- Page 1 3-Point Hitch Vertical/Horizontal Log Splitter Operation Manual Model # 100450 is safety alert symbol identi es important safety messages in this manual. Failure to follow this important safety information may result in serious injury or death. Part # 100719 Rev B...
- Page 2 For Service or Questions Call 1-877-487-8275 720-287-5182 www.dirtyhandtools.com Dirty Hand Tools® is a brand of 1100 W 120th Ave, Suite 600 Westminster, CO 80234 • 720-287-5182...
-
Page 3: Table Of Contents
Table of Contents Important Safety Information Intended Use ................4 Personal Protective Equipment ..........4 Safety Decals ................5 General Safety ................6 Preparation of the Log ...............6 Work Area ................. 6 Operation of the Log Splitter .............7 Repair and Maintenance Safety ..........8 Hydraulic Safety .................8 Assembly Instructions 1. -
Page 4: Important Safety Information
Important Safety Information WARNING WARNING: Read and understand the complete Operation Manual before assembling or using this product! Failure to comprehend and comply with warnings, cautions and instructions for assembly and operation could result in serious injury or death. Do not permit children to operate this equipment at any time. Do not permit others that have not read and understood the complete Operation Manual to operate this equipment. -
Page 5: Safety Decals
Important Safety Information SAFETY DECALS Make sure all safety warning decals are attached and in readable condition. Replace missing or defaced decals. Contact Dirty Hand Tools at 1-877-487-8275 for replacement decals. Operator Zone Decal Part # 100752 Pinch Point Decal Part # 100204 Operation Decal Part # 100212... -
Page 6: General Safety
Important Safety Information DANGER GENERAL SAFETY Failure to follow warnings, cautions, assembly and operation instructions in the Operation Manual may result in serious injury or death. Read the Operation Manual before operation. • Do not permit children to operate this equipment at any time. Do not permit others that have not read and understood the complete Operation Manual to operate this equipment. -
Page 7: Operation Of The Log Splitter
Important Safety Information OPERATION OF THE LOG SPLITTER Operate the log splitter from within the operation zone as shown in the diagrams below. e operator has the safest and most efficient access to the control valve and the beam in these locations. DANGER Failure to operate the log splitter in this position can result in serious injury or death. -
Page 8: Repair And Maintenance Safety
Important Safety Information REPAIR AND MAINTENANCE WARNING • Do not operate the log splitter when it is in poor mechanical condition or in need of repair. Frequently check that all nuts, bolts, screws, hydraulic fittings and hose clamps are tight. •... -
Page 9: Assembly Overview
1. Assembly Overview List of tools needed for assembly: • Hammer • Needle nose pliers • Box cutters • #2 Phillips screw driver • 6mm hex key wrench • 8mm driver • 13mm wrench or socket wrench • 17mm wrench or socket wrench •... -
Page 10: Unpacking The Container
2. Unpacking the Container Step 1: Remove top and sides of crate. Use a #2 phillips head and 8mm driver to remove hardware from the plywood shipping crate (shown above). Remove the straps securing the frame to the side of the crate. Due to the use of wood staples, it may be necessary to use a hammer and/or a crow bar to fully remove the packaging top and sides. -
Page 11: Frame Assembly
3. Frame Assembly Item # Part # Description Qty. 100566 Back Legs 100561 Front legs 100753 Manual Canister 100200 Hex Bolt, M12 x 1.75 x 110mm, G8.8 100570 Hex Bolt, M12 x 1.75 x 90mm, G8.8 100022 Hex Nut, M12 x 1.75, G8.8 100181 Flat Washer, M12 100023... -
Page 12: Beam Bracket Assembly
4. Beam Bracket Assembly 1. Attach the Beam Lock Bracket to the Beam & Cylinder Assembly with Hex Bolt, M12 x 1.75 x 35mm ; Flat Washer, ; Lock Washer, M12 ; and Hex Nut, M12 x 1.75 two places. Tighten securely using 19mm socket wrenches. 2. -
Page 13: Beam And Frame Assembly
5. Beam and Frame Assembly Item # Part # Description Qty. 100131 Hitch pin, 5/8 in. x 6 1/4 in. 100132 R-Clip, 1/8 in., Fits 1/2 in. to 3/4 in. 6. Final Installation Check Check tightness of all fittings, nuts and bolts prior to filling the log splitter with fluids. -
Page 14: Operating Instructions
Operating Instructions DANGER WARNING: Read and understand the complete Operation Manual before assembling or using this product! Failure to comprehend and comply with warnings, cautions and instructions for assembly and operation could result in serious injury or death. Operation of power equipment can be dangerous. It is the sole responsibility of the operator to understand the assembly and safe operation of this product. -
Page 15: Maintenance
Maintenance 1. With normal use the log splitter will not require any regular maintenance other than checking for loose bolts and the inspection of hoses and fittings. 2. If the wedge becomes dull or nicked, it can be removed and sharpened. -
Page 16: Speci Cations
GPM at 1500 to 2500 PSI. Do not exceed 3200 PSI, exceeding 3200 PSI will overstress log splitter mechanism and void warranty. For Service or Questions Dirty Hand Tools® is a brand of Call 1-877-487-8275 720-287-5182 1100 W 120th Ave., Suite 600 www.dirtyhandtools.com...
