INSTALLATION INSTRUCTIONS
ROADTHUNDER SPEAKER PODS BY MTX, SATIN BLACK
THANK YOU FOR CHOOSING KURYAKYN!
Protect yourself and others from possible injury and property damage or loss. Pay close attention to all instructions, warnings, cautions, and notices regarding the installation, use, and care of this product.
THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE CONTENTS DESCRIBED HEREIN CAN RESULT IN POTENTIAL DEATH OR SERIOUS INJURY.
THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE CONTENTS DESCRIBED HEREIN CAN RESULT IN MINOR OR MODERATE POTENTIAL INJURY.
THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE CONTENTS DESCRIBED HEREIN MAY NEGATIVELY AFFECT PRODUCT PERFORMANCE AND FUNCTIONALITY OR
DAMAGE THE PRODUCT ITSELF OR THE PRODUCT TO WHICH IT IS BEING ATTACHED.
ENSURE THAT THE FOLLOWING PARTS HAVE BEEN INCLUDED IN THE KIT:
1
3" Speaker POD
1
3" Amp Speaker POD
1
Wire Harness
2
M8-1-1/4 X 45 Cap Screw
YOU WILL ALSO NEED:
Metric Hex, Allen wrenches, Pliers
THESE INSTALLATION INSTRUCTIONS CONTAIN IMPORTANT INFORMATION. ENSURE THE END USER RECEIVES THIS COPY AND IS AWARE
OF ITS IMPORTANCE FOR FUTURE USE.
WHEN CONNECTING POWER AND GROUND WIRES ENSURE THAT THE RED POWER WIRE IS FUSED AT THE POINT WHERE IT IS
CONNECTED TO THE VEHICLE'S BATTERY. FAILURE TO DO SO CAN RESULT IN DAMAGE TO THE VEHICLE IF A SHORT CIRCUIT DEVELOPS
BETWEEN THE VEHICLE CONNECTION POINT AND THE PRODUCT.
PAGE 1
302711
DPF-MRK-003 REV A 4/22/16
4
M8 Internal Tooth Lock Washer
2
Assembly: 1" Handlebar Clamp
2
Clamp Shim, 1100-O Alum, For 7/8" Bars
1
T-Tap Quick Connect Female
1
10 Amp Mini Fuse
4
Cable Ties
866 277 9598 | INFO@KURYAKYN.COM
454 COUNTY ROAD VV SOMERSET, WI 54025
2711
K U R YA K Y N . C O M
Advertisement
Table of Contents
Related Manuals for Kuryakyn RoadThunder Speaker Pods
Summary of Contents for Kuryakyn RoadThunder Speaker Pods
-
Page 1: Installation Instructions
INSTALLATION INSTRUCTIONS ROADTHUNDER SPEAKER PODS BY MTX, SATIN BLACK 2711 THANK YOU FOR CHOOSING KURYAKYN! Protect yourself and others from possible injury and property damage or loss. Pay close attention to all instructions, warnings, cautions, and notices regarding the installation, use, and care of this product. - Page 2 INTRODUCTION Thank you for purchasing this Kuryakyn RoadThunder Speaker Pods by MTX that are designed to work with most Bluetooth enabled devices including iPhone® and Android® smartphones and tablets. This easy to install and use, all in one unit is capable of transforming your Bluetooth enabled mobile device into the center of your vehicle’s audio system.
-
Page 3: Power Connection
INSTALLATION INSTRUCTIONS ROADTHUNDER SPEAKER PODS BY MTX, SATIN BLACK 2711 -CONTINUED- Route all harness wires through the bike’s frame to the battery and proceed to the next steps in power connection. POWER CONNECTION SPEAKER PODS WIRE HARNESS CONNECTION STEP 1 Connect the Red wire (with the in-line fuse) power wire from the wire harness to the positive terminal on the battery. - Page 4 INSTALLATION INSTRUCTIONS ROADTHUNDER SPEAKER PODS BY MTX, SATIN BLACK 2711 -CONTINUED- AUDIO OUTPUT ON SPEAKER PODS The 3.5mm audio output on the Speaker Pods can be connected to a second Speaker Pods system or any other audio device. If connected to a second Speaker Pods system, the second set of powered pods will be controlled by the volume setting of the connected audio source.
- Page 5 ©2015 KURYAKYN HOLDINGS, LLC ALL RIGHTS RESERVED KURYAKYN, KURYAKYN K logo and the marks appearing on this instruction sheet are registered and common law trademarks of Kuryakyn Holdings except noted third-party trademarks. A full listing of trademarks and trademark registrations owned by Kuryakyn Holdings can be found at www.kuryakyn.com/legal-notice.
