BE Whirl-A-Way 85.403.003 Operation Manual

Pressure flat surface cleaner
Hide thumbs Also See for Whirl-A-Way 85.403.003:
Table of Contents

Advertisement

Quick Links

This product contains lead, a chemical known to the State of California to cause birth
defects or other reproductive harm. Wash your hands after handling this product.
This product contains chemicals known to the State of California to cause cancer and
birth defects or other reproductive harm.
operation manual
WARNING
WARNING
Model #
85.403.003
85.403.005
85.403.007
85.403.009
85.403.010
85.403.011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Whirl-A-Way 85.403.003 and is the answer not in the manual?

Questions and answers

Related Manuals for BE Whirl-A-Way 85.403.003

Summary of Contents for BE Whirl-A-Way 85.403.003

  • Page 1 operation manual Model # 85.403.003 85.403.005 85.403.007 85.403.009 85.403.010 85.403.011 WARNING This product contains lead, a chemical known to the State of California to cause birth defects or other reproductive harm. Wash your hands after handling this product. WARNING This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
  • Page 2 Using the Operator’s manual The operating manual is an important part of your Whirl-A-Way and should be read thoroughly before initial use, and referred to often to make sure adequate safety and service concerns are being addressed. Reading the owner’s manual thoroughly will help avoid any personal injury or damage to your pump.

  • Page 3: Product Identification

    product identification Record Identification Numbers Whirl-A-Way If you need to contact an Authorized Dealer or Customer Service line (1-866-850-6662) for information on servicing, always provide the product model and identification numbers. You will need to locate the model and serial number for the pump and record the information in the places provided below.

  • Page 4: Operation

    Should you leave the cleaner in a stationary position, the surface being cleaned can be seriously damaged by the high pres- sure. The distance of the nozzle tips from the surface can be adjusted by loosening the bolt on the rotary head mounting collar and adjusting the rotary head up or down.
  • Page 5 Whirl-a-Way. Keep hands and feet away from the high pressure, high speed rotating arm that is protected by the plastic cover. Should your surface cleaner not be used for long periods of time, it is recommended that you remove the hose from the top of the rotary head and a vegetable oil be used to lubricate the swivel head’s internal parts.
  • Page 6 parts diagram 85.403.003 85.403.007 85.403.011...

  • Page 7: Parts List

    parts list 85.403.003 PART # DESCRIPTION 85.792.003 Bracket, Mounting Head 16” 85.790.004 Rotary Head, 16” 85.792.004 Mounting Blocks 85.238.059 Hose, 62” x 3/8” AC7501 Easy Pull Gun 85.300.105 Plug, 3/8” MNPT 85.792.008K Handle 85.602.005 Hand Grip 85.792.010 Brush, 16” 85.792.009 Cover, Polypropylene 16”...
  • Page 8 parts diagram 85.403.005...
  • Page 9 parts list 85.403.005 DESCRIPTION PART # Bracket, Mounting Head 18" 85.791.001 Rotary Head, 18" 85.790.006 Mounting Blocks 85.419.116 Hose, 62" x 3/8" 85.238.057 Spray Gun 85.202.115 Plug, 3/8" MNPT 85.300.105 Handle 85.419.040K Hand Grip 85.602.005 Castor Wheel 85.790.029 Castor Bracket 85.419.046 Cover, Polypropylene 18"...
  • Page 10 parts diagram 85.403.009 85.403.010...
  • Page 11 parts list 85.403.009/85.403.015 DESCRIPTION PART # Bracket, Mounting Head 20" 85.791.002 Rotary Head, 20" 85.790.004 Mounting Blocks 85.792.019 Hose, 62" x 3/8" 85.238.059 Spray Gun AC7501 Plug, 3/8" MNPT 85.300.105S Handle 85.792.018K Hand Grip 85.602.005 Brush Skirt, 20" 85.792.013 Castor Wheel 85.790.029 Cover, Stainless Steel 20"...
  • Page 12 By removing the snap ring and washer, you can tap off the outer shell with a hammer while the output shaft is held in a vice. The rotary head repair kit can then be used to replace the worn items inside the rotary head shell.

  • Page 13: Warranty

    warranty Warranty The rotary head has a six-month warranty from the date of purchase. Should you encounter problems with the rotary head within that time period, simply return the defective part for replacement. If you encounter problems after the six month period has lapsed, we sell a rotary head repair kit.
  • Page 14 If you need assistance with the assembly or operation of your Generator please call 1-866-850-6662...
