- Page 1 Lintronix IoT Starter Kit User’s Guide Real-time Locating and Telesensing System RTLX-SK01 RTLX-SK01 V 01.0.0 2017/05/01...
-
Page 2: Table Of Contents
Lintronix IoT Starter Kit Real-time Locating and Telesensing System RTLX-SK01 User’s Guide Content Chapter 1 Introduction ..............................2 Package Contents ............................2 Cloud/SW Package Datasheet ........................3 LBS-3026 Datasheet ............................5 STG-1020 Datasheet ............................6 WTG-1045 Datasheet ............................7 LBS-3026 Quick Installation Guide........................8 STG-1020 Quick Installation Guide ........................ -
Page 3: Chapter 1 Introduction
Chapter 1 Introduction RSK-4421 Starter Kit Linctronix package provides a total solution for indoor location tracking. It helps find anything anytime, anywhere with any device. This package includes a location engine, web application, cloud service and tracking device. The location engine provides a very high level of accuracy. The location web page provides an intuitive view for target tracking and the management web page includes a status report and statistics. -
Page 4: Cloud/Sw Package Datasheet
1.2 Cloud/SW Package Datasheet Location Engine Accuracy Range of 3m Latency Move detection in 5 seconds Capacity Up to thousands of targets can be tracked Event Event triggered and notification by location Web Display Application Well-designed GUI for desktop, smartphone and smartpad Intuitive operation and graphic display of real time location Operation User defined categories for monitor targets... - Page 5 Target Information management includes name, category, description Management Category management includes name and icon modification FW Upgrade Remote upgrade device Firmware Security Authorization and authentication for access control Cloud Service Server Maintained and monitored under Azure/AWS framework Configuration Configurations are stored in MySQL for easy maintenance Data Location and sensor data are specially handled by time series database for high performance...
-
Page 6: Lbs-3026 Datasheet
1.3 LBS-3026 Datasheet Wi-Fi IEEE 802.11 a/b/g/n Bluetooth Low Energy 4.0 Panel Button multi-function (reset/custom) Interface Reset Button factory restore Visual Indicator 3 x bi-color LEDs for System/Wi-Fi/BLE status & alarm Auditor Indicator 1 x Buzzer for system status/alarm External DC +5V micro-USB type B connector Power RTLS Tag Monitoring... -
Page 7: Stg-1020 Datasheet
1.4 STG-1020 Datasheet BLE 4.x Dialog DA14580 w/ ARM Cortex M0 provide low power and high efficient BLE solution Battery Life 12 months with 50% activity Power CR-2477 1,000mAH 3V non chargeable Li battery G-Sensor Kionix Tri-axis Digital Accelerometer Sensor Tamper Switch Tag release detection 4 x Tri-Color LEDs... -
Page 8: Wtg-1045 Datasheet
1.5 WTG-1045 Datasheet BLE 4.x Nordic nRF51 w/ ARM Cortex M0 provide high efficient BLE solution Battery Life 3 days with 100% activity Power Lithium-ion Battery 55mAH rechargeable battery G-Sensor Bosch Tri-axis Digital Accelerometer Sensor Step Detector Human Walking Detector OLED Display 96 x 16 Monochrome User... -
Page 9: Lbs-3026 Quick Installation Guide
1.6 LBS-3026 Quick Installation Guide LBS-3026 contains the Machine x 1, USB power adapter x 1, USB power cord x 1, and mounting bracket x 1 Before installation, please separate the mounting bracket by counterclockwise rotation, then you can find the unique mac address number on the back shell of LBS-3026. -
Page 10: Stg-1020 Quick Installation Guide
1.7 STG-1020 Quick Installation Guide STG-1020 is shipped along with bracket in the locked state. You can remove the device from the bracket first and then find the mac address on back of the device. Tape is already provided in each unit at the back of the bracket .If you want to stick STG-1020 to an asset for tracking;... -
Page 11: Wtg-1045 Quick Operation Guide
1.8 WTG-1045 Quick Operation Guide Charge the device to full for an CHRAGING:YES hour. 1 hour Tap the right side of the device Hello!! BDADDRFF1400 to display and switch the panel. Tap to switch panel 1 Panel has 4 pages to Scroll, every page can BDADDRFF1400 show 12 characters. -
Page 12: Chapter 2 Using The Starter Kit
Chapter 2 Using the Starter Kit 2.1 RTLS Cloud System 2.2 Login in to the Cloud Web Site The Starter kit includes a 1 year cloud system account for testing, we don’t support the earlier versions of the IE browser, so to avoid unexpected errors, please use the latest version of browser e.g. Google Chrome or Safari. -
Page 13: Upload The Site-Map
2.3 Upload the Site-Map The Starter Kit contains 4 sets of LBS-3026, we recommend finding a site-field of about 100 ~200 square meters for testing. The recommended distance of each LBS-3026 is about 6 ~8 meters for installation. The map scale must conform to the size of the real site, and according to the real length of site, map file shall be adjusted to 1 cm = 1 pixel scale size. -
Page 14: Deployment Of Lbs-3026
2.4 Deployment of LBS-3026 Deploying the CBS (LBS-3026) is intuitive and easy on our cloud system. Directly click on corresponding locations of the site map and enter the mac address, actual height(cm) of installation ,then press the update button. To modify the deployment location, just remove the mac-address by clicking the delete-button and re- operate adding CBS again. -
Page 15: Restart The System To Apply The New Config
2.5 Restart the System to Apply the New Config After adding the devices, you need to restart the system to apply the new settings. 2.6 Setting Wi-Fi Config of LBS-3026 After plugging in the power supply, LBS-3026 will search for a Wi-Fi access point automatically, and try using default or custom Wi-Fi account to connect to the cloud. -
Page 16: Operation Guide Of Lbs-3026
2.7 Operation Guide of LBS-3026 Press and hold for one second to switch to mute mode (LED&buzzer OFF) Normalall mute buzzer muteNormal with 3 beeps Power indicator: LBS-3026 will automatically start with one beep when the power is plugged in. The power indicator flashes once per second, if it is off or light-on continuously, check that if it is in mute mode or re-plug the USB power connector to confirm proper power supply. -
Page 17: Short Message Service
30:E0:90:BB:00:06 30:E0:90:00:69:92 Select Category: filter icon on sidebar of location monitor page，Asset & Wristband category is provided by default. Input Description：Click the item icon on the front page to display the description Select Product: please set STG-1020 to “tag” and WTG-1045 to “wristband”. Only wristbands support SMS function. -
Page 18: Chapter 3 Real Time Location Monitoring
Chapter 3 Real time location monitoring Sidebar Filter: collapse function, Map List ,device Item list ,Category icon. Map: Zoom in & out by mouse wheel or function button. Search with keyword of the device. -
Page 19: Chapter 4 Getting Help
Quick menu: A quick list of all the devices currently detected on the site. You can click to display any device separately. Chapter 4 Getting Help For more detailed features and FAQs, please refer to our forum of starter kit products: http://www.linctronix.com/support http://www.linctronix.com/ (download page)
