Summary of Contents for Santec SanStore-4HDX
- Page 1 USER MANUAL SanStore HD-SDI hybrid digital recorder Models: SanStore-4HDX SanStore-8HDX SanStore-16HDXS Version 1.1sfi/0715/engl/A5...
- Page 2 Please follow all instructions and observe the warnings contained in this manual. Please contact your local dealer or SANTEC directly if you have any questions or if you wish to claim for a service or warranty. You will find further information on our website: www.santec-video.com...
-
Page 3: Table Of Contents
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS Table of contents 1. General 1.1 Safety instructions and precautions 1.2 CE compliance 1.3 Important general notes 1.3.1 Assembly and installation 1.3.2 Repair and maintenance 1.3.3 Spare parts and accessories 1.4 Items included in the delivery 1.5 Apps for Apple iPhone and Android smartphones... - Page 4 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.2 Display 7.2.1 OSD 7.2.2 Monitor 7.2.3 Sequence 7.2.4 Spot 7.3 Storage 7.3.1 Setup 7.3.2 Format 7.3.3 NAS information 7.4 System 7.4.1 Date and time 7.4.2 Management 7.4.3 Audio 7.4.4 RS-485 7.5 Event 7.5.1 Sensor input 7.5.2 Relay output...
-
Page 5: General
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 1. General Please read this user manual carefully before starting to operate this device. Please retain this user manual for future reference. 1.1 Safety instructions and precautions Overcharge Never expose the power socket or the power cord to electrical overcharge. This may lead to fire and life-threatening shocks. -
Page 6: Important General Notes
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 1.3 Important general notes Please read the following instructions carefully. 1.3.1 Assembly and installation On-site installation should only be performed by qualified maintenance personnel and must meet local specifications and regulations. Never operate the equipment without the respective protective cover near water, in dusty rooms or extremely humid rooms. -
Page 7: Spare Parts And Accessories
Only use spare parts which are recommended by the manufacturer or which have identical characteristics. Non-approved spare parts may cause harm to people (electric shock) and may damage the device (fire). 1.4 Items included in the delivery SanStore-4HDX, SanStore-8HDX or SanStore-16HDXS Power cord AC adapter (power adapter) USB mouse CD (user manual, document on GPL licence) Set brackets for 19“... -
Page 8: Apps For Apple Iphone And Android Smartphones
They are not connected in any way with SANTEC BW AG. Proprietary rights are with the respective manufacturers or brand owners. Illustrations and pictures in this user manual are for better understanding only and may differ from the actual product design. -
Page 9: Control Elements And Indicators
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 2. Control elements and indicators 2.1 Recorder front panel Status LED indicators (Power, HDD, network, REC) 2x USB 2.0 ports (mouse, USB-stick) _________________________________________________________________________________ - 9 -... -
Page 10: Connections On Recorder Rear
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 2.2 Rear panel connections SanStore-4HDX (4 channels): SanStore-8HDX (8 channels): SanStore-16HDXS (16 channels): _________________________________________________________________________________ - 10 -... - Page 11 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 1. Power on/off 2. e-SATA HDD connection 3. VGA main monitor connections (15 pin) 4. 4x audio input cinch 5. Power connection 12 V DC 6. Alarm inputs, RS-485, relay output: 4, 8 or 16 alarm inputs (depending on recorder model) ...
-
Page 12: Controlling Via Mouse
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 2.3 Controlling via mouse You can control the recorder using a mouse. Connect a mouse (e.g. the one supplied with this shipment) to the USB port of the recorder’s front or rear panel. Left mouse click: Make a left mouse click to navigate through the menu and to make selections. -
Page 13: Pc Requirements And Network Connection
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 2.4 PC requirements for network connection Minimum Recommended Operating system Windows XP Windows 7 Core2 Duo @2,53 GHz Core i5 @3,3 GHz oder mehr Memory (RAM) 1 GB 2 GB Video memory card 512 MB... -
Page 14: Firmware Update
Products & Shop Videomanagement & recording SanStore HD-SDI digital recorder SanStore-4HDX (or SanStore-8HDX or Sanstore-16HDXS) Downloads Firmware/Software Information on which firmware version is currently installed on the recorder can be found here: ... -
Page 15: Switching The Recorder On And Off
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 4. Switching the recorder on and off 4.1 Switching on Verify that the camera(s) are properly connected to the recorder and that they are switched on. Connect one or several monitors to the recorder (VGA, HDMI, spot monitor BNC). - Page 16 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS If you start the recorder for the first time, you have to enter your login details. The following factory default login information are used. User name: ADMIN Password: 1234 To enter your password, left click on the virtual keyboard and confirm your entry by „Enter“...
