- Page 1 XPC BIOS User Guide For the : DX30 Series...
-
Page 2: Xpc Installation Guide
For continuing product improve- ment, Shuttle® Inc. reserves the right to revise the manual or make changes to the speci- fications of this product at any time without notice and obligation to any person or entity regarding such change. -
Page 3: Safety Information
Read the following precautions before setting up a Shuttle XPC. CAUTION Incorrectly replacing the battery may damage this computer. Replace only with the same or equivalent as recommended by Shuttle. Disposal of used batteries according to the manufacturer's instructions. Laser compliance statement The optical disc drive in this server is a laser product. -
Page 4: Table Of Contents
TABLE OF CONTENTS Driver and Software Installation............1 Motherboard Driver DVD ............1 User Manuals................2 Appendix...................3 Starting BIOS ................3 BIOS Setup Menu ..............3 Main Setup ................5 Advanced ................6 TPM Configuration ............7 Power Management Configuration ......8 Hardware Health Configuration ........10 CPU Configuration .............11 SATA Configuration ...........13 USB Configuration .............14 OnBoard Device Configuration ........15... -
Page 5: Driver And Software Installation
Driver and Software Installation Motherboard Driver DVD The DVD contents attached in DX30 Series motherboard are subject to change without notice. The Motherboard Driver DVD contains all the motherboard drivers necessary to ® optimize the performance of this Shuttle Xvision in a Windows OS. -
Page 6: User Manuals
User Manuals Install Adobe Reader 9.5 MotherBoard Manual Quick Guide... -
Page 7: Appendix
Appendix Starting BIOS AMIBIOS has been integrated into many motherboards for over a decade. In the past, people often referred to the AMIBIOS setup menu as BIOS, BIOS setup, or CMOS setup. American Megatrends refers to this setup as BIOS. Specifically, it is the name of the AMIBIOS8 BIOS setup utility. - Page 8 AMIBIOS8 has default text messages built into it. The motherboard manufacture retains the option to include, leave out, or change any of these text messages. They can also add their own text messages. Because of this, many screen shots in this manual are different from your BIOS setup screen. The BIOS setup/utility uses a key-based navigation system called hot keys.
-
Page 9: Main Setup
Main Setup When you first enter the BIOS Setup Utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab. There are two Main Setup options. They are described in this section. The Main BIOS Setup screen is shown below. -
Page 10: Advanced
Advanced Select the Advanced tab from the BIOS setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as CPU Configuration, to go to the sub menu for that item. You can display an Advanced BIOS Setup option by highlighting it using the <Arrow>... -
Page 11: Tpm Configuration
TPM Configuration Security Device Support This item allows you to enable or disable TPM function. The choice: Enabled , Disabled. -
Page 12: Power Management Configuration
Power Management Configuration Wake Up By USB (S3) This item allows you to enable or disable system wake up by USB (S3). The choice: Enabled , Disabled. Wake Up By PS2 (S3) This item allows you to enable or disable system wake up by PS2 (S3). ... - Page 13 Power-On after Power-Fail This item allows you to set system power on automatically after AC power restored. The choice: Power On, Former-Sts, Power Off, Power On by LAN, Power On by RTC. Wake Up By LAN This item allows you to enable or disable system wake up by LAN. ...
-
Page 14: Hardware Health Configuration
Hardware Health Configuration ... -
Page 15: Cpu Configuration
CPU Configuration You can use this screen to select options for the CPU Configuration Settings. Use the up and down <Arrow> keys to select an item. Use the <Plus> and <Minus> keys to change the value of the selected option. A description of the selected item appears on the right side of the screen. - Page 16 C State Support This item allows you to enable or disable CPU C State. The choice: Enabled , Disabled. Intel (R) V. T. When enable, a VMM can utilize the additional hardware capabilities provided by vanderpool Technology. The choice: Enabled , Disabled. Active Processor Cores This item allows you to determine how many cores to be enabled.
-
Page 17: Sata Configuration
SATA Configuration ... -
Page 18: Usb Configuration
USB Configuration ... -
Page 19: Onboard Device Configuration
OnBoard Device Configuration High Definition Audio This item allows you to enable or disable system High Definition Audio. The choice: Enabled , Disabled. Onboard i211 LAN Function This item allows you to enable or disable LAN Function. The choice: Enabled , Disabled. Onboard LAN BOOT ROM This item allows you to enable or disable Onboard LAN BOOT ROM. - Page 20 IGD Memory Size Select Allows you to select the size of system memory used by the internal graphics device. The choice: 64MB, 128MB, 256MB, 512MB. M.2 Select M.2 PCIE and SATA module selection. The choice: PCIE, SATA. Intel (R) VT-d This item allows you to enable or disable Intel (R) VT-d.
-
Page 21: Security
Security Select the Security tab from the BIOS setup screen to enter the Security BIOS Setup screen. You can display an Security BIOS Setup option by highlighting it using the <Arrow> keys. All Security BIOS Setup options are described in this section. The Security Setup screen is shown below. - Page 22 Type the password and press <Enter>. The screen does not display the characters entered. Retype the password as prompted and press <Enter>. If the password confirmation is incorrect, an error message appears. The password is stored in NVRAM after BIOS completes. User Password Select Change User Password from the Security Setup menu and press <Enter>.
-
Page 23: Boot
Boot Select the Boot tab from the BIOS setup screen to enter the Boot BIOS Setup screen. You can select any of the items in the left frame of the screen, such as Boot Settings Configuration, to go to the sub menu for that item. You can display an Boot BIOS Setup option by highlighting it using the <Arrow>... - Page 24 Boot from USB device This item allows you to enable or disable boot from USB device. The choice: Enabled , Disabled. Boot from Card-Reader This item allows you to enable or disable boot from Card-Reader device. The choice: Enabled , Disabled. Boot Mode select Choice Boot to UEFI or Legacy.
-
Page 25: Exit
Exit Select the Exit tab from the BIOS setup screen to enter the Exit BIOS Setup screen. You can display an Exit BIOS Setup option by highlighting it using the <Arrow> keys. All Exit BIOS Setup options are described in this section. The Exit BIOS Setup screen is shown below.
