Congratulations, you are the proud owner of an outstanding, stylish and durable product to give

you many years of enjoyment.

Japidi Energy Heaters are manufactured in Canada and come with a 7 year warranty against

faulty workmanship (excluding the element and electrical connections).

Certified to: CSA C22.2 No. 46-M1988 UPD 3, UL 2021 & UL 1278-9-06

Although Japidi Energy IR Heaters are very safe to use, read these instructions before use. Turn

power off before servicing heater or replacing any parts. All electrical work should be done

according to appropriate electrical codes.

1. Read all safety warnings and instructions. Failure to follow the warnings and instructions

may result in electric shock, fire and/or serious injury;

2. If you can't find the answer, consult our website at www.japidi.com;

3. Do not expose your Japidi Energy Heater to rain or wet conditions. Water entering the

heater will increase the risk of electric shock;

4. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the heater;

5. When using the heater outdoors, use an extension cord suitable for outdoor use;

6. Do not cover or obstruct the heater while it is in use;

7. The electrical connections to the heater must be earthed;

8. Avoid the use of the Japidi Energy Infrared Heater by children or incapacitated persons;

9. Disconnect or unplug the unit during installation, repairs or replacement of the element;

10. Do not touch the heater body while the unit is burning. To avoid the risk of burns, always

make sure the element and the heater body is cool;

11. Do not touch the halogen element with bare hands. If the element is unintentionally

touched, remove the finger marks with a soft cloth and methylated spirits or alcohol. Failure

to do so results in permanent marks burning into the element causing premature element

failure. If you do need to hold or remove the element, always use a soft and clean cloth;

12. Do not insert any object through the front grid or opening of the heater;

13. Do not install more heaters on your electric circuit then allowed by your local electrical

regulations. Prior to installation you must check requirements with regards to available

OUR GUIDE TO INSTALLATION

INFRARED HALOGEN HEATERS

WARNINGS!

Table of Contents

Need help?

Do you have a question about the DELUXE 500 and is the answer not in the manual?

Questions and answers

Summary of Contents for Japidi Energy DELUXE 500

Page 1 Certified to: CSA C22.2 No. 46-M1988 UPD 3, UL 2021 & UL 1278-9-06 WARNINGS! Although Japidi Energy IR Heaters are very safe to use, read these instructions before use. Turn power off before servicing heater or replacing any parts. All electrical work should be done according to appropriate electrical codes.
Page 2 3ft away from the front of heater and 1ft from the side, top and rear; 17. CAUTION: Heater can be used outside and in damp conditions, but must be sheltered from rain, snow or any water. The Japidi Energy Infrared Halogen Heater is NOT waterproof. INSTALLING YOUR WALL OR CEILING MOUNTED HEATER 500W / 1500W / 3000W 1.
Page 3 4. When heater is aimed at the right angle fasten the bolts on side of heater and bracket to keep heater in angled position; 5. CAUTION: For residential and public heating: mount heater at 2.4m or 8ft above the floor surface or grade.
Page 4 11. The heater should be installed in a place sheltered from the rain; 12. Only use the bracket supplied with the heater to fit to the surface; 13. Always make sure your electrical circuit complies with local regulations and heater is connected to electrical wiring with suitable circuit breakers;...
Page 5 Make sure you follow the instructions as outlined below. JAPIDI ENERGY keeps a full range of replacement elements in Inventory that can be ordered any time. You can also order a spare element in advance to avoid unnecessary delay in having your element replaced.
Page 6 19. You can adjust the fixing washers on the ends of the safety grid rods in or out to keep them in correct position; SPECIFICATIONS & WARRANTIES All Japidi Energy Infrared Heaters are manufactured in Canada with the following specifications: Certified to: CSA 22.2 No. 46-M1988 UPD 3, UL 2021 & UL 1278-9-06 INDUSTRIAL...
Page 7 WATT OUTPUT 1500W 1500W 1500W 2x 1500W CURRENT 4.15 Ampere 12.5 Ampere 6.25 Ampere 12.5 Ampere IR ELEMENT Quartz Halogen Infrared with Tungsten Element TYPE BURNING Horizontal & Horizontal & Horizontal & Horizontal & POSITION Vertical Vertical Vertical Vertical RATED 4500 hours ELEMENT LIFE ELECTRICAL AWG 14/3 105⁰...
Page 8 TO SEVEN YEARS FROM DATE OF ORIGINAL PURCHASE. *LIMITED 7 YEAR WARRANTY Blink Investments Inc. t/a Japidi Energy warrants this product against any defects that are due to faulty material or workmanship for a Seven-Year period from the original date of customer purchase, excluding the Element and Electrical Connectors.
