MedToolz PO300 Instructions To User

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Dear users, thank you very much for purchasing the Pulse Oximeter.
This Manual is written and compiled in accordance with the council directive MDD93/42/EEC for
medical devices and harmonized standards. In case of modifications and software upgrades, the
information contained in this document is subject to change without notice.
The Manual describes, in accordance with the Pulse Oximeter's features and requirements, main
structure, functions, specifications, correct methods for transportation, installation, usage, operation,
repair, maintenance and storage, etc. as well as the safety procedures to protect both the user and
equipment. Refer to the respective chapters for details.
Please read the User Manual carefully before using this product. The User Manual which describes
the operating procedures should be followed strictly.Failure to follow the User Manual may cause
measuring abnormality, equipment damage and human injury. The manufacturer is NOT responsible
for the safety, reliability and performance issues and any monitoring abnormality, human injury and
equipment damage due to users' negligence of the operation instructions. The manufacturer's
warranty service does not cover such faults.
Owing to the forthcoming renovation, the specific products you received may not be totally in
accordance with the description of this User Manual. We would sincerely regret for that.
This product is medical device, which can be used repeatedly.
WARNING:
Uncomfortable or painful feeling may appear if using the device ceaselessly, especially for
the microcirculation barrier patients. It is recommended that the sensor should not be
applied to the same finger for over 2 hours.
For the special patients, there should be a more prudent inspecting in the placing process.
The device can not be clipped on the edema and tender tissue.
The light (the infrared is invisible) emitted from the device is harmful to the eyes, so the
user and the maintenance man should not stare at the light.
Testee can not use enamel or other makeup.
Testee' s fingernail can not be too long.
Please refer to the correlative literature about the clinical restrictions and caution.
This device is not intended for treatment.
The User Manual is published by our company. All rights reserved.
Instructions to User
I

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PO300 and is the answer not in the manual?

Questions and answers

Summary of Contents for MedToolz PO300

  • Page 1 Instructions to User Dear users, thank you very much for purchasing the Pulse Oximeter. This Manual is written and compiled in accordance with the council directive MDD93/42/EEC for medical devices and harmonized standards. In case of modifications and software upgrades, the information contained in this document is subject to change without notice.

  • Page 2: Table Of Contents

    CONTENTS 1. Safety ............................. 1 1.1. Instructions for safe operations ................... 1 1.2. Warning ..........................1 1.3. Hazards ..........................1 2. Overview ............................2 2.1. Features ..........................3 2.2. Major applications and scope of application ............... 3 2.3. Environment requirements ....................3 3.

  • Page 3: Safety

    1. Safety 1.1. Instructions for safe operations Check the main unit and all accessories periodically to make sure that there is no visible damage that may affect patient’s safety and monitoring performance about cables and transducers. It is recommended that the device should be inspected at least once a week. Please stop using the monitor if there is obvious damage to the device.

  • Page 4: Overview

    User Manual in the relative chapter (7.1)for instructions of cleaning and disinfection. Do not immerse the oximeter in liquid. When it needs cleaning, please wipe its surface with disinfectant solution using a soft cloth. Do not spray any liquid directly onto the device. When cleaning the device with water, the temperature should be lower than 60℃...

  • Page 5: Features

    2.1. Features A. Operation of the product is simple and convenient. B. The product is small in volume, light in weight and convenient in carrying. C. Low power consumption 2.2. Major applications and scope of application The Pulse Oximeter can be used in measuring the pulse oxygen saturation and pulse rate through finger.

  • Page 6: Technical Specifications

    Figure 1 4. Technical specifications 4.1. Main performance A . SpO value display B. Pulse rate value display, bar graph display C. Pulse waveform display D . Low-voltage indication: low-voltage indicator appears before working abnormally which is due to low-voltage E.

  • Page 7: Installation

    The deviation between the value measured in the condition of man-made light or indoor natural light and that of darkroom is less than ±1%. F. Power supply requirement: : 3.6 V DC ~ 4.2V DC. G. Optical Sensor Red light (wavelength is 660nm,6.65mW) Infrared (wavelength is 880nm, 6.75mW) H.

