2.
  • Page 93 H4. Zoom In Drag out a square from the channel screen you would like to zoom in with your mouse. icon will show up when placing your mouse cursor within the green frame, indicating it is ready to zoom in. Click the left mouse button to specify the zoom-in area.
  • Page 94 2. CONFIGURE A. System A1. Information System Information DVR Name: This name of the DVR will be shown on the IP Scanner. MAC Address: It is permanent for the DVR and cannot be revised. NTP Setting Time Zone: The time zone can only be modified on local DVR. NTP Server: The NTP Server IP address can only be modified on local DVR.
  • Page 95 ◎Automatic Uninstall Please follow the steps: 1. After updating the DVR firmware, close the web browser. 2. Run the file "unreg" in the CD to automatically remove the existing ActiveX component "WATCH_16R" from your PC. 3. Log in the DVR via web browser again, and the browser will require you to install the new version of ActiveX control.
  • Page 96 Load Setup from Default: Click “Apply” to reset the machine and revert all setting back to default value. Load Setup from: Click “Browse” to choose a file. You can load setup from your computer if you ever clicked “Download” and saved the settings before.
  • Page 97 DVR ID: The ID is used for distinguishing DVRs with a remote controller or RS485. Enter a different ID when you are operating several DVRs at the same time. Date Format: Select a format of date display. A-6. Monitor Adjust Monitor Resolution: Check the frame rate which your LCD monitor supports before the adjustment.
  • Page 98 HDD Format Password Check: Enable the option so the DVR will ask for password when users want to format HDD. Anonymous Login: Enable the option, then user can access the DVR via web browser and watch live screen without password. Disable the function so entering password is necessary to access the DVR.
  • Page 99 C. Camera C-1. Camera Setup FHD/Analog Camera: After connecting the FHD/analog camera to DVR, select “FHD/Analog Camera” to the corresponding channel. IP Camera, Normal Mode: Under Normal mode, Http protocol is used to access camera. You can key in IP address, port, username, and password manually. You can click IP Installer button to scan the LAN and find cameras being connected: Click “Edit”...
  • Page 100 FHD/Analog Camera: IP Camera: You may refer the rest of the settings to chapter CAMERA SETUP C-3. Image Setup Adjust image contrast, brightness, hue, saturation, and sharpness here. “Dwell Time” means the swap interval when performing swap on single channel screen. FHD/Analog Camera:...
  • Page 101 IP Camera: C-4. Motion Setup FHD/Analog Camera: Enable motion function, and drag on the screen the motion area. When motion is detected in the area, the alarm will be triggered and action will be executed. Relay Dwell: The value determines the relay triggering time when motion detection happens.
  • Page 102 IP Camera: The functions are all the same as the FHD/analog camera except that you can setup three areas for motion detection. C-5. Mask FHD / Analog Camera: Enable mask function, and drag areas to mask on the screen. Decide the mask color which the area will be covered with on live screen and playback video.
  • Page 103 IP Camera: Enable mask function, and drag on the screen the mask area. You can setup three mask areas which will be displayed in black on live screen and playback video. C-6. Audio Select the channel, and enable or disable the audio recording. No sound will be recorded in the playback video of the channel that audio setup is not enabled.
  • Page 104 Alarm Recording Time: When an event happens, the DVR can record the video at event time-point, and send it to mail or FTP. Adjust the recording video length. Mobile Record: Enable it, and DVR will record the streaming for mobile viewing, so that you can view playback video on mobile phone.
  • Page 105 HDD Temp. Warning: Enable it to make DVR alarm when the HDD temperature is higher than the temperature the user sets. Adjust HDD Temp. Limit Value below. Alarm Auto Switch: Select to switch to split screen or single channel when motion detection happens.
  • Page 106 E. Network E-1. IP Address IP Setup: Set up the DVR IP information. Select DHCP to get IP address from DHCP server or Static to fill in the IP address manually. UPnP Port Forwarding: When the DVR is under a router, you can use port forwarding to allow the WAN connection.
  • Page 107 E-3. DDNS Some DDNS provider requires users to apply for an account before using their DDNS service. If you select dyndns.org, you should go to their website and apply with your username and password, the website will return with a hostname to you. Fill in the hostname, username, and password that you applied to dyndns.org, and give the update time.
  • Page 108 Fill in the mail server information, including mail server address, SMTP port, username, and password. Select TLS or SSL if the server requires a Secure Connection, then fill in the sender and receiver’s mail address and mail subject. E-5. FTP Tick “Alarm”...
  • Page 109 E-6. DHCP When the function is enabled, the DVR is as a DHCP server and able to assign IP address to IP camera. Enter the Start IP and End IP for DHCP. Key in the Lease Time to decide the frequency that the IP address is renewed.
  • Page 110 F-2. Disk – Disk Information The information of the storage device will be displayed. G. Player Click the button to download D6Viewer, the DVR recording file player. Please refer to REMOTE PLAYBACK for more information regarding D6Viewer.

