dCS Network Bridge
Network Interface

User Manual

Software Release 1.0x
December 2016
© Data Conversion Systems Ltd. 2016
Price UK £10.00
All rights reserved. No part of this publication may be reproduced, stored in or introduced into a retrieval system,
or transmitted in any form, or by any means (electronic, mechanical, photocopying, recording or otherwise)
1
without the prior written permission of dCS
. Any person who does any unauthorised act in relation to this
publication may be liable to criminal prosecution and civil claims for damages.
Information contained in this manual is subject to change without notice, and whilst it is checked for accuracy, no
liabilities can be accepted for errors.
1
dCS is Data Conversion Systems Ltd. Company registered in England No. 2072115.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DCS Network Bridges and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Data Conversion Systems DCS Network Bridges

  • Page 1: User Manual

    Information contained in this manual is subject to change without notice, and whilst it is checked for accuracy, no liabilities can be accepted for errors. dCS is Data Conversion Systems Ltd. Company registered in England No. 2072115.
  • Page 2 dCS Network Bridge User Manual Software Issue 1.0x December 2016 Page 2 Network Bridge Manual v1_0x English version...

  • Page 3: Table Of Contents

    dCS Network Bridge User Manual Software Issue 1.0x December 2016 Contents   Using the dCS Network Bridge for the first time .................. 4   What’s in the box?   Positioning the unit   Important safety instructions   Safety notice   Step-by-Step Guide ..........................

  • Page 4: Using The Dcs Network Bridge For The First Time

    dCS Network Bridge User Manual Software Issue 1.0x December 2016 dCS N SING THE ETWORK RIDGE FOR THE FIRST TIME Congratulations on purchasing your dCS Network Bridge. This device is designed to stream digital audio data over a network from a NAS drive and present it in a format that is compatible with most DACs.

  • Page 5: Important Safety Instructions

    dCS Network Bridge User Manual Software Issue 1.0x December 2016 Important safety instructions The following statements are required to comply with U.S. safety standard UL60065. • Read these instructions. • Keep these instructions. • Heed all warnings. • Follow all instructions. •...

  • Page 6: Safety Notice

    dCS Network Bridge User Manual Software Issue 1.0x December 2016 Safety notice In the event of the unit developing a fault, please contact your dealer in the first instance. If you decide to remove safety covers for any reason, disconnect the power cable first. Note that removing covers voids the warranty.

  • Page 7: Step-By-Step Guide

    dCS Network Bridge User Manual Software Issue 1.0x December 2016 UIDE This section guides you through setting up the unit for basic operation. Preliminaries For digital interfaces, use with cables designed for digital audio: • for AES/EBU interfaces use 110Ω screened, twisted pair cables fitted with one male XLR connector and one female XLR connector.

  • Page 8: Step 1 - Connecting An Output

    dCS Network Bridge User Manual Software Issue 1.0x December 2016 STEP 1 – Connecting an output Choose one or more of the following sections: Connecting the Dual AES Output The Dual AES interface is most commonly used as it is the output with the highest sample rate capability.

  • Page 9: Step 2 - Network Setup

    dCS Network Bridge User Manual Software Issue 1.0x December 2016 STEP 2 – Network setup UPnP (Universal Plug and Play) is a set of protocols designed to allow consumer devices to interact over a network. The Network Bridge complies with the UPnP AV protocol, enabling it to communicate with other non-dCS devices, provided they also comply with this protocol.
  • Page 10 dCS Network Bridge User Manual Software Issue 1.0x December 2016 • For iPad or iPhone/iPod, download the dCS Network Bridge app from the App Store and install it. • Connect the Network Bridge’s Network interface to the Ethernet network. • Connect the control device (e.g. iPhone) to the network. •...

  • Page 11: Step 3 - Unit Setup

    dCS Network Bridge User Manual Software Issue 1.0x December 2016 STEP 3 - Unit setup On the Devices page, tap Configure to get information about the unit or change the Network Bridge’s settings. Information … Unit Status to see some useful information about your unit.
  • Page 12 dCS Network Bridge User Manual Software Issue 1.0x December 2016 Version to see the software versions loaded in your unit. You will need this information if you contact your dealer for advice. (See the Software Update section at the end of the manual for information on updating.) Go back 2 levels and tap Unit...
  • Page 13 dCS Network Bridge User Manual Software Issue 1.0x December 2016 Go back 1 level and tap Playback Controls … Setting Phase Inverted changes the absolute phase of both channels to correct a phase error in the track. Tap the Channel Swap toggle to temporarily correct for a connection error.
  • Page 14 dCS Network Bridge User Manual Software Issue 1.0x December 2016 Tap each setting to see the options. Favourite Inputs allows you to select which internet services appear on the Home page. Favourite Servers allows you to select which servers on the network appear on the Home page.

