Garden Oasis D71 M15150 Use And Care Manual

Lp gas fire table
Hide thumbs Also See for D71 M15150:

Advertisement

Quick Links

Download this manual See also: Owner's Manual
USE AND CARE GUIDE
LP GAS FIRE TABLE
Product Code: D71 M15150
KSN: 05355059-6
UPC Code: 034613672385
Date of Purchase: _____/_____/_____
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from
the appliance and immediately call
your gas supplier or fire department.
WARNING
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
An LP-cylinder not connected for use
shall not be stored in the vicinity of
this or any other appliance.
WARNING
For outdoor use only.
Design certified under ANS
Z21.97 - CSA 2.41-(2012)
Requirements for Outdoor Gas
Fireplaces

Advertisement

loading
Need help?

Need help?

Do you have a question about the D71 M15150 and is the answer not in the manual?

Questions and answers

Related Manuals for Garden Oasis D71 M15150

Summary of Contents for Garden Oasis D71 M15150

  • Page 1 WARNING For outdoor use only. USE AND CARE GUIDE LP GAS FIRE TABLE Product Code: D71 M15150 Design certified under ANS KSN: 05355059-6 Z21.97 - CSA 2.41-(2012) UPC Code: 034613672385 Requirements for Outdoor Gas...

  • Page 2: Table Of Contents

    Thank You For Your Purchase Thank you for your purchase! We are pleased that you have chosen Sears for your outdoor heating purchase. We hope that you enjoy the unmatched quality, ambiance, and style of your outdoor heating product. Every piece is meticulously considered all the way down to the smallest details, exclusively for you, by our world class design team.

  • Page 3: Safety Information

    Safety Information Warning! Please read and understand this entire manual before attempting to assemble, operate or install the product. Failure to follow the dangers, warnings and cautions contained in this owners manual may result in a fire or explosion causing damage to property, serious bodily injury or death. •...
  • Page 4 Safety Information • Do not use this fire table for cooking. • Do not put any other fireplace cover or anything flammable on, beneath or around the fire table. • Users should be alerted to the hazards of high surface temperatures and keep a safe distance to avoid burning or clothing ignition.

  • Page 5: Warranty

    Safety Information be inspected annually. More frequent cleaning may be required as necessary. It is imperative that the control compartment, burners and circulating air passageways of the appliance be kept clean. • Inspect the burner before each use of this fire table. If there is evidence of damage, the burner must be replaced prior to use of this fire table.

  • Page 6: Pre-Assembly

    Pre-Assembly PART DESCRIPTION QUANTITY LAVA ROCKS 1 BOX AAA BATTERY BODY DOOR PVC COVER...

  • Page 7: Assembly

    Assembly Turning the gas supply off • MAKE SURE THE CONTROL KNOB FOR THE GAS SUPPLY SYSTEM IS TURNED TO “OFF” BEFORE ASSEMBLY. Placing the gas tank • REMOVE DOOR “D” AND PLACE PROPANE GAS TANK (NOT INCLUDED) INTO THE METAL STAND INSIDE THE BODY “C”.
  • Page 8 Assembly Connecting the regulator • TURN THE CYLINDER VALVE ON THE PROPANE GAS TANK CLOCKWISE TO CLOSE THE GAS SUPPLY ON THE PROPANE GAS TANK. ATTACH THE PREASSEMBLED REGULATOR FROM THE FIRE TABLE BODY “B” TO THE CYLINDER VALVE BY TURNING THE REGULATOR COUPLING NUT CLOCKWISE BY HAND ONLY.
  • Page 9 Assembly Connecting door to body • REPLACE DOOR “D” ONTO THE BODY “C”. Installing the battery • TO INSTALL THE BATTERY “B”, UNSCREW THE RUBBER CAN OF THE ELECTRIC IGNITER AND PLACE BATTERY “B” INTO THE BATTERY CASE. MAKE SURE THE POSITIVE POLE (“+”) FACES OUT TOWARDS THE CAP.

  • Page 10: Operation

    Assembly Placing the lava rocks • PLACE THE LAVA ROCKS “A” EVENLY INTO THE FIRE TABLE BODY “C”. Warning! The screen in this fire table MUST be clear and free of obstructions at all times to ensure proper operation. Make sure the fire table is covered completely with lava rocks or the flame may extinguish occasionally.
  • Page 11 Operation 7. Continue to push and hold the control knob for 45 seconds. 8. If ignition does NOT immediately take place in seconds, push and turn the control knob(I) clockwise to “OFF”. Wait 5 minutes, then repeat the lighting procedure as above. Once the appliance is lit, flame height can be controlled by adjusting the burner control knob between the “HIGH”...
  • Page 12 Please refer to part numbers when reordering For questions or comments about this product: Email: customer.service@bondmfg.com or Call toll-free: 1-866-BOND(2663) between 8:00AM and 5:00PM Pacific Coast time. Made in / Hecho en CHINA Dirtributed by Sears, Roebuck and Co., Hoffman Estates, IL 60176 See our extensive assortment of outdoor living products on-line at www.sears.com and www.kmart.com...
