- Page 1 E800MS v.1.0 Enhance RAID E800MS Quick start guide Linux www.enhance-tech.com © Copyright. Enhance Technology, Inc. Proudly Assembled in the U.S.A.
-
Page 2: Quick Start Guide
SAS solution for professionals who demand exceptional data protection. Featuring up to 16TB of capacity, cable-less backplane and Mini SAS connectivity for PC and Mac. What is in the box? Carefully unpack your E800MS storage system, and inventory the accessories according to your model type. Enhance RAID... - Page 3 HBA/RAID Controller Installation If your system was purchased with capacity, please skip this section and Your E800MS features a RAID-ready JBOD architecture. This provides the best immediately go to next section. If your system was purchased without disks, support for a wide range of host bus adapters & PCI RAID controllers.Always install each disk into the provided disk trays and fasten using the supplied hdd follow your HBA/RAID controller’s installation procedure to ensure proper...
- Page 4 Connecting Your E800MS-Host Workstation Introduction to MiniSAS Cable Types After connecting the cable to your E800MS connect Mini SAS cable to an open port on your MiniSAS HBA or RAID controller. Currently there is no MiniSAS connector standard. Your E800MS is equipped with two industry standard SFF8088 x4 MiniSAS The most common interface cable types are both SFF8088-to-SFF8088, and interface ports.
- Page 5 E800MS Quick start guide After you power on the E800MS, you can configure the system via Web GUI taht comes with HBA RAID controller. Please refer to your HBA RAID controller user menual for detail information. This section is provided as a reference only. Please consult your dealer regarding the best choice of HBA/RAID controller for your media requirements.
- Page 6 Three (3) YEARS from the date of retail purchase by the original end-user purchaser ('Warranty Period"). If a hardware defect arises and a valid claim is received within the Warranty Period, at its option, Enhance Technology...