  • Page 15: Step 4 - Playing Music

    dCS Network Bridge User Manual Software Issue 1.0x December 2016 STEP 4 – Playing music Selecting music Home page. • Tap on Music – note that different server software reports different information. • Select the browsing method (Artist, Album, etc.). (If you need to change the settings from here, tapping the icon takes you to the...
  • Page 16 dCS Network Bridge User Manual Software Issue 1.0x December 2016 • If you selected browse by Album, navigate • Choose either All Tracks to play the whole down to the track list. album or Selected Tracks and then tap on the tracks you want to play.

  • Page 17: Current Track

    dCS Network Bridge User Manual Software Issue 1.0x December 2016 Current track Shuffle tracks. Repeat track. Change phase. Adjust volume. • Set the volume slider as required, then tap the white to close the volume panel. Note that the Network Bridge volume control is not linked to the DAC’s volume control. We recommend setting the Network Bridge volume to maximum and controlling the volume from the DAC or preamplifier where possible.

  • Page 18: Playlists

    dCS Network Bridge User Manual Software Issue 1.0x December 2016 Playlists Tap on a list or the Play Queue to open it. To delete a Playlist, swipe it to the left and tap Delete. Select a track and tap the Play icon to start playing it.

  • Page 19: Search

    dCS Network Bridge User Manual Software Issue 1.0x December 2016 Search While browsing albums, artists or tracks, you can search for some text in the list. Tap on the Search icon – the keyboard will appear. Type the text you want to search for (or just part of it).

  • Page 20: Playing Music With Airplay

    dCS Network Bridge User Manual Software Issue 1.0x December 2016 Playing music with AirPlay When the Network Bridge is connected to a network, music can be streamed from an Apple device via AirPlay to the Network Bridge. Take care when using AirPlay, as the volume set by the sending device can be very high.

  • Page 21: Step 5 - Using A Master Clock

    dCS Network Bridge User Manual Software Issue 1.0x December 2016 STEP 5 – Using a master clock So far, the system has been set up with the Network Bridge in Master Mode. If you are using the SDIF-2 interface, the DAC will lock to a word clock generated by the Network Bridge. The basic Sync Mode for the Network interface is Master Mode because it has an asynchronous Network interface.

  • Page 22: Step 6 - Using The Web Client Interface

    dCS Network Bridge User Manual Software Issue 1.0x December 2016 STEP 6 - Using the web client interface You can access the web client interface from a web browser running on any device connected to the same network. First, run ipconfig (or a similar utility) and note the IP address of the Network Bridge (10.20.30.183 in this example).

  • Page 23: Rear Panel

    dCS Network Bridge User Manual Software Issue 1.0x December 2016 ANEL Figure 4 – Rear panel AES digital outputs AES1 AES2 outputs (A & B) can be used individually at 44.1, 48, 88.2, 96, 176.4 or 192kS/s or DSD/64 in DoP format, or as a Dual AES pair at 88.2, 96, 176.4, 192, 352.8 or 384kS/s or DSD/64 or DSD/128 in DoP format.

  • Page 24: Network Interface

    dCS Network Bridge User Manual Software Issue 1.0x December 2016 Network interface Network connection on an RJ45 socket (H) allows the Network Bridge to act as a UPnP renderer, streaming music data from a NAS drive or a local computer over a standard 10/100/1000 Ethernet network.

  • Page 25: Specification

    dCS Network Bridge User Manual Software Issue 1.0x December 2016 PECIFICATION Type Network streaming bridge Colour Silver or Black. Dimensions 360mm (14.2”) wide x 245mm (9.65”) deep x 67mm (2.65”) high. Allow extra depth for cable connectors. Weight 4.6kg (10.2lbs). Digital Inputs Network interface on an RJ45 connector –...

  • Page 26: Maintenance And Support

    dCS Network Bridge User Manual Software Issue 1.0x December 2016 AINTENANCE AND UPPORT Service and maintenance dCS audio products are designed not to need regular maintenance, and contain no user serviceable parts apart from the mains fuse. If your unit is damaged in any way, please contact your dealer. Replacing a blown mains fuse There is a mains fuse below the power inlet, accessible from the outside of the unit.

  • Page 27: Limited Warranty

    dCS Network Bridge User Manual Software Issue 1.0x December 2016 Limited warranty General dCS warrants this product against defects in materials and workmanship for a period of 3 years from the date the unit was originally shipped from dCS. If the product is purchased and registered with dCS within 6 months of the date the unit was originally shipped from dCS, we will start the warranty on the purchase date.

  • Page 28: If You Need More Help

    If you need more help In the first instance, you should contact your dealer. If they cannot resolve the issue, contact your national distributor. Manufactured by: Data Conversion Systems Ltd. Unit 1, Buckingway Business Park, Anderson Road, Swavesey, Cambridgeshire. CB24 4AE www.dcsltd.co.uk...

  • Page 29: Index
