Summary of Contents for Macsense E-430
-
Page 1: Ethernet Adapter
E-430/E440 Ethernet Adapter User’s Manual Networking the future... -
Page 2: Fcc Compliance Statement
Copyright Copyright © 2000 by the manufacturer of this product. All rights reserved. No part of this documentation may be reproduced in any form or by any means or used to make any directive work (such as translation or transformation) without permission from the manufacturer of this prod- uct. -
Page 3: Table Of Contents
Table of Contents Chapter 1 - Introduction ..... . .1 Introduction ........1 Hardware Supported . -
Page 4: Chapter 1 Introduction
Chapter 1 Introduction Introduction Thank you for purchasing our NuBus/LC PDS card. Each is very user friendly and installation is a snap. This manual will walk you through the installation process and set-up. The NuBus/LC PDS Ethernet adapter is a high performance adapter which supports Plug and Play and fully auto-configures to your system. -
Page 5: Operating System Supported
Chapter 1 Introduction Operating System Supported Your system must be 7.0 or higher to install the proper driver. Please note that if your system is 7.5.2 or before. You must change a default setting in your computer. (see software installation) If your system is 7.5.3 or higher and does not contain an Open Transport extension. -
Page 6: Led Indicators
Chapter 1 Introduction LED Indicators LC PDS: Link and RX (see figure 3) NuBus: Link, RX, TX, and PWR (see figure 4) LED Indicator Functions: • Link Lit - Indicates Connection is OK. Unlit - Indicates no Connection. • RX Blinking - the Ethernet card is receiving data •.TX Blinking - the NuBus card is transmitting data... -
Page 7: Chapter 2 Installation
Chapter 2 Installation Jumper Settings ( for combo only ) If you have a BNC cable (resembles a cable TV co-axial cable) the jumper should cover the left 2 pins. (See diagram below). If you have a TP cable (resembles a telephone line plug) the jumper should be set cov- ering the 2 right side pins. -
Page 8: Chapter 2 Installation
Chapter 2 Installation • Double click on the Network icon • Click once on the EtherTalk icon. • Close the window. If your system is 7.5.3 or above with no “Open Transport Software,” you must download software from Apple Computer’s web site.When you have finished installing “... -
Page 9: Specifications
Specifications Specifications • Media: 10BASE-T (Combo&T-only) RJ-45 STP- 1/UTP-3,4,5 10BASE-2 (Combo) BNC RG-58 • Standard: IEEE 802.3 10Mbps • Transmission Rate: 20/10Mbps at Full/Half Duplex mode • LED Indicators: Link (E430 E440), RX (E430 E440), TX (E440), PWR (E440) • Certifications: FCC Class A CE Class A •...