  • Page 8: Usb Port

    5.3. USB port Figure 3. USB port :It is used to connect a personal computer to export the trend data or charge the lithium battery via a data line. 5.4. Accessories A. a hanging rope B. a user manual C. a power adapter (optional)(GTM41076-0605;CMS0105) D.
  • Page 9 Figure 4 B. Change display direction: On the measuring interface, you can change the display direction by pressing the button shortly. C. Pause alarm: a) Alarm including the alarm of measure data's going beyond the limits, the alarm of low-voltage, the alarm of finger's out of position.
  • Page 10 Figure 5 Main Menu Interface a) Backlight adjustment On the main menu interface, click the power button to select “Brightness”, Press the power button and hold to adjust the backlight brightness. b) Alarm setting On the main menu interface, click the power button to select “Alarm”, Press the power button (1sec) to enter the alarm setting interface as shown in Figure 6: a.
  • Page 11 Figure 6 Alarm Setting Menu c. Pulse sound indication setting Click the power button to select “Pulse Sound”, then Press the power button to choose to have the Pulse Sound (heart beat) alarm “on” or “off”. d. Exit the Alarm settings Click the power button to select “EXIT”, then Press the power button to exit the Alarm Settings Menu.
  • Page 12 and SpO value accurately, transfer the data to the computer, display the data and print reports (with the included SpO Software - Green Heart) a. From the “Settings Menu” Click the power button to select “Record”, then Press the power button to enter the start time of data storage test (see Figure 9).

  • Page 13: Attention For Operation

    c） When the device is in the state of battery charging, the indication light is on, when the battery capacity is full, the indication light would be off accordingly. If the alarm function is on,the device will provide high-priority alarm signal when the battery is in low power status .Intermittent alarm will occur and the battery icon turns red in the state of flashing.

  • Page 14: Maintain、Transportation And Storage

    7. Maintain、transportation and storage 7.1. Cleaning and disinfecting When using alcohol wipes to disinfect the device, please air dry or clean it with clean soft cloth. 7.2. Maintain A . Please clean and disinfect the device before using according to the User Manual(7.1). B.

  • Page 15: Key Of Symbols

    2. The battery is drained away or almost drained away . The battery can not be full charged even Please contact the local service The battery is broken center. after 10 hours charging time. 9. Key of Symbols Signal Description Warning –...

  • Page 16: Function Specification

    IPX1 Ingress of liquids rank WEEE (2002/96/EC) This item is compliant with Medical Device Directive 93/42/EEC of June 14, 1993, a directive of the European Economic Community. 10. Function Specification Information Display Mode ） The Pulse Oxygen Saturation（%SpO 2-digit digital OLED display Pulse Rate（bpm）...
  • Page 17 Battery working life Charge and discharge no less than 500 times. Power Adapter Input Voltage 100 to 240 VAC, 50/60 Hz Output voltage 5 VDC Output current 10000mA Oximeter Probe Wavelength:660nm 880nm Dimensions and Weight Dimensions 57(L) × 32(W) × 30 (H) mm Weight About 50g (with the lithium battery*1)

  • Page 18: Appendix 1

    Guidance and manufacture’s declaration – electromagnetic emission The PO300 Pulse Oximeter is intended for use in the electromagnetic environment specified below. The customer of the user of the PO300 Pulse Oximeter should assure that it is used in such and environment. Emission test Compliance Electromagnetic environment –...
  • Page 19 Guidance and manufacture’s declaration – electromagnetic immunity The PO300 Pulse Oximeter is intended for use in the electromagnetic environment specified below. The customer or the user of PO300 Pulse Oximeter should assure that it is used in such an environment.
  • Page 20 Guidance and manufacture’s declaration – electromagnetic immunity The PO300 Pulse Oximeter is intended for use in the electromagnetic environment specified below. The customer or the user of PO300 Pulse Oximeter should assure that it is used in such an environment.
  • Page 21 RF communications equipment and the PO300 Pulse Oximeter. The PO300 Pulse Oximeter is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the PO300 Pulse Oximeter can help prevent electromagnetic interference by...