-
Page 17: Logoff And Switching Off
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 4.2 Logout and switching the recorder off There are 2 options to logout from the recorder: Manually or automatically after a specified period of time. Manual logout: Click on this symbol in the tool bar: The following window pops up: If you click on “Log off”, you are logged off of the recorder and cannot use it anymore. - Page 18 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS Switching the recorder off: In order to finally switch off the recorder, it is not required to logout first (see previous section If you switch off the recorder without logging off, you are still logged in when powering the recorder the next time and you don’t need to enter your password again.
-
Page 19: Tool Bar
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 5. Tool bar Once you have switched on the recorder as previously explained, the live view (split view mode) of the connected cameras is displayed. If you are in live view mode and move the mouse cursor to the edge of the image, the... -
Page 20: Calling-Up The Main Menu
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 5.2 Calling up the main menu To call-up the main menu click on the following symbol in the tool bar: The following menu window is displayed: Close main menu In the main menu, settings can be made for: ... -
Page 21: Calling-Up The Backup Menu
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 5.3 Calling-up the backup menu To call-up the backup menu, click on the following symbol in the tool bar: A little window is displayed where you can define the following for the backup: Format: .avi or .dvr... -
Page 22: Calling-Up The Search Menu
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 5.4 Calling-up the search menu To call-up the search menu, click on the following symbol in the tool bar: The following menu window is displayed: You can search for video recordings by the following categories (see tabs in upper left corner... -
Page 23: Search Menu: Time
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 5.4.1 Search menu: Time To search for a recording by time, please proceed as follows: 1. Day selection: In the calendar, the recording days are highlighted in blue. Click on the blue marked recording day. - Page 24 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS Right-click on the hour or the minute to define the start time or end time for the backup (copy). 3. Playback: Here you can define the view mode for the playback: 16-split view mode 9-split view mode...
- Page 25 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 4. Copy: Here you can store (copy) video recordings on an external device. From: Enter the start date and time for the backup. By default, the last 10 minutes are defined for backup. To change the date/time, please double-click in the date/time field. A window is displayed.
-
Page 26: Search Menu: Panorama
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 5.4.2 Search menu: Panorama Use the panorama search to search for events in 16-split view mode. To search for a recordings by using the panorama search, please proceed as follows: 1. Day selection: In the calendar, the recording days are highlighted in blue. Click on the blue marked recording day. -
Page 27: Search Menu: Event
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 5.4.3 Search menu: Event To search for a recordings by using the event search, please proceed as follows: 1. Day selection: In the calendar, the recording days are highlighted in blue. Click on the blue marked recording day. -
Page 28: Calling-Up The Display Menu
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 5.5 Calling-up the display menu To call-up the display menue, click on the following symbol in the tool bar: You can select the display format. Single view 4-view 9-view 16-view Start sequence on main monitor... -
Page 29: Calling-Up The Ptz Menu
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 5.6 Calling-up the PTZ menu Note: The PTZ menu can only be used if a PTZ enabled camera is connected. If you are in a multi-split viewing mode, the PTZ control is enabled for the selected camera. If you haven’t selected a camera before, the PTZ control is enabled for camera number 1. - Page 30 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS Preset: Preset number: Use the up/down arrows to select the desired preset (0 – 256). Go to Auto xcan Tour: Tour number: Use the up/down arrows to select the desired tour (1 – 6).
-
Page 31: Digital Zoom
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 5.7 Digital zoom There are 2 options to control the digital zoom: Either by using the zoom symbol in the tool bar or by using the mouse in the camera imge. Zoom by using the zoom symbol in the tool bar: To call-up the menu for the digital zoom, please click on the following symbol in the tool bar: If you are in a multi-split viewing mode, the digital zoom is enabled for the selected camera. - Page 32 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS Zoom by using the mouse in the camera image: You can use the mouse to zoom the camera image. Display the desired channel as full screen. Left-click into the image and draw an area in the image which you would like to zoom.
