devention DEVO-12 User Manual
  1. Manuals
  2. Brands
  3. devention Manuals
  4. Remote Control
  5. DEVO-12
  6. User manual

devention DEVO-12 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Part one: General information ...................................................................................................... 5
1.0 General information ........................................................................................................................................5
1.1 Foreword................................................................................................................................................5
1.2 Important statements ..............................................................................................................................6
1.3 Safety needing attention..........................................................................................................................6
1.4 Attention before flight ..............................................................................................................................6
2.0 Features.........................................................................................................................................................7
2.1 Features of DEVO-12..............................................................................................................................7
2.2 Features of RX1201................................................................................................................................7
3.0 Specification ...................................................................................................................................................8
3.1 DEVO-12 specification ............................................................................................................................8
3.2 Receiver specification .............................................................................................................................8
4.0 Definition of DEVO-12.....................................................................................................................................9
4.1 Panel definition .......................................................................................................................................9
4.2 Rear definition ......................................................................................................................................10
4.3 Wiring Diagram.....................................................................................................................................11
4.4 Function keys in panel ..........................................................................................................................12
5.0 Control stick adjustment................................................................................................................................12
5.1
Control stick length adjustment .......................................................................................................12
5.2 Control stick tension adjustment ............................................................................................................13
6.0 Neck strap usage..........................................................................................................................................13
7.0
Stick mode switch...................................................................................................................................14
8.0
Switches between left-hand and right-hand throttles ................................................................................16
8.1 Right-hand throttle switched to left-hand throttle.....................................................................................16
8.2
Left-hand throttle switched to right-hand throttle...............................................................................20
5.5 Stick tension adjustment ............................................................................................错误！未定义书签。
9.0 Training function ...........................................................................................................................................22
10.0 Customized fixed ID....................................................................................................................................25
11.0 Installation requirements for receiver............................................................................................................28
12.0 Installation requirement for DEVO-12 Battery pack.......................................................................................29
12.1 Matters needing attention on battery pack............................................................................................30
12.2 DEVO-12 battery charging ..................................................................................................................30
12.3 Voltage parameters.............................................................................................................................31
12.4 Indication for charging status...............................................................................................................31
Part two: Helicopter ................................................................................................................... 32
1.0
System menu .........................................................................................................................................32
1.1 Language setting ..................................................................................................................................34
1.2 Skin selection .......................................................................................................................................34
1.3 Display .................................................................................................................................................35
1.4 Buzzer warning.....................................................................................................................................36
1.5 Date & Time .........................................................................................................................................36
1.6 TFT screen calibration ..........................................................................................................................38
1.7 Stick mode ...........................................................................................................................................39
1.8 Stick and lever ......................................................................................................................................39
1.9 Power amplifier.....................................................................................................................................41
1.10 About..................................................................................................................................................42
