Congratulations with your new imported STENHØJ piston compressor. Please read and follow these instructions carefully, prior to using your new piston compressor. Contents Page List of types 1.1 Name plate 1.2 Technical data Before using your compressor 2.1 Safety precautions Function 3.1 Function 3.2 Usage...
Page 3
1.0 List of models 1.1 Name plate [ Date ] [ Type ] [ Serial no. ] [ Working pressure 1.2 Technical data Model no. Model Size of air Output R.P.M. No of Pressure Pressure D-O-L Motor receiver [L/min] cylinders stage [bar] [Kw]...
2.0 Before using your compressor When you have unpacked your compressor, kindly check carefully that the product is without defects and that nothing is missing. Kindly contact your STENHØJ distributor if you should find defects . Stationary compressor units must be mounted on vibration dampers. Connection to mains supply always to be carried out by STENHØJ service engineer or authorized electrician.
3.3 Limitations Do not use compressed air directly as breathing matter. If you require air in such a quality, kindly contact your STENHØJ distributor. If you have any questions in this regard, please contact your STENHØJ distributor. IMPORTANT Never direct outlet air towards human beings or animals. 4.0 Operation instructions 4.1 Where to place the compressor unit The compressor unit can be placed any place dry and frost-proof.
4.4 Pressurizing If motor is overloaded, the motor starter will stop the compressor unit. For safety rea- sons a safety valve is fitted with the pressure switch, the function of which is to equalize pressure if this exceeds max. allowable pressure for the unit in question. Do no touch the safety valve.
5.0 Maintenance 5.1 Maintenance The lifetime of the compressor unit depends on the maintenance carried out. There- fore check regularly oil level, belt tension and suction filter, and keep compressor block and motor clean. (Especially oleaginous dust on ribs reduces cooling). Oil: Change oil after app.
6.0 Trouble shooting • IMPORTANT 1) Switch off the current before remowing any parts from the compressor. 2) Empty the air receiver of air before dismantling any part of the compres- sor unit’s pressure system. SYMPTOM CAUSE REMEDY A. Compressor unit will not Fault in electrical installation: Let an electrician check the elec- start automatically.
Page 9
6.0 Trouble shooting SYMTOM CAUSE REMEDY F. Compressor can not at- Inlet underdimensioned, e.g. inlet pipe Dimension inlet pipe correctly - tain the required working between inlet and compressor. larger fresh air intake. pressure. Pressure gauge defective. Replace it. Unit too small in proportion to air con- Connect further capacity.
6.0 Trouble shooting SYMTOM CAUSE REMEDY K. Compressor’s oil con- Too much oil in compressor. Check oil level 2 or 3 minutes sumption rises. after stopping. Leaks around crank case. Change packing and inspect pack- ing surface. Repair or replace de- fective parts.
8.0 Spare parts STENHØJ offers the following spare parts kit for the various compressor types. Kindly note that only the spare parts kits as listed below are available.The kits are defined on the following pages. Ref. no. Designation Compressor type C49409 Packing kit, complete PL30...
Page 12
8.1 Drawing for compressorblock type PL30 8.1 Spare parts kit for compressorblock type PL30 -12-...
Page 13
Article no. C49409 Packing kit cpl. consist. of : Ref. no. Discription Qty. Cylinder head packing Packing for valve Packing for valveseat Packing for cylinder Oil filling assembly packing 1 Oil sight gauge packing Bearing seat packing * The spareparts kit is cpl. for the compressorblock Article no.
Page 14
8.2 Drawing for compressorblock type PL50 -14-...
Page 15
8.2 Spare parts kit for compressorblock type PL50 Article no. C49402 Packing kit cpl. consist. of : Ref. no. Discription Qty. Cylinder head packing Valve packing Valve seat packing Cylinder packing Oil filling assembly packing 1 Oil sight gauge packing Rear bearing seat packing * The spareparts kit is cpl.
Page 16
8.3 Drawing for compressorblock type PL75 -16-...
Page 17
8.3 Spare parts kit for compressorblock type PL75 Article no. C49406 Packing kit cpl. consist. of : Ref. no. Discription Qty. Cylinder head packing Packing for valve seat Packing for valve Packing for cylinder Oil sight gauge packing O-ring Rear bearing seat packing Cylinder head packing Packing for valve * The spareparts kit is cpl.
Page 18
8.3 Spare parts kit for compressorblock type PL75 Article no. C49207 Pistonring kit cpl. LP consist. of : Ref. no. Discription Qty. Packing for cylinder Pistonring kit Cylinder head packing Packing for valve * The spareparts kit is only for one cylinder Article no.
Page 19
8.4 Drawing for compressorblock type PL100 -19-...
Page 20
8.4 Spare parts kit for compressorblock type PL100 Article no. C49403 Packing kit cpl. consist. of : Ref. no. Discription Qty. Cylinder head packing Packing for valve seat Packing for cylinder O-ring Oil sight gauge packing Rear bearing seat packing * The spareparts kit is cpl.
Page 21
8.5 Drawing for compressorblock type TE50 -21-...
Page 22
8.5 Spare parts kit for compressorblock type TE50 Article no. C49404 Packing kit cpl. consist. of : Ref. no. Discription Qty. Cylinder head packing Packing for valve Packing for valve seat Packing for valve seat Packing for cylinder Cylinder head packing Oil sight gauge packing O-ring Rear bearing seat packing...
Page 23
8.5 Spare parts kit for compressorblock type TE50 Article no. C49205 Pistonring kit cpl. LP consist. of : Ref. no. Discription Qty. Packing for valve seat Packing for cylinder Pistonring kit Cylinder head packing * The spareparts kit is only for one cylinder. Article no.
Page 24
8.6 Drawing for compressorblock type TE75 -24-...
Page 25
8.6 Spare parts kit for compressorblock type TE75 Article no. C49406 Packing kit cpl. consist of : Ref. no. Discription Qty. Cylinder head packing Packing for valve seat Packing for valve Packing for cylinder Oil sight gauge packing O-ring Rear bearing seat packing Cylinder head packing Packing for valve * The spareparts kit is cpl.
Page 26
8.6 Spare parts kit for compressorblock type TE75 Article no. C49207 Pistonring kit cpl. LP consist of : Ref. no. Discription Qty. Packing for cylinder Pistonring kit Cylinder head packing Packing for valve * The spareparts kit is only for one cylinder. Article no.
Page 27
8.7 Drawing for compressorblock type TE100 -27-...
Page 28
8.7 Spare parts for for compressorblock type TE100 Article no. C49408 Packing cpl. consist of : Ref. no. Discription Qty. Cylinder head packing Packing for valve seat Packing for cylinder O-ring Oil sight gauge packing Rear bearing seat packing O-ring Cylinder head packing Packing for valve seat * The spareparts kit is cpl.
Page 29
8.7 Spare parts kit for compressorblock type TE100 Article no. C49209 Pistonring kit cpl. LP consist of : Ref. no. Discription Qty. Cylinder head packing Packing for valve seat Packing for cylinder Pistonring kit * The spareparts kit is only for one cylinder. Article no.
Page 30
8.8 Drawing for compressorblock type PE 50B -30-...
Page 31
8.8 Spare parts kit for compressorblock type PE 50B Article no. C49405 Packing kit cpl. consist. of : Ref. no. Discription Qty. Cylinder head packing Packing for valve seat Packing for cylinder O-ring Oil sight gauge packing Rear bearing seat packing * The spareparts kit is cpl.
