LED Panel Light – E830J
1．Key Features and Benefits
20W LED lamp as high‐quality
300*300mm Side‐glowing LED panel light
AC100~277V/ 50‐60Hz input voltage
160° beam angle
Non‐Dimmable
Available in three different colour temperatures:
▷
3000K – warm white
▷
4000K – neutral white
▷
5000K – cool white
▷
Other Colours ¹
LED panel light with High uniformity
High colour consistency (standard deviation colour matching <5)
Shock‐proof and vibration‐proof
40,000 hours lifetime
UV and NIR radiation free
Mercury free
3 years Light Emission Technology Guarantee and Lifetime technical support
"¹"
Demand for other colours，please land on www.lightemissiontech.com , we can do more for you !
SSL LED panel light
Edition January 2013, subject to alteration
High energy efficiency 20W LED panel light Luminous
update 1700Lm
High power factor
Over‐temperature protection
High uniformity
High quality light with a colour rendering index of 80
Product Offering
Type reference
E830J-20-830-160S
E830J-20-840-160S
E830J-20-850-160S
The Future of Lighting, Today!
Light Emission Technology
www.lightemissiontech.com
Wattage
CCT
Luminous
20W
3000K
1500Lm
20W
4000K
1700Lm
20W
5000K
1750Lm
Beam
Angle
160°
160°
160°
LIGHT EMISSION TECHNOLOGY
Advertisement
Summary of Contents for Light Emission Technology E830J
- Page 1 Light Emission Technology www.lightemissiontech.com LED Panel Light – E830J High energy efficiency 20W LED panel light Luminous update 1700Lm High power factor Over‐temperature protection High uniformity High quality light with a colour rendering index of 80 Product Offering Beam Type reference Wattage CCT Luminous Angle E830J-20-830-160S 3000K 1500Lm 160° E830J-20-840-160S 4000K 1700Lm 160° E830J-20-850-160S 5000K 1750Lm 160°...
-
Page 2: Mounting Information
LED parameters are merely statistical values that do not necessarily correspond to the actual parameters of an individual product; individual products may vary from the typical values. “³” The average lifetime of LED lamps is defined as the number of hours when the light output of 50% of a large group of identical lamps goes below 70% of its initial luminous flux(L70B50,IEC60969).The lifetime is estimated open lamps at room (Ta=25℃) ,free air burning, base up burning position and at rated voltage. “⁴” The Tc is defined as the highest permissible temperature which may occur on the outer surface of the LED lamp under normal operating conditions and at the rated voltage/current/power or the maximum of the rated voltage/current/power range. “⁵” The tolerance of the product weight is +5%. SSL LED panel light The Future of Lighting, Today! Edition January 2013, subject to alteration LIGHT EMISSION TECHNOLOGY... - Page 3 1m 523Lux 496Lux 2m 130.5Lux 124Lux 3m 58Lux 55Lux The data is for samsung 5630 LED. 7．Uniformity Unit: x 1000Lux 6. Photometri “⁶” Center intensity spread angle（50%） ：half beam angle; Center intensity spread angle（10%） ：full beam angle. SSL LED panel light The Future of Lighting, Today! Edition January 2013, subject to alteration LIGHT EMISSION TECHNOLOGY...
-
Page 4: Disposal Information
11. Installation instructions Supply with no fixtures, you can DIY the steel wire for fixing. Supply with specific fixtures. *The fixtures need to be charged additionally, it depends on your choice. SSL LED Lamps The Future of Lighting, Today! Edition January 2013, subject to alteration LIGHT EMISSION TECHNOLOGY... - Page 5 Light Emission Technology, Ltd. 4/F, Midstar Technology Building, 3 Road Liuxian, 68 The Future of Lighting, Today! Zone, BaoAn District, Shen Zhen, China. 518101 Tel: +86-755-29641619 Fax: +86-755-29641700 LIGHT EMISSION TECHNOLOGY www.lightemissiontech.com, service@lightemissiontech.com © 2013 Light Emission Technology, Ltd. All rights reserved.01/01...