-
Page 33: Log Lists
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 5.8 Calling-up the log list To call-up the menu for the log list, please click on the following symbol in the tool bar: In the displayed window, the logs are sorted chronologically (the newest log is on top of the list). -
Page 34: Quick Menu
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 6. Quick menu You can call-up the quick menu by right-clicking in the live view image (either in full screen or in split screen): The following quick menu is displayed: Freeze on: If you click on „Freeze on“, all images on all channels will be freezed. Wenn Sie auf „Standbild ein“... - Page 35 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS PTZ: If you select „PTZ“, the PTZ control menu will be displayed in the video image. The PTZ control can only be used by one authorized user. PTZ will be activated for the channel you have selected.
- Page 36 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS Live audio: If you select „Live audio“, you can choose audio channels 1-4. Important note: Regarding transmission and recording of audio data, please respect the laws and legal regulations which apply in your country. Playback: Selecting „Playback“...
-
Page 37: Main Menu
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7. Main menu To configure the recorder you have to call-up the main menu. To call-up the main menu, please click on the following symbol in the tool bar: The following window is displayed: Here you can make configurations for: ... -
Page 38: Camera
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.1 Camera Click on the camera symbol. 7.1.1 Title Double-click in the entry field of the respective channel to bring-up the virtual keyboard. You can now enter a camera name (title) consisting of max. 10 characters. -
Page 39: Setup
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.1.2 Adjust For each camera, the following parameters can be set: Brightness Contrast Saturation For each parameter, the range of value is 0-100%. Click on „OK“ to confirm your entry and to return to the main menu. -
Page 40: Ptz
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.1.3 PTZ For each camera, the following parameters can be set: Address: ID of the PTZ camera Protocol: Protocol of the PTZ camera Baud rate: Baud rate of the PTZ camera ... -
Page 41: Motion Detection
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.1.4 Motion Sensitivity: For each camera, the sensitivity can be set (1-10) and the area of motion detection can be defined. Area setup: If you click on „Area setup“, the video image is covered with a grid. Motion is either detected for the entire grid or for individual grids/areas. - Page 42 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS You can define individual areas for motion detection by left-clicking in the desired grid cell(s). This cell is hence enabled and displayed in grey. If you click again the the cell(s), they will be disabled again.
-
Page 43: Privacy Masking
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.1.5 Privacy masking For each channel, privacy masking zones can be defined, i.e. these areas will be masked (covered) in live view as well as in playback. Define privacy masking zones: Drag with the left mouse button an area into the desired position. Once you release the button, a little menu window is displayed. -
Page 44: Display
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.2 Display Click on the display symbol. 7.2.1 OSD Here you can make adjustments for the following settings: Toolbar display time: Define whether the tool bar is to be displayed „Always on“ or whether it will be hidden after a specified period of time (5/10/15/20/30 sec, 1 min). - Page 45 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS Border colour: If you have actived the „Border“ function (see above), then you can define the border colour to frame each image in the multi-split view. Event icon: Define whether the event icon (alarm, video loss) is to be displayed in the video image.
-
Page 46: Monitor
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.2.2 Monitor Here you can make the following adjustments: Alarm pop-up mode: If set to „On“, an alarm input will cause the associated channel to be displayed in full screen. Alarm pop-up dwell: Determine how log the full screen pop-up is to be displayed after an alarm has occurred (3-60 sec). -
Page 47: Sequence
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.2.3 Sequence The following settings can be adjusted: Sequence dwell: Define the time that each screen is displayed in a sequence operation. Spot sequence dwell: Define the time that each screen is displayed in a spot sequence operation. -
Page 48: Spot
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.2.4 Spot The following settings can be adjusted: Spot covert: If you click on „Detail“, you can define for each channel whether it is to be covered or not. Spot operation mode: You can choose from „Single“ „4-Multi“, 9-Multi“ or „16-Multi“. -
Page 49: Storage
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.3 Storage Click on the storage symbol. 7.3.1 Setup The following settings can be adjusted: Overwrite: If enabled, the data will be overwritten. Recording time limit: Define the duration (12 hours to 2 months). - Page 50 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS Record: Select the HDD as record HDD. Mirror. Select the HDD as mirroring HDD. SMART: You can view the HDD’s configuration: Good = The current HDD condition is good. Bad = The current HDD condition is bad.
