  • Page 1 MV-410HS Multi Viewer MV-410HS Command MV-410HS Layout Editor MV-410HS Live Viewer MV-410HS Web Browser Layout Editor Tutorial Edition...
  • Page 2 37 pages MV-410HS Command • • • • • • • • • • 29 pages MV-410HS Layout Editor • • • • • • • • • • 37 pages MV-410HS Live Viewer • • • • • • • • • •...
  • Page 3 Operate unit on the specified supply voltage. Caution Disconnect power cord by connector only. pull on cable portion. place or drop heavy or sharp-edged objects on power cord. A damaged cord can cause fire or electrical shock hazards. Regularly check power cord for excessive wear or damage to avoid possible fire / electrical hazards.
  • Page 4 remove covers, panels, casing, or access circuitry with power applied to the unit! Turn power off and disconnect power cord prior to removal. Internal servicing / adjustment of unit should only be performed by qualified personnel. touch any parts / circuitry with a high heat factor. Capacitors can retain enough electric charge to cause mild to serious shock, even after power is disconnected.

  • Page 5: Connection

    Unpacking MV-410HS units and their accessories are fully inspected and adjusted prior to shipment. Operation can be performed immediately upon completing all required connections and operational settings. Check your received items against the packing lists below. ITEM REMARKS MV-410HS AC Cord...
  • Page 6 3) Insert the both ends of Retaining Clip 1 into the holes of Retaining Clip 2. The installation is now complete. Font The font used in this product is the Ricoh Vector Font designed by Ricoh Company Limited.

  • Page 7: Table Of Contents

    2. Quick Start ..........................3 2-1. Connection .......................... 3 2-2. Displaying Image on DVI / RGB Monitor ................4 2-3. Connecting MV-410HS and PC over LAN ................6 2-3-1. PC Network Settings ....................6 2-3-2. Installing MV-410HS Layout Editor ................7 2-3-3.
  • Page 8 7-1. Main Menu Screen ......................22 7-2. SYSTEM .......................... 24 7-2-1. INPUT FORMAT ....................... 25 7-3. LAN ..........................26 7-4. SERIAL ..........................27 7-5. VERSION ......................... 28 8. Output Size Test Mode ......................29 9. RS-232C/422/485 Interface ...................... 30 9-1. Changing RS-422/RS-485 or Termination ................ 30 9-2.
  • Page 9 FOR-A provides a wide range of products, from basic support units to complex system controllers, which have been increasingly joined by products for computer video based systems. Whatever your needs, talk to your FOR-A representative. We will do our best to be of continuing service to you.
  • Page 10 The following conventions are used throughout this manual: Text enclosed by a square (such as MATT) indicates software Text enclosed by square brackets (such as [Ctrl]) indicates the Shaded text (such as OFF) indicates the setting in the menu. MV-410HS...
  • Page 11 This chapter describes the basic operations to set up the system for your MV-410HS multi viewer. Refer to the section given for each operation you may need more details, if necessary. 3) DVI/RGB monitor 2) Video cameras, etc. (HD/SD-SDI or/and...
  • Page 12 LOCK/ENTER button 1) Checking Monitor Display of Output Image Turn on the power switch on the MV-410HS front panel. When power switch is turned on, the output image is displayed on the DVI/RGB monitor. Is the image displayed on the monitor? Follow the steps given for each case.
  • Page 13 'No display or Incorrect Display' or 'Checking other output screen sizes', and see if you can get a correct display. * Pressing the MENU button will start up the MV-410HS and also store the adjustments. 3) After completing all adjustments Press the MENU button to resume the MV-410HS start up.

  • Page 14: Pc Network Settings

    Connect the MV-410HS and a PC (on which you are going to install the Layout Editor) over a LAN interface. This setting example shows the case when connecting to the MV-410HS with the default settings. The MV-410HS default settings are shown below.

  • Page 15: Installing Mv-410Hs Layout Editor

    Install the MV-410HS Layout Editor on the PC using the supplied CD-ROM. In this section a rough instruction for the installation is given. For more details see section 1-4. "Installing MV-410HS Layout Editor" in the MV-410HS Layout Editor Operation Manual.
  • Page 16 2) After the application is started the screen shown below is displayed. MV-410HS ID boxes 3) Enter the IP address, ID and password of the MV-410HS that you wish to connect in the MV-410HS ID boxes at the top-right of the main screen. (The factory default of the MV-410HS is as below.)

