Summary of Contents for Ness Security Products M1RF
- Page 1 INSTALLATION MANUAL Ness M1RF Wireless Receiver Specifications, Installation and Programming (Version 1.4 - May 2008) Ness Document No. 895-364 Page 1...
-
Page 2: Specifications
PIRs. The M1RF receiver is wired to the M1 via the 4 Wire High Speed Data bus and receives signals for connecting radio detectors and radio keys to the Ness M1 cross platform controller. - Page 3 ° The Ness M1RF Receiver connects onto the M1 data bus, which uses 4-wires. However, CAT5 or CAT6 eight (8) conductor is recommended for all data bus cables. The extra wires are for data return paths. If cable is to be installed in installations where electrical noise maybe present then a twisted pair shielded cable should be considered.
- Page 4 Programming. Ness RP Wireless Set-Up 1. In NessRP click on "Wireless Setup" then "New" to assign zone to be wireless. New Wireless Expander 2. Select the zones (that match the address of the wireless expander module) for the zone to be allocated for wireless .
- Page 5 3. Configure all your wireless zones in the "Wireless Expander" and then 'send' the data to the M1 System. LEARNING IN DEVICES INTO THE M1 From within Installation program mode select menu 14 “Wireless Definition”. Press RIGHT arrow key to select this menu. Press UP or DOWN arrow keys to select menu 3 “Learn Wireless Transmitter”.
- Page 6 Receiving Data to NessRP Once transmitters have been learnt into the M1 their data can be uploaded to NessRP. RIGHT mouse click on "Wireless Setup" and then select "Receive Wireless Setup" Once data has been received their Tx ID's can be viewed when wireless "Transmitters" tab is selected.
- Page 7 To change setting in the transmitter settings, click on the Zone and then change. Enabled - Ensure this is ticked to enable the Wireless Transmitter to be activated by the M1 Control Panel. Supervised - Select if you require the Zone to be Supervised.
- Page 8 AND Last User was Pam Kingsley (user 3) THEN Turn Garage Door2 (Out 10) ON for 2 seconds Ness Security Products Pty Ltd Sydney (02) 8825 9222 - Melbourne (03) 9875 6400 - Brisbane (07) 3399 4910 - Perth (08) 9328 2511 - Adelaide (08) 8152 0000 email m1support@ness.com.au...
