Battery Doctor 20068 Owner's Manual

8 & 4 amp cec smart battery charger

Advertisement

Quick Links

BEFORE RETURNING FOR REPAIRS
15.
15.1 When a charging problem arises, make certain that the battery is capable of accepting a normal charge. Be sure to double check all connec-
tions, AC outlet for power, charger clips or ring terminals are clean and for proper polarity.
15.2 Check the fuse holder on the ring terminal cable attachment. In the rare occurance the fuse blows, replace the fuse with the same type (ATO/
ATC style) and same amerage marked on the top of the fuse before returning.
15.3 When a battery is very cold, partially charged or sulfated, it will not draw the full rated amperes from the charger. It is both dangerous and
damaging to a battery to force higher amperage into it than it can effectively use.
16.
WIRTHCO ENGINEERING, INC., MINNEAPOLIS, MN 55439 MAKES THIS LIMITED WARRANTY TO THE ORIGINAL PURCHASER AT RETAIL OF THIS PRODUCT. THIS
LIMITED WARRANTY IS NOT TRANSFERABLE.
WirthCo Engineering, Inc. has a limited warranty for this battery charger for fi ve years from date of purchase at retail against defective material or
workmanship. If such should occur, the unit will be repaired or replaced at the option of the manufacturer. It is the obligation of the purchaser to
forward the unit together with proof of purchase, transportation and/or mailing charges prepaid to the manufacturer or its authorized representative.
This limited warranty is void if the product is misused, subjected to careless handling, or repaired by anyone other than the manufacturer or its
authorized representative.
The manufacturer makes no warranty other than this limited warranty and expressly excludes any implied warranty including any warranty for
consequential damages.
This is the only express limited warranty and the manufacturer neither assumes nor authorizes anyone to assume or make any other obligation
towards the product other than this express limited waranty. The manufacturer makes no warranty of merchantability or fi tness for purpose of this
product and expressly excludes such from this limited warranty.
Some states do not allow the exclusion or limitation of incidental or consequential damages or length of implied warranty so the above limitations
or exclusions may not apply to you.
This warranty gives you specifi c legal rights and you may also have other rights which vary from state to state.
IMPORTANT SAFETY INSTRUCTIONS • SAVE THESE INSTRUCTIONS
WIRTHCO ENGINEERING, INC. • MINNEAPOLIS, MN 55439
© 2015 All rights reserved
LIMITED WARRANTY
OWNER'S MANUAL (MODEL #20068)
8 & 4 Amp CEC Smart Battery Charger/Maintainer Instructions
for 12/24 Volt Batteries
Read Instructions Carefully for Safe Operation
READ THE ENTIRE MANUAL BEFORE USING THIS PRODUCT.
FAILURE TO DO SO CAN RESULT IN SERIOUS INJURY OR DEATH.
WORKING IN VICINITY OF A LEAD-ACID BATTERY IS DANGEROUS. BATTERIES GENERATE EXPLOSIVE
GASES DURING NORMAL BATTERY OPERATION. FOR THIS REASON, IT IS OF UTMOST IMPORTANCE
THAT, EACH TIME BEFORE USING THE CHARGER, READ THIS MANUAL AND FOLLOW THE
INSTRUCTIONS EXACTLY.
This manual will show how to use the charger safely and effectively. Please read, understand and follow these instructions and precautions carefully, as
this manual contains important safety and operating instructions. The safety messages used throughout this manual contain a signal word, a message
and an icon.
The signal word indicates the level of the hazard in a situation.
indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury to the operator or bystanders.
indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury to the operator or bystanders.
indicates a potentially hazardous situation which, if not avoided, could result in moderate or minor injury to the operator or bystanders.
indicates a potentially hazardous situation which, if not avoided, could result in damage to the equipment or vehicle or
property damage.
Safety messages in this manual contain two different type styles.
• Unnumbered type states the hazard
• Numbered type states how to avoid the hazard.
The icon gives a graphical description of the potential hazard.
Pursuant to California Proposition 65, this product contains chemicals known to the state of California to cause cancer and
birth defects or other reproductive harm.
IMPORTANT SAFETY INSTRUCTIONS
1.
Risk of electric shock or fi re.
IMPORTANT SAFETY INSTRUCTIONS • SAVE THESE INSTRUCTIONS
WIRTHCO ENGINEERING, INC. • MINNEAPOLIS, MN 55439
© 2015 All rights reserved
