Operating instructions
Headend Controller
Headend control unit with 8A power supply
Professional Headend Solutions
Contents
1. Safety and operating instructions ................................................................... 2
2. Device variants ................................................................................................. 2
3. General ....... ..................................................................................................... 2
4. Front view ......................................................................................................... 3
5. Functional description ..................................................................................... 3
6. Head end bus structure ................................................................................... 3
6.1 Minimum configuration (without Bus Extender) ...................................... 3
6.2 Standard configuration (with Bus Extender) ........................................... 4
7. Head end bus structure ................................................................................... 4
8. Redundancy circuit .......................................................................................... 4
9. Alarm function ................................................................................................. 5
10. Technical data .... ........................................................................................... 5
11. Programming ................................................................................................ 6
10.1 Main program ........................................................................................ 6
10.2 Adjustments ........................................................................................... 6
10.4 Adjusting of the IP number .................................................................... 7
11. Bibliography .................................................................................................. 8
12. Document history .......................................................................................... 9
HCB x00
Part N
: 965x.01
o
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Blankom 965x.01 series
Summary of Contents for Blankom 965x.01 series
-
Page 1: Table Of Contents
Professional Headend Solutions Operating instructions Headend Controller Headend control unit with 8A power supply Contents 1. Safety and operating instructions ..............2 2. Device variants ....................2 3. General ......................2 4. Front view ......................3 5. Functional description ..................3 6. -
Page 2: Safety And Operating Instructions
HCB x00 Headend Controller Headend control unit with 8A power supply Part N : 965x.01 LINE 1. Safety and operating instructions When assembling, starting-up and adjusting the modules, it is necessary to consider the system specific references in the manual instruction! The modules may only be installed and started up by authorized technical personnel! When assembling the modules into the receiving points, the adherence of the EMC regulations is to be secured! The assembly and wiring have to be done without voltage! -
Page 3: Front View
HCB x00 Headend Controller Headend control unit with 8A power supply Part N : 965x.01 LINE 4. Front view Display HEADEND CONTROLLER POWER SUPPLY Control keys Type: HCB 200 Part No.: 9652.01 Reset key INPUT VOLTAGE 100 ... 240 V INPUT FREQUENCY 50 / 60 Hz INPUT POWER... -
Page 4: Standard Configuration (With Bus Extender)
HCB x00 Headend Controller Headend control unit with 8A power supply Part N : 965x.01 LINE 6.2 Standard configuration (with Bus Extender) HCB x00 Headend Controller BEB x00 Bus Extender Module signal processing unit The number of the possible module connections (01 ... 15) to a BEB x00 depends on the total power consumption of this line! 7. -
Page 5: Alarm Function
HCB x00 Headend Controller Headend control unit with 8A power supply Part N : 965x.01 LINE 8. Alarm function To activate the alarm function is additional hardware 9651.01 or 9651.02 necessary! The device is endorsed by an additional alarm function and current limitations, voltage drops and communication disturbaces. The contact 13 in the communication and supply bus is switched (+5V to 0 V) in case of alarm. -
Page 6: Programming
HCB x00 Headend Controller Headend control unit with 8A power supply Part N : 965x.01 LINE 10. Programming 10.1 Main program BLANKOM ENTER Ú Address selection Selection modules Ú abort Type/ article number Change module see operating instructions of the module Ú... -
Page 7: Subroutine "Change Configuration
HCB x00 Headend Controller Headend control unit with 8A power supply Part N : 965x.01 LINE 10.3 Subroutine “Change configuration” Change configuration Ú Address selection direct input or selection Ú Ú all characters/ numbers & capital letters only All characters Ú... -
Page 8: Bibliography
HCB x00 Headend Controller Headend control unit with 8A power supply Part N : 965x.01 LINE Subroutine “Change IP number“ IP number is displayed change 4. Byte (MSB) 3. Byte 2. Byte 1. Byte (LSB) 11. Bibliography [1] EN 60728-11: Cable networks for television signals, sound signals and interactive services Part 11: Safety (IEC 60728-11:2005);... -
Page 9: Document History