-
Page 51: Format
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.3.2 Format The following settings can be adjusted: HDD type: You can select „Record“ or „Mirror“. Click on „Format“ to format the HDD. Attention: Formatting a HDD means to delete all stored data on the HDD. -
Page 52: Nas Information
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.3.3 NAS Information Here you can provide the following information on the NAS server: Host name: IP-address of the NAS server. Backup directory: Directory in the NAS server User ID, password: User name and password to login to the NAS server. -
Page 53: System
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.4 System Click on the system symbol. 7.4.1 Date and time The following settings can be adjusted: Date/time: Enter the correct date and time and confrim by clicking „Apply“. Date format: Determine how the date is to be displayed. -
Page 54: Management
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS Adjust period: Define whether the recorder is to synchronize with the NTP server and enter the interval. Time zone: Select your time zone. DST: When set to „On“, the recorder will automatically adjust the time by one hour regarding start and end of Daylight Savings Time. - Page 55 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS System name: Double-click on „System ID“ to bring-up the virtual keyboard. Now enter a name (max. 15 characters). Confirm your entry by clicking “Enter” on the virtual keyboard. F/W upgrade: You can use a USB stick to perform a firmware update.
-
Page 56: Audio
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.4.3 Audio The following settings can be adjusted: Live audio: If enabled, audio is activated in the live image. default audio channel: Specify which one of the four audio inputs is routed to the audio output. -
Page 57: Rs-485
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.4.4 RS-485 The following RS-485 settings can be adjusted: System ID: Define an ID for the external device connected to the RS-485 port. Baud rate: Define a Baud Rate for the external device connected to the RS-485 port. -
Page 58: Event
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.5 Event Click on the event symbol. 7.5.1 Sensor input Operation: Enable or disable the sensor input per channel, i.e. action when a sensor alarm is triggered. You may also select the panic recording function for this channel. -
Page 59: Relay Output
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.5.2 Relay output The following settings can be adjusted: Relay out: Define the relay for the alarm output. Operation: Enable/disable the alarm output. Mode: o Transparent: Keep the relay output until the event trigger has stopped. -
Page 60: Buzzer Output
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.5.3 Buzzer output The following settings can be adjusted: Operation: Enable/disable the buzzer. HDD event: If enabled, the buzzer will be active in case of a HDD event. Mode: o Transparent: Keep the relay output until the event trigger has stopped. -
Page 61: E-Mail
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.5.4 E-mail The following settings can be adjusted: Notice: If enabled, an e-mail will be sent when an alarm is triggered. In addition, en e-mail server has to be installed in your network settings. This e-mail address has to be entered there and the box “Send e-mail”... -
Page 62: Ptz Preset
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.5.5 PTZ preset The following settings can be adjusted: PTZ camera: Select the PTZ camera to which the following configurations are to be applied. Operation: Enable/disable the PTZ preset function. Sensor: Determine presets (0-255) if an alarm is triggered. -
Page 63: Push Alarm
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.5.6 Push Alarm Determine whether an e-mail notification is sent in case of a sensor alarm, a video loss or a motion detection. _________________________________________________________________________________ - 63 -... -
Page 64: User
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.6 User Click on the user symbol. 7.6.1 Register By default, the user is „ADMIN“ and the password is „1234“. Up to 10 user accounts can be created. _________________________________________________________________________________ - 64 -... - Page 65 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS Double-click on the user (or, alternatively, in the e-mail field) to bring-up the following window: The user ID is indicated. The password is hidden by dots. If you enable “E-mail send” you can double-click in the e-mail field to bring-up the virtual keyboard and make your entry.
-
Page 66: Authority
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.6.2 Authority The following settings can be adjusted by ticking the respective boxes: Search & play: The user has the authority to enter the search menu and to start playbacks. Copy: The user has the authority to enter the backup menu and to make copies. -
Page 67: Logout
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.6.3 Logout The following settings can be adjusted: Auto logout: Enable/disable the automatic logout function. Duration: If you have enabled the auto logout function (see above), you can define when the automatic logout should happen (after 1-99 minutes). -
Page 68: Record
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.7 Record Click on the record symbol. 7.7.1 Setup Size: Select the individual resolution per channel. If you choose “All”, the resolution will be set as follows: o If „All“ =25 % Channel 1 = 940x540; other channels = 480x288 o If „All“... -
Page 69: Event
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.7.2 Event If an event occurs, the following settings can be adjusted: Motion event: In case of a detected motion, the following settings can be made: o FPS: NTSC: 0, 1, 2, 4, 5, 8, 10, 15, 30 frames per second. -
Page 70: Schedule
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.7.3 Schedule The following settings can be adjusted: Go to menu item „Misc.“ (see chapter 8.7.4) and select as schedule mode „daily“ or „weekly“. Then return to the schedule page. As „type“ please select the type of recording: ... - Page 71 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS „Weekly“: You can configure the recording type by hour (24 hours) and by channel; click in the respective grid cell. In this mode, you can configure a separate schedule for every single day of the week.
