Summary of Contents for Qupa M600
- Page 1 Manual Instruction Manual Multifunction Binder M600 PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn...
- Page 2 Manual Multifunction Binder Item: M600 1．Check Main body Paper flat Manual Instruction 1pc 2．Structure 1.Paper stop 2.Die set lock 3.Die set 4.Punching handle 5.Disengagement pins 6.Margin adjuster 7.Paper entrance 8.Paper flat 9.Waste paper drawer ① PDF 文件使用 "pdfFactory Pro" 试用版本创建...
- Page 3 3．Features 1. Various interchangeable die sets can be chosen for different punching purpose and combined binder S600 will conveniently binding punched documents. 2. Available Dies sets can be fit for following punching and binding purpose: 21 holes plastic comb 10 Holes Greenbinder 35 round / square holes double wire, pitch 1/3 inch 23 round / square holes double wire, pitch 1/2 inch 49 round holes coil, pitch 6mm...
- Page 4 ① Raise the front edge according to Fig shows to make sure paper flat has take off the main body ② Draw out the paper flat ③ Turn Die set lock to position OPEN ④ Draw out Die set 5. Die set choose and buy ·We developed 6 sets of normally used Die sets for choice ·When Die set bellow can’t fit your requirement, please email us for customization.
- Page 5 DIE-F23 23 Square hole dies set1 23 Square 1/2′ 5x5mm Φ5mm DIE-Y23 23 Round hole dies set 23 Round 1/2′ Φ4mm DIE-Y49 49 hole dies set 49 Round Note: DIE -F21 can also fit the punching & binding requirement of Greenbinder 6.
- Page 6 opening package, if there is no series label or it is unclear/incomplete, replace the machine with seller otherwise your after sales service may be refused. ·The machine weights around 30kgs, take care when moving. Working table should be steady. ·Away from water and keep machine dry. ·It is strictly prohibited to punch hard material such metal plate, when punching binding cover, the Maximum thickness should less than 1mm.
- Page 7 In the case ‘No good’, Please draw the disengagement pin out which corresponding to the broken place. When use DIE-F35/Y35 Die set to punch A4size sheets, the right first disengagement pin should be pull out to avoid broken. ⑤ Push down and turn Margin Width adjuster to set margin width, there are 2/4/6/8mm four classes (See chart below).
- Page 8 · Binding See Manual Instruction of S600-Multifunction Binder. It can bind 21rings, 24rings plastic comb and 2:1/3:1Double wire. ⑦ PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn...