  • Page 111: Package Contents

    viii. PACKAGE CONTENTS 16CH aHD Hybrid DVR Quick Power cord Installation Guide Adapter Mouse Screw Package • The CD includes user manual and software tools...

  • Page 112: Appendix

    APPENDIX * RECORDING TIME LAPSE (HOURS) UNIT：Hours IMAGE QUALITY LOW(0.25M) MEDIUM(0.5M) STANDARD(1M) HIGH(1.5M) (Mbps) AVERAGE AVERAGE AVERAGE AVERAGE 16CH UNIT：Hours IMAGE QUALITY LOW(0.25M) MEDIUM (0.5M) STANDARD (1M) HIGH (1.5M) (Mbps) AVERAGE AVERAGE AVERAGE AVERAGE 16CH 1920 UNIT：Hours IMAGE QUALITY LOW(0.25M) MEDIUM (0.5M) STANDARD (1M) HIGH (1.5M)

  • Page 113: Hdd Compatiblity Table

    * HDD COMPATIBLITY TABLE Brand Model Capacity Others ST3500320SV 500GB SV35.3 ST3500410SV 500GB SV35.5 ST3500413AS 500GB Barracuda 7200 12 ST3500418AS 500GB 7200 12 ST500NM0011 500GB ST500DM002 500GB Barracuda ST31000333AS 7200 11 ST31000340AS 7200 11 ST31000340NS Barracuda ES.2 SEAGATE ST31000340SV SV35.3 ST31000322CS Pipeline HD .2 ST31000525SV...
  • Page 114 WD5003AZEX 500GB Caviar Black WD6400AAKS 640GB 7200 BLUE WD6400AVVS 640GB 7200 GP WD7500AACS 750GB 7200 GP WD7500AVVS 750GB 7200 GP WD1003FBYX Enterprise Storage WD1002FAEX Caviar Black WD10EACS 7200 GP WD10EADS Caviar Green WD10EALX Caviar Blue WD10EARS Caviar Green WD10EFRX WD10EURX AV-GP WD10EZEX Caviar Blue...
  • Page 115 HDS721010CLA332 7200 HDS721010CLA362 HDS721010DLE630 7200 HDS722020ALA330 7200 HDS723020BLA642 7200 DS7SAE202 DT01ACA050 500GB DT01ACA100 DT01ACA200 TOSHIBA DT01ABA050V 500GB DT01ABA100V DT01ABA200V DT01ACA300 DT01ABA300V...

  • Page 116: Error Message List

    * ERROR MESSAGE LIST ERROR MESSAGE ERROR STATUS & REASON H.D.D. Data structure un-normal. DISK ACCESS ERROR! The data is not recorded into the DVR or there are bad sectors on the DVR H.D.D. Please install another H.D.D. and perform the recording again. Please re-download the updated file and update UPDATE FILE ERROR! again.
  • Page 117 FAN FAILED Fan Error Warning. NO LOG DATA No Events Record. The condition is caused by trying to stop recording when performing the schedule record. SCHEDULE RECORD Please setup the record to manual mode and then stop the recording. The message will be shown while using the ZOOM PLEASE SELECT ONE function under split screen mode.