-
Page 72: Panic
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.7.4 Panic During panic recording, all other recordings will be stopped. The panic recording will run on all channels according to the below specified settings: Size: Select the individual resolution per channel. If you choose “All”, the resolution will be set as follows: o If „All“... -
Page 73: Miscellaneous
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.7.5 Miscellaneous Schedule mode: Select „daily“ or „weekly“. This information is important for schedule definition (also see chapter 8.7.3.) Pre-event recording time: Define the amount of footage that is always recorded before an event occurs (0-5 seconds). -
Page 74: Network
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.8 Network Click on the network symbol. 7.8.1 IP setup The following settings can be adjusted: DHCP: If DHCP is enabled, the recorder will obtain an Ethernet IP address automatically if connected to a DHCP server or router. - Page 75 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS IP address: If DHCP is disabled, enter an IP address here manually. Gateway: If DHCP is disabled, enter a gateway here manually. Subnet mask: If DHCP is disabled, enter a subnet mask here manually.
-
Page 76: Ddns
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.8.2 DDNS The following settings can be adjusted: DDNS: If DDNS is enabled, the recorder can be accessed through a dynamic DNS server. This is commonly used if a broadband connection does not have a static IP address. -
Page 77: E Mail
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 7.8.3. E-mail The following settings can be adjusted: Use default server: If enabled, e-mail notifications will be sent by your own mail server. Server: SMTP outbound e-mail server which should be used to send e-mail notifications. -
Page 78: Remote Access
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 8. Remote access There are several options to access the recorder remotely: Either by using the web server or by using a smart phone (Android Viewer, iOS Viewer). 8.1 Remote access via web server The recorder prepares the web server internally. This server consists of two services. One is for the remote configuration of DVR setup and the other is for the client viewer based on the ActiveX. -
Page 79: Connection To Web Server
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 8.1.1 Connection to web server Open your web browser and enter the IP address of the recorder into the address field. Example: http://192.168.123.54:80 You will find the recorder’s IP address and web server port here: ... -
Page 80: Configuration Page
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 8.1.2 Configuration page Once you have called-up the recorder via the web browser (as described in chapter 8.1.1), you can configure the recorder settings via the configuration page. Note: The configuration page will automatically close again if you have been idle for 5 minutes after login. - Page 81 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 8.1.2.1 Camera Title: For setting options and descriptions please see chapter 7.1.1. Setup: For setting options and descriptions please see chapter 7.1.2. PTZ: For setting options and descriptions please see chapter 7.1.3. _________________________________________________________________________________ - 81 -...
- Page 82 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS Motion: For setting options and descriptions please see chapter Kapitel 7.1.4. Privacy masking: For setting options and descriptions please see chapter Kapitel 7.1.5. _________________________________________________________________________________ - 82 -...
- Page 83 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 8.1.2.2 Display OSD: For setting options and descriptions please see chapter 7.2.1. Monitor: For setting options and descriptions please see chapter 7.2.2. Sequence: For setting options and descriptions please see chapter 7.2.3. _________________________________________________________________________________ - 83 -...
- Page 84 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS Spot: For setting options and descriptions please see chapter 7.2.4. _________________________________________________________________________________ - 84 -...
- Page 85 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 8.1.2.3 System Date/time: For setting options and descriptions please see chapter Kapitel 7.4.1. Management: For setting options and descriptions please see chapter 7.4.2. Audio: For setting options and descriptions please see chapter 7.4.3. _________________________________________________________________________________ - 85 -...
- Page 86 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 8.1.2.4 User Add user: For setting options and descriptions please see chapter 7.6.1. Authority: For setting options and descriptions please see chapter 7.6.2. Logout: For setting options and descriptions please see chapter 7.6.3. _________________________________________________________________________________ - 86 -...
