Summary of Contents for Tecla Shield DOS
- Page 1 Getting Started with your Tecla Shield Getting Started Connecting theTecla Shield DOS The Hardware...
- Page 2 When you first turn on your Tecla Shield, the status indicator light will start to blink. The colour of the blinking indicates the current mode. You can change the mode as described in “Connecting the Tecla Shield DOS” section, but first, you will want to decide which mode is right for you.
- Page 3 Shield doS Turn on the Tecla Shield DOS The - and + buttons are Slide the On/Off switch to ON to power up the Tecla Shield; the recessed into the case to Status Indicator Light will start to blink. prevent accidental selection.
- Page 4 / out) understanding the charging indicator Light When the Tecla Shield is connected to a power source (USB or DC input), the charging indicator light will come on, unless the battery is already fully charged. After the battery is fully charged, the charging...
- Page 5 DC Power Port Switch Ports (1 and 2) Use an AC adapter with 2.1mm center-positive barrel plug (9–24V) The Tecla Shield has two dual switch 1/8” or 3.5mm stereo ports to charge your Tecla Shield. (Optional) labelled 1 and 2.
- Page 6 The Hardware bottom View configuration buttons Configuration Buttons (- and +) These buttons can be used to: • Select a mode prior to connecting with a host device, or • Once connected, modify (increase/decrease) the auto-scanning...
