Summary of Contents for Scout WAVE
- Page 1 Digital Marine TV Antenna Installation and user instructions Guida d’installazione e istruzioni utente www.scoutantenne.com rev. 12/2016...
- Page 2 Omnidirectional design eliminates the time needed to locate the direction of a local TV and radio transmitter. Wave is equipped with a built-in high gain amplifier (25 dB) with extreme low noise figure (0.2) that increases the strength of incoming digital signals.
- Page 3 Antenna installation - Installazione dell’antenna Install the antenna in accordance with the following procedures to insure maximum performance of the antenna. The antenna should be installed in the place where is an all round clear view of the horizon and ►...
-
Page 4: Operation
OUTPUT IF REQUIRED Run the coax cable through the central hole and fit the F male connectors on both its terminations. TO TV ‘F’ COAXIAL FLYLEAD 12/24V FUSED CONNECTION Fate scorrere il cavo coassiale attraverso il foro centrale e montate i connettori F su entrambe POWER CONNECTION le estremità. - Page 5 Connect the F male connector that you fitted on the termination of the coax cable to the F female connector on the bottom of the antenna, then set the antenna on the surface in a way that both screws enter into the holes that you drilled earlier.
- Page 6 Wiring - Collegamento Wire the antenna as shown in the picture below. Collegare l’antenna seguendo lo schema sotto riportato. RED +12V Coax cable 75 Ohm 10 m (33’) BLACK - ANTENNA TV/RADIO TV/RADIO * Not supplied with the antenna. To be purchased separately.
-
Page 7: Specifications
Frequency Range (MHz): 40-860 PACK C SPECIFICATIONS Designed for Channels: 2-69 Wave è garantita per 2 anni da difetti di fabbricazione in termini di materiale e lavorazione dal ► continuous use Gain control: 0-18dB ” ” momento dell’acquisto. La garanzia esclude ogni malfunzionamento derivante da uso improprio o...