- Page 87 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 8.1.2.4 Network IP-Einstellung: For setting options and descriptions please see chapter 7.8.1. DDNS: For setting options and descriptions please see chapter 7.8.2. E-mail: For setting options and descriptions please see chapter 7.8.3. _________________________________________________________________________________ - 87 -...
- Page 88 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 8.1.2.5 Event Relay input: For setting options and descriptions please see chapter 7.5.1. Relay output: For setting options and descriptions please see chapter 7.5.2. Buzzer output: For setting options and descriptions please see chapter 7.5.3.
- Page 89 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS E-mail: For setting options and descriptions please see chapter 7.5.4. PTZ preset: For setting options and descriptions please see chapter 7.5.5. 9.1.2.6 Storage For setting options and descriptions please see chapter 7.3. _________________________________________________________________________________ - 89 -...
- Page 90 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 8.1.2.7 Record Continuous recording: For setting options and descriptions please see chapter 7.7.1. Event: For setting options and descriptions please see chapter 7.7.2. Schedule: For setting options and descriptions please see chapter 7.7.3. _________________________________________________________________________________ - 90 -...
- Page 91 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS Panic: For setting options and descriptions please see chapter 7.7.4. Miscellaneous: For setting options and descriptions please see chapter 7.7.5. _________________________________________________________________________________ - 91 -...
-
Page 92: Web Viewer
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 8.1.3 Web Viewer The Web Viewer opens independently of the web browser. Login with your user name and password. (Factory default: User = ADMIN; Password = 1234) 8.1.4 Live view Once you have logged in, the following live view is displayed: The currently selected camera has a yellow border. - Page 93 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 1. The recorder’s IP is displayed. 2. The display mode is indicated: Single camera view Quad view (4x) 3. Minimize, maximize, close buttons: Minimize the window Maximize the window Close the window 4. Reconnect, live/search, full screen: Logout and reconnect Toggle between live view and search/playback.
-
Page 94: Jpeg Snapshots, Ptz Control, Video Configuration
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 8.1.5 JPEG snapshots, PTZ control, video configuration Using the web viewer, you will have the following options: Save as JPEG file PTZ control Listen to audio Video configuration Right-click into the video image to bring-up the following little window:... -
Page 95: Search & Playback
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 8.1.6 Search & playback Click here to start the search/playback function and to return to the live view. 1. The recorder’s IP is displayed. 2. The display mode is indicated: Single view Quad view (4fx) 3. - Page 96 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 4. Control bar for playback speed: Use the bar to adjust the playback speed: Click on right half of the bar = Fast forward Click on left half of the bar Fast reverse Center click Normal speed 5.
- Page 97 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS Yellow: Selected hour and minute. Green: Continuous recording Red: Event recording Double-click in a minute cell to start the recording playback. Right-click to open a little window: Enter the start time and end time of the recording.
-
Page 98: Remote Access Via Smartphone (Android Viewer, Ios Viewer)
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 8.2 Remote access via smartphone (Android Viewer, iOS Viewer) Pocket Viewer Viewer for Android smartphones iPocket Viewer Viewer for iOS smartphones 8.2.1 Start Pocket Viewer / iPocket Viewer When you start the Pocket Viewer / iPocket Viewer application, the following windos is displayed: ... - Page 99 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 8.2.1.1 Quick connect DVR Address: IP address of recorder Port Number: Port number of recorder User ID, Password: Enter the user name and password for the recorder (factory default: ADMIN, 1234). ...
- Page 100 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 8.2.1.2 DVR list New: A new recorder will be added to the list. Enter the required data about the recorder. Edit: The current recorder list can be edited. Delete: The current recorder list will be deleted.
-
Page 101: Technical Specifications
User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS 9. Technical specifications SanStore-4HDX SanStore-8HDX SanStore-16HDXS Model 4 channels 8 channels 16 channels Recorder type HD-SDI hybrid digital video recorder Video input (HD-SDI) 1x VGA (1920x1080), 1x HDMI (1920x1080), BNC spot monitor Video output output... - Page 102 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS GNU GPL License note Certain open source components are licensed pursuant to GNU General Public License. This establishes that the customers have the right to acquire, modify and redistribute the source code of said software in accordance with the terms of the GNU General Public License or Lesser General Public License.
- Page 103 User manual SanStore-4HDX, SanStore-8HDX, SanStore-16HDXS Notes: _________________________________________________________________________________ - 103 -...
- Page 104 Your local distributor: __________________________________________________________________________ www.santec-video.com...
