Summary of Contents for Minuteman RPM20161VN
- Page 1 RPM1581HVN RPM20161VN RPM2082HVI RPM20162VI (Remote Power Manager) User’s Manual...
-
Page 2: Table Of Contents
Table of Contents 1. IMPORTANT SAFETY INSTRUCTIONS .................. 1 2. Introduction ..........................3 3. RPM Package ........................... 4 4. Function ............................ 5 5. Installation ..........................6 6. Web Interface ........................... 7 7. Specifications .......................... 22 8. Obtaining Technical Assistance ....................23 9. -
Page 3: Important Safety Instructions
1. IMPORTANT SAFETY INSTRUCTIONS This manual contains important instructions that should be followed during the installation and the operation of the Remote Power Manager (RPM). SAVE THESE INSTRUCTIONS An Important Notice To ensure safety in all applications ensure that a Qualified Service Personnel installs the system. ... - Page 4 In the unlikely case that the RPM needs to be returned to MINUTEMAN, please use the original packing material. Since MINUTEMAN is not responsible for shipping damage incurred when the system is returned, the original packing material is inexpensive insurance.
-
Page 5: Introduction
2. Introduction The RPM is an Internet ready device designed and equipped with an intelligent current-meter (True RMS) that will indicate the total power consumption of the RPM. Features: Built-in web server. Build-in true RMS current meter. Easy setup. -
Page 6: Rpm Package
3. RPM Package The standard RPM package contains a Remote Power Manager unit with supporting hardware. The contents of the package are: Remote Power Manager unit. Rackmount Brackets. CD-ROM, which contains: User Manual. MIB files. ... -
Page 7: Function
4. Function Interface 7-segment LCD Functions Description Ethernet RJ45 port for the network communication. Audible Alarm Warning- 1 beep in 1 second. Overload- 3 beeps in 1 second. Note: The audible alarm will keep beeping until the current is lower than the threshold by 0.5 amps. -
Page 8: Installation
5. Installation This RPM series is ONLY intended to be installed in an indoor temperature controlled environment that is free of conductive contaminants. DO NOT operate the RPM in: extremely dusty and/or unclean areas, locations near heating devices, water or excessive humidity, or where the RPM is exposed to direct sunlight. Select a location, which will provide good air circulation for the RPM at all times. -
Page 9: Web Interface
6. Web Interface Login: Enter the IP address of RPM in a web browser. Note: The default setting for the IP address is DHCP enabled. If the RPM cannot get the IP from the DHCP server, the IP address will remain at the default IP address 192.168.0.216 The default User name is snmp. - Page 10 Information: RPM This screen displays the total current draw of the RPM.
- Page 11 Information: System Indicates the RPM’s system information, including: Model No. Firmware Version MAC Address System Name System Contact Location...
- Page 12 Control: Outlet Indicates the RPM’s outlet on/off status and control. Select the outlet by checking the box and then click the ON or the OFF button to control the outlet. ON: Press the ON button to turn on the assigned outlets. OFF: Press the OFF button to turn off the assigned outlets.
- Page 13 Control: Group This allows you to group multiple outlets for group control. Setting: Allows you to enter into the setting mode. Outlet: Allows you to assign the outlet to a group. Note: The identified outlets need to be listed in the alphabetical order. ON: Press the ON button to turn on the assigned group.
- Page 14 Control: Schedule This allows you to Schedule turning OFF/ON the RPM’s outlets. Outlet: Assign the outlet to be controlled in this schedule. Every: Set the schedule for an outlet using: a single day, an assigned weekly day, or every day. Date: When selecting the single day option “sgl”...
- Page 15 Control: Ping Action This allows you to Ping the device that is connected to a specific outlet and if there is no response the outlet can be rebooted. Automatically cycle’s power to a locked device connected to the RPM by rebooting the outlet. Ping IP Address: Set the IP address of the device to be monitored by the RPM.
- Page 16 Configuration: RPM Configure the outlet name and the delay time. Name: Rename the outlet. ON: Set the delay time for the power on sequence. OFF: Set the delay time for the power off sequence. Note: The maximum delay time is 255 seconds. Note ：...
- Page 17 Configuration: Threshold Set the warning and overload thresholds for entire RPM.
- Page 18 Configuration: User Change the ID (User name) and the password. The default ID (User name) is snmp and the password is 1234.
- Page 19 Configuration: Network Enter the network information or enable the DHCP function. The default setting for DHCP is enabled.
- Page 20 Configuration: Mail When an event occurs, the RPM can send out email messages to predefined accounts. Email Server: Input the email server’s domain name (does not support IP addresses). Sender’s Email: Input the sender’s email address. Email Address: Input the recipient’s email address. The email message format is as follows: Indicates the Outlets A~H-XXXXXXXX status in order X=0: means the outlet is off.
- Page 21 Configuration: SNMP When an event occurs, the RPM can send out SNMP Traps to predefined targets. Trap Notification: Set the IP address for the Trap receiver. Community: Set the SNMP community. The Read Community is public and fixed. The Default Write Community is “public” and can be changed.
- Page 22 Configuration: SSL These RPMs only support the SSLv1 protocol, which in most browsers is no longer supported. Please DO NOT ENABLE the SSL function, doing so will require resetting the RPM back to the factory default settings. See page 5 the ‘Function Button’ to reset to the factory default settings.
- Page 23 Configuration: Time This will allow you to setup the system time for the schedule control. Internet Time Setting: Get the time from an assigned network timeserver. System Time: Input the time manually.
-
Page 24: Specifications
7. Specifications Model Number RPM1581HVN RPM20161VN RPM2082HVI RPM20162VI Load Capacity 12Amps 16Amps 16Amps 16Amps (Max) INPUT PARAMETERS Number of Phases Single (12W +G) Nominal Voltage 100-120VAC 200-240VAC Frequency 50/60Hz Input Protection Re-settable circuit breaker OUTPUT PARAMETERS Nominal Voltage 100-120VAC 200-240VAC... -
Page 25: Obtaining Technical Assistance
Mark the RMA # on the outside of all packages. The factory cannot accept any package without the RMA # marked on the outside of the package. Return the unit by insured, prepaid carrier to: Para Systems Inc. MINUTEMAN UPS 1809 W. Frankford Road, Suite 150 Carrollton, TX 75007 ATTN: RMA # _______ Please have the information listed above ready when you contact us. -
Page 26: Limited Product Warranty
9. Limited Product Warranty Para Systems, Inc. (Para Systems) warrants this equipment, when properly applied and operated within specified conditions, against faulty materials or workmanship for a period of three (3) years from the date of purchase. For equipment sites within the United States and Canada, this warranty covers depot repair or replacement of defective equipment at the discretion of Para Systems.