  • Page 17: Front Panel

    (10) MENU (Menu button) Used to open Main menu. While displaying menus, used to return to Main menu or submenu, or exit Main menu. * To open Main menu, press and hold down the button at least 2 seconds. MV-410HS...
  • Page 18 Used to ground the unit to protect operators against static electricity and electrical shock. (9) AC IN (100-240VAC 50/60Hz) Used for connecting to an AC power source using the supplied accessory cord. Use AC IN1 when using a single power unit. MV-410HS...
  • Page 19 Control on MV-410HS To directly connect PC and MV-410HS, use a crossover LAN cable for the connection. To connect PC and MV-410HS using a hub or such device, use a straight LAN cable. DVI/RGB monitor Video cameras, etc. (HD/SD-SDI or/and...
  • Page 20 ENTER POWER 1 POWER 2 The MULTICAST mode using IP multicast supports the system that can provide video outputs to multiple monitors through the MV-410HS as shown below. Video cameras, etc. (HD/SD-SDI or/and Analog composite) Switching HUB MV - 410HS...
  • Page 21 If a menu screen was displayed when the unit was turned off, operation resumes from the status before the menu screen. Although initialization is normally not required, you can restore the MV-410HS factory settings by the data initialization when the previous data is no longer needed such as after relocation or system modification.
  • Page 22 MV - 410HS MULTI VIEWER POWER 1 LOCK MENU FULL SPLIT POWER 2 ENTER ALARM POWER 1 POWER 2 SPLIT button The image distortion occurs while switching layouts. A black screen is shown for channels with no input signals. MV-410HS...

  • Page 23: Rear Panel

    MV-410HS can be remotely controlled using contact inputs to the TALLY IN/REMOTE connector on the rear panel. The connector is also provided with pins for external tally inputs that enables to display two color borders on video frames. REMOTE/TALLY Connector pin assignments (25-pin, D-sub female) Inch screws Pin no.
  • Page 24 The figure at right depicts the MV-410HS circuit for each input pin. Photo coupler Input pin The figure at right depicts the MV-410HS circuit for each output pin. 74LS06 or equivalent Outputs 5V TTL level alarm signal. MV-410HS External control device Control via REMOTE connector operates the same as control from front panel buttons.
  • Page 25 The display mode can be selected from three options. See section 3-2-1. "System" in the MV-410HS Layout Editor Operation Manual for details on setting display mode. Displays the title and audio level meters without overlapping on the video image. The aspect ratio of the input signal is retained.
  • Page 26 Overlaps the title and audio level meters on the video image. The aspect ratio of the input signal is not retained, and the image is displayed to fill the selected display mode screen. Image CHANNEL1 The split screen layout can be freely arranged using the supplied Layout Editor. CHANNEL2 CHANNEL1 CHANNEL4 CHANNEL3 LOSS MV-410HS...
  • Page 27 Two tally inputs (red and green) are available for each channel input. Tally is displayed outside the border. Tally display color for simultaneous inputs of red tally and green tally can be selected from red or orange. See section 3-2-3. "Tally" in the MV-410HS Layout Editor Operation Manual for details.
  • Page 28 4:3 or 16:9 can be reduced or eliminated, and the images can be enlarged and displayed to best fit the output screen. See section 3-2-6. "Crop" in the MV-410HS Layout Editor Operation Manual for details on crop settings. <Side Panel>...
  • Page 29 Audio level meter for up to 8 channels can be displayed for each HD-SDI and SD-SDI input. For the details on audio level meter settings, see section 4-3-8. "Changing Display Position of Audio Level Meters" in the MV-410HS Layout Editor Operation Manual. (1) Peak Level Peak level can be set in the range of -30dBFS to 0dBFS.

  • Page 30: System

    Accesses the submenu of the selected item. Item Setting details Reference Input signal format settings Network mode settings 1 SYSTEM ID and Password settings Date and time settings 2 LAN Network settings 3 SERIAL Serial interface settings 4 VERSION Version display MV-410HS...
  • Page 31 Menu Diagram INPUT FORMAT MAIN SYSTEM AUTO NETWORK MODE PASSWORD MANUAL ADJUST TIME STANDARD 2007-01-01 00 00 00 IP ADDRESS MASK LENGTH MULTICAST ADDRESS MULTICAST PORT GATEWAY MAC ADDRESS SERIAL SELECT SERIAL BAUDRATE PARITY SERIAL ID VERSION MV-410HS...

