ExPelec DJ-STAR Operating Manual

Professional stereo sound mixer
Hide thumbs

Advertisement

Available languages

Available languages

Quick Links

Download this manual
DJ - STAR
TABLE DE MIXAGE
NOTICE D'UTILISATION

Advertisement

loading
Need help?

Need help?

Do you have a question about the DJ-STAR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ExPelec DJ-STAR

  • Page 1 DJ - STAR TABLE DE MIXAGE NOTICE D’UTILISATION...
  • Page 3 FACE SUPERIEURE 1 – INTERRUPTEUR DE MARCHE/ARRET 2 – CUE LEVEL : Contrôle du volume du casque. 3 - BOUTON « GAIN » : Ils permettent le réglage du gain d’entrée de chaque voie. 4 – CONTROLE DU VOLUME DE CHAQUE VOIE : Fader stéréo de réglage du niveau.

  • Page 4: Face Arriere

    FACE ARRIERE 13 – ENTREES PHONO ASYMETRIQUES : Ce sont des entrées jack RCA spécialement étudiées pour être utilisées avec des cellules phono magnétiques. Aucun autre appareil ne peut être utilisé avec cette entrée. 14 - ENTREES LINE/CD ASYMETRIQUES : Ce sont des entrées Jack RCA qui doivent être connectées à...

  • Page 6: Specifications Techniques

    SPECIFICATIONS TECHNIQUES Sensibilité d’entrée 1 mV / 600 ohms PHONO 3 mV / 51 K ohms (RIAA) LINE 150 mV / 100 K ohms Niveau de sortie (maxi 4V) MASTER 0.775 V / 600 Ohms 0.38 V / 600 Ohms PHONES 100 mV / 100 K Ohms Réponse en fréquence...
  • Page 7 Owner’s Operating Manual Professional Stereo Sound Mixer     Please read before using this equipment     ...
  • Page 9 Front Panel 1. POWER Switch: This switches the AC power to the mixer ON or OFF. Note: Be sure to switch on the power to your mixer before switching on the amplification system. 2. CUE Level Control: This control varies the volume in your headphones, the volume of the signal heard through the headphones.
  • Page 10 Rear Panel 13. PHONO Inputs: These inputs are unbalanced RCA jacks. Use these only for turntables with moving magnet cartridges. Line level sources will overload these inputs. Moving coil cartridges require a separate head amp for optimum sound. 14. LINE/CD Inputs: These inputs are unbalanced RCA jacks, connect stereo audio from Hi Fi VCRs, cassette and reel-to-reel tape decks, CD players, VDPs, Tuners, even synthesizers or other mixing consoles.

  • Page 12: Specifications

    SPECIFICATIONS: Input Sensitivity/ Impedance: 1mV / 600 Ohms PHONO 3mV / 51KOhms (RIAA) LINE 150mV / 100KOhms Output Level/ Impedance: MASTER (Max. Output: 4V) 775mV/600Ohms 380mV/600Ohms PHONES 100mV/8Ohms Frequency Response: 20Hz~20KHz ±1dB (RIAA ±2dB) Total Harmonic Distortion: Less than 0.1% Stereo Separation: More than 45dB Signal-To-Noise Ratio:...
