Summary of Contents for Ruijie RG-AP620 Series
- Page 1 Installation Guide RG- AP620 Series Wireless Access Device...
-
Page 2: Copyright Statement
Ruijie Networks reserves all copyrights of this document. Any reproduction, excerption, backup, modification, transmission, translation or commercial use of this document or any portion of this document, in any form or by any means, without the prior written consent of Ruijie Networks is prohibited. - Page 3 You can obtain the documentation you need through the following channels: Internet: You can obtain the latest on-line documentation at:http://www.ruijie.com.cn Documentation CD-ROM: The documentation of Ruijie Networks switches is stored in the CD-ROM package, which is provided to you together with the product you purchase. The...
- Page 4 You can obtain the technical assistance you need through any of the following channels: Ruijie Networks website, from which you can obtain the latest product documentation, causes and problems analysis of product faults, application solutions, and software upgrade. http://www.ruijie.com.cn/ ...
-
Page 5: Product Overview
Product Overview Introduction Ruijie RG-AP620-H WLAN Access Point (hereafter referred to as AP620-H) is one of the wireless AP products independently developed by Fujian Ruijie Networks Co., Ltd. AP620-H is mainly designed for demanding outdoor applications. Besides serving as Fit AP and networking with wired/wireless integrated switch/wireless controller, it can also act a FAT AP and provide wireless access service for WLAN users. - Page 6 Serial flash 128MB Automatic control of AP power Radio management Automatic channel See left (wireless) switchover AP load sharing Normal operations can be achieved at ambient temperature of -40 - 55℃ and without water Environmental requirement immersion. Detailed Introduction to AP620-H Wireless AP 1.3.1 AP620-H Wireless AP...
- Page 7 1.3.1.2 Front Panel Fig 1-2 Front panel of RG-AP620-H 1. Console interface 2. 1000Base-X SFP port 3. 10/100/1000Base-T self-adaptive Ethernet port 1.3.1.3 Power System AP620-H adopts POE input and complies with 802.3at protocol. Input voltage range: 36-57V Rated current: 0.57A 1.3.1.4 Cooling System RG-AP620-H adopts fanless design.
-
Page 8: Preparations Before Installation
Preparations Before Installation Safety Precautions To avoid the harms caused to human and device, please carefully read the safety precautions given in this manual before installing RG-AP620-H. The following safety precautions can't cover all possible hazardous conditions. Note Grounding and Lightning Protection 1. -
Page 9: Temperature And Humidity
inserted into the steel tube and buried into the ground, with both ends of the steel tube properly grounded. 6. The lightning protector shall be installed nearby the premises-outgoing segment of network cable. 7. In plain areas, the protection angle of antenna lightning arrester shall be less than 45 degree. -
Page 10: Outdoor Installation
Outdoor Installation RG-AP620-H WLAN AP is designed for direct outdoor installation and supports wall-mount installation and pole-mount installation. Waterproof Considerations 1. For unused interfaces, the corresponding waterproof plugs shall be processed (use waterproof tape to rewind the screw thread of waterproof plug for three loops), and then seal the unused interfaces with waterproof plugs. -
Page 11: Emi Considerations
EMI Considerations Various interference sources, no matter from inside or outside of the device or application system, will have impacts on the device through capacitive coupling, inductive coupling and electromagnetic wave radiation. Electromagnetic interference can be divided into radiated interference and conducted interference, which will be determined according to the type of transmission path. -
Page 12: Installation Tools
Precautions for Optical Fiber Connection Before optical fiber connection, please make sure the optical connector matches with the optical interface used. Meanwhile, please pay attention to the transmitting and receiving directions of optical cable. The transmitting interface of this device shall be connected to the receiving interface of counterpart device, while the receiving interface of this device shall be connected to the transmitting interface of counterpart device. -
Page 13: Product Installation
Product Installation Make sure you have carefully read the contents of Chapter II. Make sure the requirements described in Chapter II have been satisfied. Note Installation Flow Verifications Before Installation Verify the following points before the installation: Whether the installation site satisfies the requirements on temperature and humidity;... - Page 14 Install AP620-H Main Unit First fix the mounting bracket to the rear of main unit and tighten the screws on the mounting bracket, as shown below: Figure: Fix the mounting bracket to the rear of AP620-H and tighten the screws on the mounting bracket Prepare to mount the main unit onto the hold pole (parallel or vertical), as shown below:...
- Page 15 Parallel installation Vertical installation...
- Page 16 There are two groups of mounting holes on the mounting bracket. Put the U-hoop in respective holes according to the mode of installation and lock screws to mount AP620-H onto the hold pole. Mounting holes on the bracket Parallel installation...
- Page 17 Vertical installation Tighten the screws to fix the hoop...
-
Page 18: Install Outdoor Antenna
Install Outdoor Antenna The outdoor antenna can be divided into directional outdoor antenna and all-directional outdoor antenna. The all-directional antenna can be directly installed onto the main unit. Install the direction antenna through the following steps. 1. Make sure the directional antenna is protected by lightning arrester. If there is no lightning arrester nearby, a lightning arrester shall be installed at the top of hold pole. -
Page 19: External Cables
horizontal reach of the all-directional antenna). Instead, a lightning arrester must be separately erected between the hold poles of two all-directional antennae. The height of lightning arrester must allow the top of all-directional antenna to be covered by the protection angle. 2. - Page 20 2. After that, prepare the modular plug.
- Page 21 S7800 Series Hardware Installation Guide Appendix A AppendixA Connectors Connection Media 1. 1000BASE-T/100BASE-TX/10BASE-T Port 1000BASE-T/100BASE-TX/10BASE-T is a port that supports adaptation of three rates, and automatic MDI/MDIX Crossover at these three rates. The 1000BASE-T complies with IEEE 802.3ab, and uses up to 100m of 100-ohm Category-5 or Supper Category-5 UTP or STP cable.
-
Page 22: Fiber Connection
S7800 Series Hardware Installation Guide Appendix A Figure A-3 Connections of the twisted pairs of the 100BASE-TX/10BASE-T 2. Fiber Connection For the optic ports, select single-mode or multiple-mode fibers for connection according to the fiber module connected. The connection schematic diagram is shown in Figure A-4: Figure A-4 Schematic Diagram for Fiber Connection Switch Switch... - Page 23 S7800 Series Hardware Installation Guide Appendix A AppendixB Mini-GBIC Modules and Technical Specification 1000M SFP modules (Mini-GBIC modules) are available to address the requirements of interface types of switch modules. You can select the SFP module to suit your specific needs. Below the models and technical specifications of some 1000M SFP modules are listed for your reference.
- Page 24 S7800 Series Hardware Installation Guide Appendix A ode optic Mini-GBIC-ZX80 80km fiber Mini-GBIC-ZX10 100km Mini-GBIC-GT 100m For the optical modules that the maximum cabling distance exceeds 40km(including 40km), when using the short-distance single-mode fiber, the online optical attenuators Warning shall be inserted in the link to prevent the overload of the optical receiving machine.