  • Page 32: Unicast Mode

    STANDARD Uses LTC time code signal. Year: 2000 - 2099 Month: 01 - 12 Day: 01 - 31 Date and Time Used to set the current time. Time: 00 - 23 Minute: 00 - 59 Second: 00 - 59 MV-410HS...
  • Page 33 Setting details AUTO mode: Displays input signal format 1080/59.94i, 1080/50i MANUAL mode: Used to select input 720/59.94p, 720/50p signal format. CH1 - 4 525/60, 625/50 *525/60, and 625/50 represent SD-SDI signals. NTSC, and PAL represent NTSC, PAL analog composite signals. MV-410HS...
  • Page 34 *This setting is not required for the connection in unicast mode. If your using network does not have a GATEWAY 0.0.0.0 - 255.255.255.255 gateway, this setting is not required. Displays the MAC addresses of the device. Do not change ADDRESS The value cannot be changed. MV-410HS...
  • Page 35 If you change the value for the items other than MULTICAST ADDRESS and MULTICAST PORT, a warning message appears to require the restart of the unit. Whenever you have changed these settings, power off the MV-410HS once and power on again.
  • Page 36 On the MAIN MENU screen, move the cursor to [VERSION] and press the ENTER button. The VERSION screen is displayed as shown below. On the VERSION screen, the version information of MV-410HS can be seen. SOFT 01.00 HARD1 01.00 HARD2 01.00...
  • Page 37 MENU is stored.) If the connected monitor does not display the image in the format set on the MV-410HS, verify the format actually output by the LEDs on the front panel. See the table below for the verification. If you need to change the format for the display according to the test result, change the format using the Layout Editor.
  • Page 38 SUB card inside. Remove 8 screws from the top panel of the main unit. MV - 410HS MULTI VIEWER POWER 1 FULL SPLIT LOCK MENU POWER 2 ENTER ALARM POWER 1 POWER 2 MV-410HS...
  • Page 39 Termination Front Return the top panel in place and secure with screws. 5) Power on the MV-410HS. Open [SERIAL] Menu screen, and select RS-422 or RS-485 at [SERIAL SELECT]. Before performing the above operation to change interface selection, disconnect the serial cable from the connector on the rear panel.
  • Page 40 Unassigned Signal ground Unassigned Input Receive data Output Transmit data Unassigned RS-485 connector pin assignment (9-pin, D-sub male) Pin no. Signal In/Out Description Unassigned TX/RX+ In/Out Transmit/Receive data Unassigned Unassigned Signal ground Unassigned TX/RX- In/Out Transmit/Receive data Unassigned Unassigned MV-410HS...
  • Page 41 1 [bit] Parity Select from NONE, ODD, or EVEN Flow control None DSR/DTR and RTS/CTS are looped back in the MV-410HS Use a RS-232C straight cable or 422 straight cable to connect another device such as a PC. MV-410HS Pin no.
  • Page 42 If any of the following problems occur during operation of the MV-410HS, before assuming a unit malfunction has occurred, follow the troubleshooting procedures below to see if the problem can be corrected. If the problem is not corrected by performing the procedures below, turn the unit off and then on again.

  • Page 43: Screen Display

    Frame: Red or Green per input. (Red or Umber selectable for the display at the simultaneous inputs of red and green tallies.) Audio Level Meters 8 embedded audio channels per input * Embedded audio signals are not passed through. MV-410HS...

  • Page 44: Dimensions

    430 (W) x 44 (H) x 400 (D)mm, EIA1RU Accessories Operation Manual, AC cord, Rack mount brackets, CD-R (Layout Editor, Live Viewer) Option Redundant power supply Consumables Battery: Replace every 4 years (at room temperature) Fan: P1399 (front and rear) Replace every 5 years (at room temperature) MV-410HS...
  • Page 45 (All dimensions in mm) MV-410HS MU LTI VI E W ER F ULL S P LI T LO C K MEN U O FF EN TER POWER 1 POWER 2 2x2-6.4x12 MV-410HS...

  • Page 46: Crop

    Crop ..............20 MV-410HS...
  • Page 47 MV-410HS...
  • Page 49 This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
  • Page 50 10/03/2011 Printed in Japan Head Office 3-8-1 Ebisu, Shibuya-ku, Tokyo 150-0013, Japan Overseas Division Phone: +81(0)3-3446-3936, Fax: +81(0)3-3446-1470 Japan Branch Offices Osaka/Okinawa/Fukuoka/Hiroshima/Nagoya/Sendai/Sapporo R&D/Production Sakura Center/Sapporo Center 11155 Knott Ave., Suite G&H, Cypress, CA 90630, USA Phone: +1-714-894-3311 Fax: +1-714-894-5399 2 Executive Drive, Suite 670, Fort Lee Executive Park, Fort Lee, NJ 07024, USA Phone: +1-201-944-1120 Fax : +1-201-944-1132 2400 N.E.
  • Page 53 Redo...
  • Page 54 Half...
  • Page 56 Setti...
  • Page 57 LARGE...
  • Page 58 Change Change...
  • Page 59 page, the tally detection On or Off to the TALLY IN/REMOTE connector on the rear...
  • Page 62 at the top right of the main...
  • Page 64 at the top right of the main...
